FTX-N/U, FVXS-N, FDMQ-R Series EDUS091558E
11
Model
Indoor Unit FVXS15NVJU
Outdoor Unit
RXL15QMVJUA
Cooling Heating
Power Supply
1 φ , 60 Hz, 208 - 230 V
Capacity Rated (Min. ~ Max.) kW 4.40 (1.70 ~ 5.00) 5.28 (1.70 ~ 7.00)
Btu/h 15,000 (5,800 ~ 17,100) 18,000 (5,800 ~ 24,000)
kcal/h 3,780 (1,460 ~ 4,300) 4,540 (1,460 ~ 6,020)
Moisture Removal gal/h 0.63 —
Running Current (Rated) A 6.06 - 5.48 7.00 - 6.33
Power Consumption Rated (Min. ~ Max.) W 1,200 (320 ~ 1,560) 1,400 (340 ~ 2,190)
Power Factor (Rated) % 95.2 - 95.2 96.2 - 96.2
COP Rated (Min. ~ Max.) W/W 3.66 (5.30 ~ 3.20) 3.76 (5.00 ~ 3.20)
EER Rated (Min. ~ Max.) Btu/h·W 12.5 (18.1 ~ 11.0) 12.9 (17.1 ~ 11.0)
SEER / HSPF 20.0 11.3
Piping
Connections
Liquid
in. (mm)
φ 1/4 (φ 6.4)
Gas
in. (mm)
φ 1/2 (φ 12.7)
Drain
in. (mm)
φ 13/16 (φ 20.0)
Heat Insulation Both Liquid and Gas Pipes
Max. Interunit Piping Length ft (m) 98-1/2 (30)
Max. Interunit Height Di󰀨erence ft (m) 65-5/8 (20)
Chargeless ft (m) 32-13/16 (10)
Amount of Additional Charge of
Refrigerant
oz/ft
(g/m)
0.21 (20)
Indoor Unit FVXS15NVJU
Front Panel Color White
Airow Rate H
cfm
(m³/min)
378 (10.7) 417 (11.8)
M 325 (9.2) 357 (10.1)
L 275 (7.8) 300 (8.5)
SL 233 (6.6) 251 (7.1)
Fan Type / Motor Output W Turbo Fan / 23.3
Speed Steps 5 Steps, Quiet, Auto
Air Direction Control Right, Left, Horizontal, Downward
Air Filter Removable, Washable, Mildew Proof
Running Current (Rated) A 0.19 - 0.17 0.21 - 0.19
Power Consumption (Rated) W 27 - 27 34 - 34
Power Factor (Rated) % 68.3 - 69.1 77.8 - 77.8
Temperature Control Microcomputer Control
Dimensions (H × W × D) in. (mm) 23-5/8 × 27-9/16 × 8-1/4 (600 × 700 × 210)
Packaged Dimensions (H × W × D) in. (mm) 27-3/8 × 30-15/16 × 11 (696 × 786 × 280)
Weight (Mass) Lbs (kg) 31 (14)
Gross Weight (Gross Mass) Lbs (kg) 40 (18)
Sound Pressure
Level
H / M / L / SL
dB(A) 44 / 40 / 36 / 32 45 / 40 / 36 / 32
Outdoor Unit RXL15QMVJUA
Casing Color Ivory White
Heat Exchanger Fin / Spec. Tube
Wa󰀪e Fin (PE) / φ 7 mm Hi-XSL Tube
Compressor Type Hermetically Sealed Swing Type
Model 2YC36PXD
Motor Output W 1,100
Refrigerant Oil Type FVC50K
Charge oz (L) 21.5 (0.650)
Refrigerant Type R-410A
Charge Lbs (kg) 3.20 (1.45)
Airow Rate H
cfm
(m³/min)
2,044 (57.9) 2,044 (57.9)
SL 1,762 (49.9) 1,585 (44.9)
Fan Type / Motor Output W Propeller / 71
Running Current (Rated) A 5.87 - 5.31 6.79 - 6.14
Power Consumption (Rated) W 1,173 - 1,173 1,366 - 1,366
Power Factor (Rated) % 96.1 - 96.0 96.7 - 96.7
Starting Current A 6.79
Dimensions (H × W × D) in. (mm) 28-15/16 × 34-1/4 × 12-5/8 (735 × 870 × 320)
Packaged Dimensions (H × W × D) in. (mm) 31-7/8 × 41-9/16 × 18-1/4 (810 × 1,056 × 464)
Weight (Mass) Lbs (kg) 108 (49)
Gross Weight (Gross Mass) Lbs (kg) 123 (56)
Sound Pressure Level H dB(A) 50 55
Conditions Based on Indoor ; 80°FDB (26.7°CDB) / 67°FWB (19.4°CWB)
Outdoor ; 95°FDB (35°CDB) / 75°FWB (24°CWB)
Piping Length: 25 ft (7.5 m)
Indoor ; 70°FDB (21°CDB) / 60°FWB (15.6°CWB)
Outdoor ; 47°FDB (8.3°CDB) / 43°FWB (6°CWB)
Piping Length: 25 ft (7.5 m)
Drawing No. C: 3D127170
Notes SL: The quiet fan level of the airow rate setting.
Conversion Formulae
kcal/h = kW × 860
Btu/h = kW × 3412
cfm = m3/min × 35.3
