6. Power-on
• Checkforcompletionofindoor/outdoorunitswiring.
• Checkforclosingofcontrolboxlidofindoorandoutdoorunitsbeforeturningonthepower.
• When1indoorunitiscontrolledby2remotecontrollers.
BesuretosetthesubremotecontrollerbychangingtheSS1switchonthesideofthePCBfromthe
MASTERtotheSLAVEposition.

Fortheconnectionbetweenthemainremotecontrollerandsubremotecontroller,pleasereferto
Connection diagram “Group control: main controller + sub controller”onpage20.
SS1MASTERSLAVE
SS1MASTERSLAVE SS1MASTERSLAVE
(1)
(2)
(1)Factoryset:MASTER (2)MovetoSLAVE
1) “ ”isdisplayedafterturningonthepower.
Theairconditionerwillchecktheconnection.
• Iferrorsaredetected,therelevanterrorcodeblinkson
the screen. Please see more details about error codes
athttps://www.daikin.co.th/en/service-error-code
Aftercorrectingtheerror,thebasicscreenisdisplayed.
• Ifsubremotecontrollerisnotsetwhenturningonthe
powerinthecaseofindoorunitscontrolledby
2 remote controllers.

Incasethescreendisplayshows“ ”,turnoffthe
poweroftheremotecontrollerandbreakerofair
conditioner.ThenchangetheSS1switchfromthe
MASTERtotheSLAVEpositionasdescribedabove,
thenturnonthepoweragain.
Ifthebasicscreenisnotdisplayedmorethan
2minutesafterthesubremotecontrollerisset,turn
offthepoweragainandcheckthewiring.

Incasethescreendisplayshows“ ”formore
than2minutes,turnoffthepoweroftheremote
controllerandbreakerofairconditioner.Then,
pleasemakesuretheswitchSS1positionofmain
remote controller is MASTER and the sub remote
controllerisSLAVE.
2) Whennoerrorsaredetected,thebasicscreenis
displayed.
1)
2)
*Errorcodeblinks
[Main/Sub remote controller]
[Basic screen]
