Daikin BRC2E61 - Upper Case Installation

12
5) Install the upper case in the original position.
• Aligntheuppercasewiththetabsonthelowercase(4points),theninsertandinstalltheuppercase.
Carefullycheckthatthereisnogapbetweentheupperandlowercaseswhentheyareclosed.
Nogap
Good Wrong
There is a gap.
Ifthereisagap,removetheuppercaseandrearrangewireharnesspositionthenreinstall
theuppercase.(Fortheremovalmethodoftheuppercase,seethenote.)
• Installthewiringwithcaretopreventpinching.
• Peelofftheprotectivesheetwhichisattachedtotheuppercase.
Note:
When removing the upper case
Insertascrewdriverintherecessoflowercasetoremovetheuppercase(2points).
Remote controller PCB is installed
on the upper case.
TakecarenottodamagethePCB
withthescrewdriver.
Takecarethatdustormoisturedoes
not touch the PCB.
Uppercase
Lowercase
Screwdriver
Insertandtwistthe
screwdriverlightlyforremoval.
