Si041138 Removal of Fan Rotor
Removal Procedure 29
4
Unfasten the hook (a)
of the fan motor fixing
plate and unfasten the
hook (b).
Step Procedure Points
Hook (a)
Hook (b)
(R13211)
Fan motor fixing
plate (upper)
Fan
motor
fixing
plate
(lower)
Hook (b)
Hook (a)
Hook
(R4411)
