Daikin FTX-N/U - 7 Capacity Tables

FTX-N/U, FVXS-N, FDMQ-R Series EDUS091558E
31
7. Capacity Tables
FTX09NMVJU + RXL09QMVJU
Cooling (60 Hz, 208 V)
AFR 11.8
BF 0.22
Temp: Celsius / TC, SHC, PI: kW
INDOOR OUTDOOR TEMPERATURE (°CDB)
EWB EDB 10 20 30 35 40 46
°C °C TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI
14.0 20.0 2.95 2.38 0.45 2.70 2.27 0.55 2.46 2.15 0.66 2.34 2.10 0.71 2.21 2.04 0.77 2.07 1.97 0.83
16.0 22.0 3.07 2.34 0.45 2.83 2.23 0.56 2.58 2.12 0.66 2.46 2.07 0.72 2.33 2.02 0.77 2.19 1.96 0.83
18.0 25.0 3.19 2.47 0.45 2.95 2.37 0.56 2.70 2.27 0.67 2.58 2.22 0.72 2.46 2.18 0.77 2.31 2.12 0.84
19.4 26.7 3.25 2.63 0.45 3.01 2.54 0.56 2.76 2.44 0.67 2.64 2.39 0.72 2.52 2.35 0.77 2.37 2.29 0.84
22.0 30.0 3.44 2.54 0.46 3.19 2.46 0.57 2.95 2.37 0.67 2.82 2.33 0.73 2.70 2.29 0.78 2.55 2.24 0.84
24.0 32.0 3.56 2.48 0.57 3.31 2.41 0.57 3.07 2.33 0.68 2.94 2.29 0.73 2.82 2.25 0.78 2.67 2.21 0.85
Temp: Fahrenheit / TC, SHC: kBtu/h / PI: kW
INDOOR OUTDOOR TEMPERATURE (°FDB)
EWB EDB 50 68 86 95 104 115
°F °F TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI
57.2 68.0 10.07 8.13 0.45 9.23 7.73 0.55 8.39 7.34 0.66 7.97 7.15 0.71 7.55 6.96 0.77 7.05 6.74 0.83
60.8 71.6 10.48 7.98 0.45 9.64 7.61 0.56 8.80 7.24 0.66 8.39 7.06 0.72 7.97 6.89 0.77 7.46 6.68 0.83
64.4 77.0 10.90 8.44 0.45 10.06 8.09 0.56 9.22 7.76 0.67 8.80 7.59 0.72 8.38 7.43 0.77 7.88 7.23 0.84
67.0 80.0 11.10 8.98 0.45 10.27 8.65 0.56 9.43 8.33 0.67 9.00 8.17 0.72 9.00 8.01 0.77 8.08 7.82 0.84
71.6 86.0 11.73 8.68 0.46 10.89 8.39 0.57 10.05 8.10 0.67 9.63 7.96 0.73 9.21 7.82 0.78 8.71 7.66 0.84
75.2 89.6 12.14 8.47 0.57 11.30 8.21 0.57 10.46 7.95 0.68 10.05 7.82 0.73 9.63 7.69 0.78 9.12 7.54 0.85
Heating (60 Hz, 208 V)
AFR 11.4
Temp: Celsius / TC, PI: kW
INDOOR OUTDOOR TEMPERATURE (°CWB)
EDB -25 -20 -15 -10 -5 0 6 15.5
°C TC PI TC PI TC PI TC PI TC PI TC PI TC PI TC PI
15.0 2.17 1.51 2.80 1.54 3.41 1.58 3.75 1.60 4.09 1.62 4.44 1.64 4.86 1.66 5.53 1.80
21.1 1.95 1.56 2.59 1.59 3.20 1.62 3.56 1.64 3.91 1.66 4.27 1.68 4.70 1.70 5.38 1.83
22.0 1.86 1.58 2.47 1.58 2.95 1.50 3.42 1.61 3.84 1.68 4.20 1.69 4.64 1.72 5.32 1.85
24.0 1.62 1.39 2.09 1.30 2.57 1.28 3.04 1.40 3.77 1.69 4.13 1.71 4.57 1.73 5.26 1.86
25.0 1.43 1.20 1.90 1.16 2.38 1.17 2.85 1.30 3.73 1.70 4.10 1.72 4.54 1.74 5.23 1.87
27.0 1.05 0.85 1.52 0.91 2.00 0.96 2.47 1.10 3.42 1.54 4.03 1.73 4.47 1.75 5.16 1.89
Temp: Fahrenheit / TC: kBtu/h / PI: kW
INDOOR OUTDOOR TEMPERATURE (°FWB)
EDB -13 -4 5 14 23 32 43 60
°F TC PI TC PI TC PI TC PI TC PI TC PI TC PI TC PI
59.0 7.40 1.51 9.55 1.54 11.62 1.58 12.77 1.60 13.94 1.62 15.12 1.64 16.55 1.66 18.83 1.80
70.0 6.63 1.56 8.81 1.59 10.90 1.62 12.11 1.64 13.33 1.66 14.54 1.68 16.00 1.70 18.31 1.83
71.6 6.33 1.58 8.43 1.58 10.05 1.50 11.68 1.61 13.08 1.68 14.31 1.69 15.78 1.72 18.10 1.85
75.2 5.51 1.39 7.14 1.30 8.76 1.28 10.38 1.40 12.84 1.69 14.08 1.71 15.56 1.73 17.89 1.86
77.0 4.87 1.20 6.49 1.16 8.11 1.17 9.73 1.30 12.72 1.70 13.96 1.72 15.45 1.74 17.79 1.87
80.6 3.57 0.85 5.19 0.91 6.81 0.96 8.43 1.10 11.68 1.54 13.73 1.73 15.23 1.75 17.58 1.89
