Engineering & Physical Data
Engineering Data - R22 MODEL (Heatpump)
MODEL
INDOOR UNIT FTY09JXV1 FTY15JXV1 FTY20JXV1 FTY25JXV1
OUTDOOR UNIT RY09CXV1 RY15CXV1 RY20CXV1 RY25CXV1
NOMINAL COOLING CAPACITY
Btu/h 8400 11800 19500 24000
W 2462 3458 5720 7030
NOMINAL HEATING CAPACITY
Btu/h 9000 13000 19500 25000
W 2642 3810 5720 7330
NOMINAL TOTAL INPUT POWER (COOLING) W 925 1192 1850 2530
NOMINAL TOTAL INPUT POWER (HEATING) W 750 1064 1750 2465
NOMINAL RUNNING CURRENT (COOLING) A 4.07 5.45 8.21 11.3
NOMINAL RUNNING CURRENT (HEATING) A 3.32 4.90 7.73 11.0
EER W/W 2.66 2.90 3.09 2.78
COP W/W 3.52 3.58 3.27 2.97
REFRIGERANT CONTROL (EXPANSION DEVICE) OUTDOOR CAP TUBE
REFRIGERANT CHARGE kg 0.65 0.93 1.35 1.50
POWER SOURCE V/Ph/Hz 220-240 / 1 / 50
REFRIGERANT TYPE R22
INDOOR UNIT
CONTROL
AIR DISCHARGE AUTOMATIC LOUVER (UP & DOWN)
OPERATION WIRELESS OR WIRED REMOTE CONTROL
AIR FLOW
TURBO l/s / CFM 157 / 332 176 / 372 269 / 570 303 / 641
HIGH l/s / CFM 149 / 315 168 / 355 253 / 536 290 / 614
MEDIUM l/s / CFM 127 / 269 140 / 298 226 / 478 253 / 537
LOW l/s / CFM 106 / 225 114 / 242 200 / 424 224 / 474
QUIET l/s / CFM 99 / 209 106 / 225 177 / 375 197 / 418
SOUND PRESSURE LEVEL (T/H/M/L/Q) dBA 36 / 34 / 32 / 29 / 28 41 / 40 / 35 / 29 / 28 44 / 42 / 39 / 36 / 35 48 / 46 / 43 / 40 / 37
UNIT DIMENSION HEIGHT X WIDTH X DEPTH mm 288 X 800 X 206 310 X 1065 X 224 310 X 1065 X 224
PACKING DIMENSION HEIGHT X WIDTH X DEPTH mm 344 X 874 X 274 386 X 1136 X 314 386 X 1136 X 314
UNIT WEIGHT kg 91414
CONDENSATE DRAIN SIZE mm 19.05
FAN
TYPE CROSS FLOW FAN
DRIVE DIRECT
FAN MOTOR
TYPE INDUCTION
INDEX OF PROTECTION (IP) 20 44 44
INSULATION GRADE CLASS E
RATED INPUT POWER W 35 42 61 72
RATED RUNNING CURRENT A 0.19 0.21 0.30 0.34
MOTOR OUTPUT W 18 18 26 30
POLES 4
COIL
TUBE
MATERIAL COPPER
DIAMETER mm 7
FIN
MATERIAL ALUMINIUM
FACE AREA m
2
0.18 0.29
ROW 2
AIR QUALITY FILTER
TYPE SARANET
QUANTITY pc 2
CASING COLOUR WHITE
OUTDOOR UNIT
AIR FLOW l/s / CFM 320 / 680 453 / 960 614/ 1300 755 / 1600
SOUND PRESSURE LEVEL dBA 45 49 49 52
UNIT DIMENSION HEIGHT X WIDTH X DEPTH mm 494 X 600 X 245 540 x 700 x 250 651 X 855 X 328 753 X 855 X 328
PACKING DIMENSION HEIGHT X WIDTH X DEPTH mm 535 X 721 X 330 596 x 803 x 323 693 X 990 X 415 793 X 990 X 415
UNIT WEIGHT kg 26 30 47 57
PIPE
CONNECTION
TYPE FLARE VALVE
SIZE
LIQUID mm 6.35 6.35 6.35 9.52
GAS mm 9.52 12.70 15.88 15.88
FAN
TYPE PROPELLER
DRIVE DIRECT
FAN MOTOR
TYPE INDUCTION
INDEX OF PROTECTION (IP) 23 23 44 44
INSULATION GRADE BBFF
RATED INPUT POWER W 44 74 80 123
RATED RUNNING CURRENT A 0.20 0.33 0.36 0.54
MOTOR OUTPUT W 18 30 32 60
POLES 6
COMPRESSOR
TYPE ROTARY
OIL TYPE
SUNISO - 4GSI /
FREOLK56
ATMOS NM56M /
SUNISO 4GDID
ATMOS NM56M /
SUNISO 4GDID
ATMOS NM56M /
SUNISO 4GDID
OIL AMOUNT cm
3
330 350 670 700
RATED INPUT POWER (COOLING) W 846 1076 1709 2335
RATED INPUT POWER (HEATING) W 671 948 1609 2270
RATED RUNNING CURRENT (COOLING) A 3.68 4.91 7.55 10.4
RATED RUNNING CURRENT (HEATING) A 2.93 4.36 7.07 10.1
LOCKED ROTOR AMP. A 18 25 34 56
COIL
TUBE
MATERIAL COPPER
DIAMETER mm 7 9.52 7 7
FIN
MATERIAL ALUMINIUM
FACE AREA m
2
0.29 0.36 0.50 0.61
ROW 1122
CASING COLOUR LIGHT GREY
ALL UNITS ARE BEING TESTED AND COMPLY TO ISO 5151 (NON-DUCTED UNIT) OR ISO 13253 (DUCTED UNIT).
COOLING HEATING
INDOOR: 27°C DB / 19°C WB INDOOR: 20°C DB
OUTDOOR: 35°C DB / 24°C WB OUTDOOR: 7°C DB / 6°C WB
