74
APPENDIX A BLOWER PERFORMANCE DATA
RPM DDC % BHP RPM DDC % BHP RPM DDC % BHP RPM DDC % BHP RPM DDC % BHP
600 462 17 0.08 606 17 0.11 721 22 0.16 812 26 0.22 886 28 0.27
800 526 22 0.11 656 24 0.16 761 28 0.23 852 31 0.31 924 32 0.37
1000 590 26 0.16 705 30 0.22 802 33 0.32 891 37 0.43 962 35 0.51
1200 653 31 0.24 754 36 0.32 842 39 0.45 930 42 0.59 1000 39 0.70
1400 717 35 0.35 804 42 0.46 883 45 0.64 970 48 0.81 1038 42 0.96
1500 749 38 0.42 828 45 0.55 903 48 0.76 989 51 0.95 1057 44 1.13
RPM DDC % BHP RPM DDC % BHP RPM DDC % BHP RPM DDC % BHP RPM DDC % BHP
600 486 17 0.08 622 17 0.12 763 22 0.17 861 25 0.23 939 28 0.29
800 553 21 0.11 685 23 0.17 806 27 0.24 902 31 0.32 979 34 0.38
1000 619 26 0.17 749 29 0.23 848 33 0.33 943 36 0.43 1018 39 0.50
1200 686 30 0.25 812 35 0.33 890 39 0.46 984 42 0.58 1057 44 0.66
1400 753 35 0.37 875 41 0.46 933 44 0.63 1025 47 0.78 1097 50 0.88
1500 786 37 0.46 907 44 0.55 954 47 0.74 1045 50 0.90 1117 52 1.01
RPM DDC % BHP RPM DDC % BHP RPM DDC % BHP RPM DDC % BHP RPM DDC % BHP
600 441 13 0.08 583 18 0.09 702 24 0.13 794 28 0.17 876 32 0.21
800 498 22 0.10 628 26 0.12 740 32 0.18 829 36 0.23 910 41 0.28
1000 556 31 0.12 673 34 0.17 778 40 0.25 864 44 0.31 944 50 0.37
1200 613 40 0.15 718 42 0.25 816 49 0.35 899 53 0.42 978 60 0.50
1400 670 49 0.19 764 50 0.34 853 57 0.49 934 61 0.57 1012 69 0.68
1500 699 54 0.21 786 54 0.41 872 61 0.58 951 65 0.66 1029 74 0.79
RPM DDC % BHP RPM DDC % BHP RPM DDC % BHP RPM DDC % BHP RPM DDC % BHP
600 944 30 0.24 1015 36 0.30 1076 42 0.37 1139 40 0.46 1193 53 0.52
800 980 43
0.33 1049 48 0.43 1109 55 0.51 1169 56 0.63 1225 66 0.71
1000 1016 56 0.47 1082 61 0.60 1141 67 0.70 1200 71 0.87 1258 79 0.96
1200 1052 69 0.66 1116 74 0.84 1174 79 0.97 1231 87 1.20 1290 93 1.29
1400 1088 82 0.92 1150 87 1.19 1207 91 1.34 1261 102 1.65 1322 106 1.74
1500 1106 89 1.10 1167 93 1.40 1224 98 1.57 1277 110 1.93 1339 112 2.02
RPM DDC % BHP RPM DDC % BHP RPM DDC % BHP RPM DDC % BHP RPM DDC % BHP
RPM DDC % BHP RPM DDC % BHP RPM DDC % BHP RPM DDC % BHP RPM DDC % BHP
600 468 18 0.06 629 23 0.10 752 24 0.13 845 27 0.18 929 32 0.23
800 527 24 0.09 670 28 0.13 786 31 0.17 878 34 0.24 963 40 0.30
1000 585 29 0.12 711 33 0.17 821 38 0.23 912 42 0.31 997 47 0.40
1200 644 35 0.17 752 38 0.22 856 45 0.30 946 49 0.42 1031 55 0.53
1400 702 40 0.23 792 43 0.29 890 52 0.40 979 56 0.55 1065 62 0.70
1500 732 43 0.27 813 45 0.33 908 55 0.46 996 60 0.63 1082 66 0.80
RPM DDC % BHP RPM DDC % BHP RPM DDC % BHP RPM DDC % BHP RPM DDC % BHP
600 1006 31 0.25 1076 35 0.31 1141 41 0.39 1208 39 0.45 1264 46 0.55
800 1038 41 0.34 1109 46 0.42 1173 52 0.53 1238 53 0.60 1296 60 0.73
1000 1071 51 0.45 1141 58 0.57 1205 64 0.72 1268 67 0.79 1328 74 0.96
1200 1103 62 0.61 1174 70 0.76 1237 75 0.97 1297 81 1.05 1359 87 1.27
1400 1136 72 0.83 1206 81 1.03 1269 86 1.31 1327 95 1.39 1391 101 1.68
1500 1152 77 0.96 1222 87 1.20 1285 92 1.52 1341 102 1.60 1407 108 1.94
MODELS : DHG0363D,DHG0364D & DHG0367D WITH DDC CONTROLS
CFM
Shaded area indicates air flow below 900 SCFM (300 SCFM/ton) that is not recommended for High Stage cooling or heang.
Valid motor operang range for DDC% seng is 20 - 90.
CFM
Shaded area indicates air flow below 900 SCFM (300 SCFM/ton) that is not recommended for High Stage cooling or heang.
Valid motor operang range for DDC% seng is 20 - 90.
MODELS : DHG0363W,DHG0364W & DHG0367W WITH DDC CONTROL
CFM
CFM
Shaded area indicates air flow below 900 SCFM (300 SCFM/ton) that is not recommended for High Stage cooling or heang.
Valid motor operang range for DDC% seng is 20 - 90.
CFM
CFM
CFM
Shaded area indicates air flow below 900 SCFM (300 SCFM/ton) that is not recommended for High Stage cooling or heang.
Valid motor operang range for DDC% seng is 20 - 90.
