Daikin BRC2E61 - Securing the Controller Casing

11
4) Fix the lower case to a wall.
IncaseofwiringaremotecontrollerthroughToprightoutlet,Rightoutlet,orBottomcentreoutlet,
performwiringthoughtheoutletholeinthelowercasebeforeinstallingonthewall.
Securebyusingtheattachedwoodscrews(2pcs.)orsmallscrews(2pcs.).Fixthetopscrew
holerst,thenxthebottomscrewhole.
Woodscrews(M3.5×16)
orSmallscrews(M4×16)
• Selectasataplaceaspossiblefortheinstallationface.
• Donottightentheinstallationscrewstoomuchsoasnottodeformthelowercase.
CAUTION
