19
Engineering & Physical Data
Engineering Data - R22 MODEL (Cooling Only)
MODEL
INDOOR UNIT FT30FXV1
OUTDOOR UNIT R28CXV1 R30DXV1 R30DYV1
NOMINAL COOLING CAPACITY
Btu/h 27000 28000 28000
W 7913 8206 8206
NOMINAL TOTAL INPUT POWER (COOLING) W 2640 2570 2565
NOMINAL RUNNING CURRENT (COOLING) A 11.9 12.2 4.74
EER W/W 3.00 3.19 3.20
REFRIGERANT CONTROL (EXPANSION DEVICE) EXTERNAL ORIFICE
REFRIGERANT CHARGE kg 1.75 1.60 1.60
POWER SOURCE V/Ph/Hz 220-240 / 1 / 50 380-415 / 3 / 50
REFRIGERANT TYPE R22
INDOOR UNIT
CONTROL
AIR DISCHARGE AUTOMATIC LOUVER (UP & DOWN)
OPERATION WIRELESS OR WIRED REMOTE CONTROL
AIR FLOW
HIGH l/s / CFM 316 / 670
MEDIUM l/s / CFM 297 / 630
LOW l/s / CFM 260 / 550
SOUND PRESSURE LEVEL (H/M/L) dBA 49 / 47 / 45
UNIT DIMENSION HEIGHT X WIDTH X DEPTH mm 360 X 1200 X 200
PACKING DIMENSION HEIGHT X WIDTH X DEPTH mm 430 X 1267 X 271
UNIT WEIGHT kg 17
CONDENSATE DRAIN SIZE mm 20
FAN
TYPE CROSS FLOW FAN
DRIVE DIRECT
FAN MOTOR
TYPE INDUCTION
INDEX OF PROTECTION (IP) 20
INSULATION GRADE CLASS E
RATED INPUT POWER W 66
RATED RUNNING CURRENT A 0.29
MOTOR OUTPUT W 40
POLES 4
COIL
TUBE
MATERIAL COPPER
DIAMETER mm 9.52
FIN
MATERIAL ALUMINIUM
FACE AREA m
2
0.29
ROW 2
AIR QUALITY FILTER
TYPE SARANET
QUANTITY pc 3 X 3
CASING COLOUR LIGHT GREY
OUTDOOR UNIT
AIR FLOW l/s / CFM 741 / 1570 1605 / 3400 1605 / 3400
SOUND PRESSURE LEVEL dBA 54 58 58
UNIT DIMENSION HEIGHT X WIDTH X DEPTH mm 753 X 855 X 328 852 X 1030 X 400 852 X 1030 X 400
PACKING DIMENSION HEIGHT X WIDTH X DEPTH mm 793 X 990 X 415 1010 X 1180 X 514 1010 X 1180 X 514
UNIT WEIGHT kg 57 95 95
PIPE
CONNECTION
TYPE FLARE VALVE
SIZE
LIQUID mm 9.52
GAS mm 15.88
FAN
TYPE PROPELLER
DRIVE DIRECT
FAN MOTOR
TYPE INDUCTION
INDEX OF PROTECTION (IP) 23 54 54
INSULATION GRADE FBB
RATED INPUT POWER W 124 257 257
RATED RUNNING CURRENT A 0.54 1.10 1.10
MOTOR OUTPUT W 66 145 145
POLES 688
COMPRESSOR
TYPE ROTARY SCROLL
OIL TYPE
ATMOS NM56M /
SUNISO 4GDID
MINERAL
(Sontex 200LT)
MINERAL
(Sontex 200LT)
OIL AMOUNT cm
3
1130 1240 1240
RATED INPUT POWER (COOLING) W 2450 2247 2242
RATED RUNNING CURRENT (COOLING) A 11.1 10.8 3.35
LOCKED ROTOR AMP. A 62 82 82
COIL
TUBE
MATERIAL COPPER
DIAMETER mm 7.00 9.52 9.52
FIN
MATERIAL ALUMINIUM
FACE AREA m
2
0.62 0.87 0.87
ROW 222
CASING COLOUR LIGHT GREY
ALL UNITS ARE BEING TESTED AND COMPLY TO ISO 5151 (NON-DUCTED UNIT) OR ISO 13253 (DUCTED UNIT).
COOLING HEATING
INDOOR: 27°C DB / 19°C WB INDOOR: 20°C DB
OUTDOOR: 35°C DB / 24°C WB OUTDOOR: 7°C DB / 6°C WB
