Daikin DHG - Page 75

75
APPENDIX A BLOWER PERFORMANCE DATA
RPM DDC % BHP RPM DDC % BHP RPM DDC % BHP RPM DDC % BHP RPM DDC % BHP
800 524 24 0.10 658 31 0.16 763 35 0.21 853 40 0.27 931 44 0.33
1000 588 32 0.15 708 38 0.21 807 42 0.28 892 47 0.35 968 50 0.41
1200 652 41 0.20 757 45 0.29 850 50 0.37 930 53 0.46 1005 57 0.53
1400 716 49 0.29 807 53 0.39 893 57 0.48 969 60 0.60 1043 63 0.67
1600 781 57 0.40 857 60 0.52 936 64 0.64 1008 67 0.77 1080 70 0.85
1800 845 65 0.57 906 68 0.71 979 71 0.85 1047 74 1.00 1117 76 1.08
2000 909 73 0.79 956 75 0.96 1023 78 1.12 1086 80 1.30 1154 83 1.38
RPM DDC % BHP RPM DDC % BHP RPM DDC % BHP RPM DDC % BHP RPM DDC % BHP
800 551 24 0.11 695 30 0.16 807 35 0.22 903 39 0.27 986 43 0.34
1000 618 32 0.16 747 37 0.21 853 42 0.29 943 46 0.35 1025 50 0.43
1200 685 40 0.22 798 45 0.27 898 49 0.39 983 53 0.44 1063 56 0.55
1400 752 48 0.31 850 52 0.36 943 56 0.51 1024 59 0.56 1102 62 0.70
1600 819 56 0.44 902 59 0.48 988 63 0.68 1064 66 0.71 1141 69 0.89
1800 885 64 0.61 954 67 0.63 1033 70 0.90 1105 72 0.90 1180 75 1.14
2000 952 72 0.86 1005 74 0.83 1078 76 1.19 1145 79 1.15 1218 81 1.44
RPM DDC % BHP RPM DDC % BHP RPM DDC % BHP RPM DDC % BHP RPM DDC % BHP
800 513 19 0.11 608 23 0.16 735 29 0.22 820 34 0.28 892 38 0.33
1000 565 28 0.15 658 32 0.21 775 38 0.27 856 43 0.35 926 46 0.40
1200 617 37 0.20 709 41 0.28 815 47 0.34 891 51 0.44 959 55 0.49
1400 669 46 0.26 760 50 0.36 856 55 0.42 926 59 0.55 993 64 0.60
1600 721 54 0.35 811 59 0.47 896 64 0.53 961 68 0.68 1026 72 0.73
1800 772 63 0.46 862 68 0.60 937 73 0.66 997 76 0.85 1059 81 0.90
2000 824 72 0.61 913 77 0.78 977 82 0.82 1032 85 1.06 1093 89 1.09
RPM DDC % BHP RPM DDC % BHP RPM DDC % BHP RPM DDC % BHP RPM DDC % BHP
800 975 43 0.38 1036 47 0.46 1099 51 0.50 1155 54 0.58 1213 57 0.65
1000 1005 51 0.45 1067 55 0.56 1128 59 0.60 1183 62 0.70 1238 65 0.76
1200 1035 60 0.54 1099 64 0.69 1157 67 0.72 1210 70 0.83 1263 74 0.89
1400 1065 68 0.65 1130 72 0.84 1186 76 0.86 1238 79 1.00 1287 82 1.05
1600 1095 76 0.78 1162 81 1.03 1215 84 1.03 1266 87 1.19 1312 90 1.23
1800 1125 85 0.93 1193 89 1.25 1244 92 1.23 1294 96 1.43 1337 99 1.44
2000 1155 93 1.11 1225 98 1.53 1273 101 1.47 1321 104 1.71 1362 107 1.70
RPM DDC % BHP RPM DDC % BHP RPM DDC % BHP RPM DDC % BHP RPM DDC % BHP
800 541 18 0.12 642 23 0.17 783 29 0.23 870 34 0.28 950 38 0.35
1000 595 27 0.16 695 32 0.22 823 38 0.29 907 42 0.34 983 46 0.42
1200 649 36 0.21 748 41 0.29 863 46 0.36 943 50 0.42 1016 54 0.51
1400 704 44 0.28 801 50 0.38 904 54 0.45 980 58 0.51 1049 62 0.63
1600 758 53 0.37 854 59 0.49 944 62 0.56 1017 67 0.62 1082 70 0.77
1800 812 62 0.49 907 69 0.63 984 70 0.70 1053 75 0.76 1115 78 0.94
2000 866 70 0.65 960 78 0.82 1024 79 0.87 1090 83 0.93 1148 86 1.15
RPM DDC % BHP RPM DDC % BHP RPM DDC % BHP RPM DDC % BHP RPM DDC % BHP
800 1026 40 0.40 1098 46 0.46 1167 50 0.53 1226 53 0.61 1288 56 0.69
1000 1059 49 0.49 1130 54 0.55 1197 58 0.63 1255 61 0.73 1314 64 0.81
1200 1092 57 0.60 1163 62 0.65 1227 66 0.76 1284 70 0.88 1340 73 0.95
1400 1125 66 0.73 1195 71 0.78 1258 74 0.91 1313 78 1.05 1366 81 1.12
1600 1158 75 0.89 1228 79 0.94 1288 83 1.09 1342 86 1.26 1392 89 1.31
1800 1192 83 1.09 1260 87 1.12 1318 91 1.30 1371 94 1.50 1418 97 1.54
2000 1225 92 1.33 1293 95 1.34 1348 99 1.56 1400 102 1.80 1443 106 1.81
4 TON
MODELS : DHG0483D,DHG0484D & DHG0487D WITH DDC CONTROLS
STANDARD STATIC
DOWN FLOW
CFM
0.2
0.4
0.6
0.8
1.0
Shaded area indicates air flow below 1200 SCFM (300 SCFM/ton) that is not recommended for High Stage cooling or heang.
Valid motor operang range for DDC% seng is 20 - 90.
HORIZONTAL FLOW
CFM
0.2
0.4
0.6
0.8
1.0
Shaded area indicates air flow below 1200 SCFM (300 SCFM/ton) that is not recommended for High Stage cooling or heang.
Valid motor operang range for DDC% seng is 20 - 90.
4 TON
MODELS : DHG0483W,DHG0484W & DHG0487W WITH DDC CONTROLS
HIGH STATIC
DOWN FLOW
CFM
0.2
0.4
0.6
0.8
1.0
CFM
1.2
1.4
1.6
1.8
2.0
Shaded area indicates air flow below 1200 SCFM (300 SCFM/ton) that is not recommended for High Stage cooling or heang.
Valid motor operang range for DDC% seng is 20 - 90.
HORIZONTAL FLOW
CFM
0.2
0.4
0.6
0.8
1.0
CFM
1.2
1.4
1.6
1.8
2.0
Shaded area indicates air flow below 1200 SCFM (300 SCFM/ton) that is not recommended for High Stage cooling or heang.
Valid motor operang range for DDC% seng is 20 - 90.
