Engineering & Physical Data
Engineering Data - R22 MODEL (Heatpump)
MODEL
INDOOR UNIT FTY30JXV1
OUTDOOR UNIT RY28CXV1 RY30DXV1
NOMINAL COOLING CAPACITY
Btu/h 27000 30000
W 7913 8790
NOMINAL HEATING CAPACITY
Btu/h 27000 30000
W 7913 8790
NOMINAL TOTAL INPUT POWER (COOLING) W 2650 2990
NOMINAL TOTAL INPUT POWER (HEATING) W 2600 2863
NOMINAL RUNNING CURRENT (COOLING) A 12.2 14.30
NOMINAL RUNNING CURRENT (HEATING) A 12.2 13.70
EER W/W 2.99 2.94
COP W/W 3.04 3.07
REFRIGERANT CONTROL (EXPANSION DEVICE) OUTDOOR CAP TUBE
REFRIGERANT CHARGE kg 1.83 2.15
POWER SOURCE V/Ph/Hz 220-240 / 1 / 50
REFRIGERANT TYPE R22
INDOOR UNIT
CONTROL
AIR DISCHARGE AUTOMATIC LOUVER (UP & DOWN)
OPERATION WIRELESS OR WIRED REMOTE CONTROL
AIR FLOW
HIGH l/s / CFM 316 / 670
MEDIUM l/s / CFM 297 / 630
LOW l/s / CFM 236 / 500
SOUND PRESSURE LEVEL (H/M/L) dBA 49 / 47 / 45
UNIT DIMENSION HEIGHT X WIDTH X DEPTH mm 360 X 1200 X 200
PACKING DIMENSION HEIGHT X WIDTH X DEPTH mm 430 X 1267 X 271
UNIT WEIGHT kg 17
CONDENSATE DRAIN SIZE mm 20
FAN
TYPE CROSS FLOW FAN
DRIVE DIRECT
FAN MOTOR
TYPE INDUCTION
INDEX OF PROTECTION (IP) 20
INSULATION GRADE CLASS E
RATED INPUT POWER W 66
RATED RUNNING CURRENT A 0.29
MOTOR OUTPUT W 40
POLES 4
COIL
TUBE
MATERIAL COPPER
DIAMETER mm 9.52
FIN
MATERIAL ALUMINIUM
FACE AREA m
2
0.29
ROW 2
AIR QUALITY FILTER
TYPE SARANET
QUANTITY pc 3 X 3
CASING COLOUR LIGHT GREY
OUTDOOR UNIT
AIR FLOW l/s / CFM 741 / 1570 1605 / 3400
SOUND PRESSURE LEVEL dBA 54 58
UNIT DIMENSION HEIGHT X WIDTH X DEPTH mm 753 X 855 X 328 852 X 1030 X 400
PACKING DIMENSION HEIGHT X WIDTH X DEPTH mm 793 X 990 X 415 1010 X 1180 X 514
UNIT WEIGHT kg 57 95
PIPE
CONNECTION
TYPE FLARE VALVE
SIZE
LIQUID mm 9.52 9.52
GAS mm 15.88 15.88
FAN
TYPE PROPELLER
DRIVE DIRECT
FAN MOTOR
TYPE INDUCTION
INDEX OF PROTECTION (IP) 23 44
INSULATION GRADE FB
RATED INPUT POWER W 124 257
RATED RUNNING CURRENT A 0.54 1.10
MOTOR OUTPUT W 66 145
POLES 68
COMPRESSOR
TYPE ROTARY SCROLL
OIL TYPE
ATMOS NM56M /
SUNISO 4GDID
MINERAL
(Sontex 200LT)
OIL AMOUNT cm
3
1130 1240
RATED INPUT POWER (COOLING) W 2460 2667
RATED INPUT POWER (HEATING) W 2410 2537
RATED RUNNING CURRENT (COOLING) A 11.4 12.8
RATED RUNNING CURRENT (HEATING) A 11.4 12.3
LOCKED ROTOR AMP. A 62 82
COIL
TUBE
MATERIAL COPPER
DIAMETER mm 7 9.52
FIN
MATERIAL ALUMINIUM
FACE AREA m
2
0.62 0.87
ROW 22
CASING COLOUR LIGHT GREY
ALL UNITS ARE BEING TESTED AND COMPLY TO ISO 5151 (NON-DUCTED UNIT) OR ISO 13253 (DUCTED UNIT).
COOLING HEATING
INDOOR: 27°C DB / 19°C WB INDOOR: 20°C DB
OUTDOOR: 35°C DB / 24°C WB OUTDOOR: 7°C DB / 6°C WB
