Daikin DHG - Page 76

76
APPENDIX A BLOWER PERFORMANCE DATA
RPM DDC % BHP RPM DDC % BHP RPM DDC % BHP RPM DDC % BHP RPM DDC % BHP
900 466 30 0.11 609 34 0.16 721 38 0.22 770 42 0.27 905 45 0.35
1100 541 36 0.15 669 41 0.22 773 44 0.29 831 48 0.34 948 51 0.44
1300 615 43 0.21 730 47 0.30 825 50 0.38 892 53 0.43 990 56 0.56
1500 689 49 0.29 791 53 0.40 877 56 0.51 953 59 0.55 1033 61 0.71
1700 764 56 0.41 852 59 0.55 929 62 0.67 1013 64 0.69 1075 67 0.91
1900 838 62 0.58 913 65 0.74 981 68 0.89 1074 70 0.88 1118 72 1.15
2100 912 69 0.81 973 71 0.99 1033 73 1.18 1135 75 1.12 1160 77 1.47
2300 987 76 1.14 1034 78 1.34 1085 79 1.56 1196 81 1.43 1203 83 1.87
2500 1061 82 1.60 1095 84 1.81 1137 85 2.06 1257 86 1.81 1246 88 2.37
RPM DDC % BHP RPM DDC % BHP RPM DDC % BHP RPM DDC % BHP RPM DDC % BHP
900 488 29 0.11 641 34 0.16 761 38 0.21 870 42 0.28 958 45 0.37
1100 566 35 0.16 704 40 0.21 816 44 0.27 917 47 0.36 1002 50 0.47
1300 643 42 0.22 768 46 0.28 870 49 0.35 965 52 0.45 1046 55 0.59
1500 721 48 0.31 831 52 0.37 924 55 0.46 1012 58 0.58 1091 60 0.75
1700 799 55 0.44 894 58 0.49 978 61 0.59 1060 63 0.73 1135 66 0.96
1900 876 61 0.61 958 64 0.65 1032 66 0.77 1107 69 0.93 1179 71 1.22
2100 954 68 0.86 1021 70 0.85 1086 72 1.00 1155 74 1.19 1223 76 1.55
2300 1031 74 1.21 1084 76 1.13 1140 78 1.29 1202 80 1.51 1267 81 1.97
2500 1109 81 1.70 1148 82 1.50 1195 84 1.68 1250 85 1.92 1312 87 2.50
RPM DDC % BHP RPM DDC % BHP RPM DDC % BHP RPM DDC % BHP RPM DDC % BHP
900 502 17 0.12 631 21 0.19 722 26 0.23 806 27 0.28 895 29 0.33
1100 562 23 0.17 680 27 0.24 767 32 0.30 849 32 0.35 932 35 0.40
1300 622 29 0.22 729 32 0.31 813 37 0.39 892 37 0.44 969 41 0.49
1500 683 35 0.30 778 38 0.41 858 43 0.50 935 43 0.54 1006 46 0.60
1700 743 41 0.41 827 43 0.53 903 49 0.65 978 48 0.68 1043 52 0.73
1900 803 47 0.55 877 49 0.68 949 55 0.75 1021 53 0.84 1081 57 0.89
2100 864 53 0.75 926 54 0.88 994 61 1.01 1064 59 1.05 1118 63 1.08
2300 924 59 1.01 975 59 1.15 1040 67 1.22 1107 64 1.31 1155 69 1.32
2500 984 65 1.36 1024 65 1.49 1085 73 1.55 1150 69 1.63 1192 74 1.62
RPM DDC % BHP RPM DDC % BHP RPM DDC % BHP RPM DDC % BHP RPM DDC % BHP
900 967 32 0.41 1006 29 0.47 1075 32 0.54 1142 35 0.63 1197 37 0.69
1100 1001 37 0.50 1043 35 0.56 1109 38 0.65 1174 41 0.76 1228 44 0.83
1300 1035 43 0.61 1080 42 0.68 1143 45 0.78 1206 48 0.91 1259 50 1.00
1500 1069 48 0.75 1117 48 0.81 1177 51 0.93 1238 54 1.08 1290 56 1.19
1700 1103 54 0.92 1154 55 0.97 1211 57 1.12 1270 60 1.30 1321 62 1.43
1900 1137 59 1.12 1191 61 1.16 1245 64 1.34 1302 67 1.55 1352 69 1.71
2100 1170 65 1.27 1228 68 1.39 1279 70 1.60 1334 73 1.86 1383 75 2.05
2300 1204 70 1.57 1265 74 1.66 1313 77 1.92 1366 79 2.23 1414 81 2.40
2500 1238 76 1.84 1302 81 1.99 1348 83 2.29 1398 85 2.67 1445 87 2.93
RPM DDC % BHP RPM DDC % BHP RPM DDC % BHP RPM DDC % BHP RPM DDC % BHP
900 528 16 0.11 661 20 0.17 764 23 0.21 854 25 0.27 949 29 0.40
1100 591 22 0.15 715 26 0.22 811 28 0.27 899 31 0.33 987 34 0.48
1300 654 28 0.21 768 31 0.29 858 34 0.34 943 37 0.42 1026 40 0.57
1500 717 34 0.28 822 37 0.38 906 39 0.44 988 42 0.52 1065 45 0.68
1700 780 40 0.38 875 42 0.49 953 45 0.56 1033 48 0.65 1103 51 0.82
1900 842 46 0.51 929 48 0.63 1000 50 0.71 1078 54 0.80 1142 56 0.98
2100 905 51 0.69 982 54 0.82 1048 55 0.90 1122 60 1.00 1181 62 1.17
2300 968 57 0.93 1036 59 1.06 1095 61 1.14 1167 66 1.25 1219 67 1.40
2500 1031 63 1.25 1089 65 1.38 1142 66 1.45 1212 72 1.56 1258 73 1.68
RPM DDC % BHP RPM DDC % BHP RPM DDC % BHP RPM DDC % BHP RPM DDC % BHP
900 1046 31 0.40 1067 28 0.46 1140 31 0.54 1212 34 0.63 1270 37 0.64
1100 1081 37 0.48 1105 35 0.55 1176 37 0.65 1245 41 0.76 1302 43 0.78
1300 1116 42 0.59 1144 41 0.66 1211 44 0.77 1279 47 0.91 1335 49 0.96
1500 1152 47 0.72 1182 47 0.79 1247 50 0.93 1312 53 1.09 1367 55 1.11
1700 1187 53 0.88 1221 54 0.95 1282 56 1.11 1345 59 1.30 1400 61 1.34
1900 1222 58 1.08 1259 60 1.14 1318 63 1.33 1379 65 1.56 1432 67 1.59
2100 1258 64 1.32 1298 67 1.36 1354 69 1.59 1412 71 1.87 1464 73 1.94
2300 1293 69 1.61 1336 73 1.63 1389 75 1.90 1445 78 2.23 1497 80 2.30
2500 1328 75 1.97 1375 79 1.95 1425 82 2.28 1478 84 2.68 1529 86 2.32
Shaded area indicates air flow below 1500 SCFM (300 SCFM/ton) that is not recommended for High Stage cooling or heang.
HORIZONTAL FLOW
CFM
0.2
0.4
0.6
0.8
1.0
CFM
1.2
1.4
1.6
1.8
2.0
CFM
1.2
1.4
1.6
1.8
2.0
Shaded area indicates air flow below 1500 SCFM (300 SCFM/ton) that is not recommended for High Stage cooling or heang.
Valid motor operang range for DDC% seng is 20 - 90.
5 TON
MODELS : DHG0603W,DHG0604W & DHG0607W WITH DDC CONTROLS
HIGH STATIC
DOWN FLOW
CFM
0.2
0.4
0.6
0.8
1.0
5 TON
MODELS : DHG0603D,DHG0604D & DHG0607D WITH DDC CONTROLS
STANDARD STATIC
DOWN FLOW
CFM
0.2
0.4
0.6
0.8
1.0
Shaded area indicates air flow below 1500 SCFM (300 SCFM/ton) that is not recommended for High Stage cooling or heang.
Valid motor operang range for DDC% seng is 20 - 90.
HORIZONTAL FLOW
CFM
0.2
0.4
0.6
0.8
1.0
Shaded area indicates air flow below 1500 SCFM (300 SCFM/ton) that is not recommended for High Stage cooling or heang.
Valid motor operang range for DDC% seng is 20 - 90.
