 Group control: main controller + sub controller
P1 P2P1 P2P1 P2
P1 P2P1 P2
20 1
[Maincontroller] [Subcontroller]
 Controller + DIII central control equipment
F1 F2 P1 P2
P1 P2F1 F2
Note:
IfthecontrollerisusedtogetherwithDIIIcentralcontrolequipment,then...
• ... the schedule timer function can be restricted.
• ...donotenablesetbackmode.
