Performance Data
R22 Heatpump
Model: FTY09JXV1 - RY09CXV1
Cooling Mode
AFR
(CFM)
EWB EDB
Outdoor temperature
19°C 25°C 30°C 35°C 40°C 46°C
TC SC PI TC SC PI TC SC PI TC SC PI TC SC PI TC SC PI
225
16°C
21°C 2.32 1.80 0.70 2.24 1.75 0.76 2.16 1.70 0.82 2.07 1.65 0.89 1.90 1.54 0.97 1.75 1.45 1.07
24°C 2.32 2.15 0.70 2.24 2.10 0.76 2.16 2.05 0.82 2.07 2.00 0.89 1.90 1.87 0.97 1.76 1.76 1.07
27°C 2.34 2.34 0.70 2.26 2.26 0.76 2.18 2.18 0.83 2.10 2.10 0.90 1.94 1.94 0.97 1.81 1.81 1.07
30°C 2.41 2.41 0.71 2.35 2.35 0.77 2.27 2.27 0.83 2.20 2.20 0.90 2.04 2.04 0.98 1.91 1.91 1.08
19°C
24°C 2.56 1.68 0.71 2.47 1.63 0.77 2.38 1.59 0.84 2.29 1.55 0.91 2.10 1.44 0.99 1.94 1.36 1.09
27°C 2.56 1.92 0.71 2.47 1.88 0.77 2.38 1.83 0.84 2.29 1.79 0.91 2.10 1.67 0.99 1.94 1.58 1.09
30°C 2.57 2.37 0.71 2.48 2.32 0.77 2.39 2.27 0.84 2.30 2.21 0.91 2.12 2.07 0.99 1.96 1.96 1.09
33°C 2.60 2.60 0.72 2.51 2.51 0.78 2.43 2.43 0.84 2.35 2.35 0.91 2.17 2.17 0.99 2.03 2.03 1.10
22°C
27°C 2.82 1.64 0.73 2.72 1.60 0.79 2.62 1.56 0.85 2.52 1.52 0.93 2.32 1.42 1.01 2.14 1.33 1.11
30°C 2.82 2.00 0.73 2.72 1.96 0.79 2.62 1.91 0.85 2.52 1.87 0.93 2.32 1.75 1.01 2.14 1.66 1.11
33°C 2.82 2.34 0.73 2.72 2.29 0.79 2.62 2.25 0.85 2.52 2.20 0.93 2.32 2.07 1.01 2.15 1.96 1.11
36°C 2.83 2.65 0.73 2.73 2.60 0.79 2.64 2.54 0.86 2.54 2.49 0.93 2.35 2.33 1.01 2.18 2.18 1.11
269
16°C
21°C 2.42 1.87 0.71 2.33 1.83 0.77 2.24 1.78 0.83 2.15 1.73 0.90 1.97 1.61 0.98 1.82 1.51 1.08
24°C 2.42 2.27 0.71 2.34 2.22 0.77 2.25 2.17 0.83 2.16 2.11 0.90 1.98 1.97 0.98 1.83 1.83 1.08
27°C 2.45 2.45 0.71 2.37 2.37 0.77 2.29 2.29 0.83 2.21 2.21 0.91 2.04 2.04 0.98 1.90 1.90 1.08
30°C 2.55 2.55 0.72 2.48 2.48 0.78 2.40 2.40 0.84 2.33 2.33 0.91 2.16 2.16 0.99 2.01 2.01 1.10
19°C
24°C 2.66 1.77 0.72 2.57 1.73 0.78 2.47 1.68 0.85 2.37 1.64 0.92 2.18 1.53 0.99 2.01 1.44 1.10
27°C 2.67 2.04 0.72 2.57 2.00 0.78 2.47 1.95 0.85 2.38 1.91 0.92 2.18 1.78 1.00 2.02 1.69 1.10
30°C 2.68 2.52 0.72 2.59 2.46 0.78 2.49 2.41 0.85 2.40 2.35 0.92 2.21 2.20 1.00 2.05 2.05 1.10
33°C 2.72 2.72 0.72 2.64 2.64 0.79 2.56 2.56 0.85 2.47 2.47 0.92 2.29 2.29 1.00 2.14 2.14 1.11
22°C
27°C 2.92 1.74 0.73 2.82 1.69 0.80 2.72 1.65 0.86 2.61 1.61 0.94 2.40 1.50 1.01 2.22 1.41 1.12
30°C 2.93 2.13 0.73 2.82 2.09 0.80 2.72 2.04 0.86 2.61 1.99 0.94 2.40 1.87 1.01 2.22 1.77 1.12
33°C 2.93 2.50 0.73 2.83 2.45 0.80 2.73 2.40 0.86 2.62 2.35 0.94 2.41 2.20 1.02 2.23 2.09 1.12
36°C 2.95 2.82 0.74 2.86 2.77 0.80 2.76 2.71 0.87 2.66 2.65 0.94 2.45 2.45 1.02 2.28 2.28 1.12
315
16°C
21°C 2.50 1.96 0.72 2.41 1.91 0.77 2.32 1.86 0.84 2.22 1.80 0.91 2.04 1.68 0.98 1.88 1.58 1.09
24°C 2.52 2.38 0.72 2.43 2.32 0.77 2.34 2.26 0.84 2.24 2.20 0.91 2.06 2.06 0.99 1.90 1.90 1.09
27°C 2.56 2.56 0.72 2.47 2.47 0.78 2.39 2.39 0.84 2.31 2.31 0.91 2.13 2.13 0.99 1.99 1.99 1.10
30°C 2.69 2.69 0.72 2.61 2.61 0.78 2.53 2.53 0.85 2.44 2.44 0.92 2.26 2.26 1.00 2.11 2.11 1.11
19°C
24°C 2.76 1.88 0.73 2.66 1.83 0.79 2.56 1.78 0.85 2.45 1.73 0.92 2.25 1.62 1.00 2.08 1.52 1.10
27°C 2.76 2.17 0.73 2.67 2.12 0.79 2.57 2.07 0.85 2.46 2.02 0.93 2.26 1.89 1.00 2.09 1.79 1.11
30°C 2.79 2.67 0.73 2.69 2.61 0.79 2.59 2.55 0.86 2.49 2.49 0.93 2.30 2.30 1.01 2.13 2.13 1.11
33°C 2.85 2.85 0.73 2.76 2.76 0.79 2.68 2.68 0.86 2.59 2.59 0.94 2.40 2.40 1.02 2.25 2.25 1.12
22°C
27°C 3.03 1.83 0.74 2.92 1.79 0.80 2.81 1.75 0.87 2.69 1.70 0.94 2.48 1.59 1.02 2.29 1.50 1.13
30°C 3.03 2.26 0.74 2.92 2.22 0.80 2.81 2.17 0.87 2.70 2.12 0.94 2.48 1.99 1.02 2.29 1.88 1.13
33°C 3.04 2.65 0.74 2.94 2.60 0.80 2.83 2.55 0.87 2.72 2.49 0.95 2.50 2.34 1.03 2.32 2.22 1.13
36°C 3.07 2.99 0.74 2.97 2.94 0.81 2.87 2.87 0.87 2.77 2.77 0.95 2.56 2.56 1.03 2.38 2.38 1.14
Model: FTY09JXV1 - RY09CXV1
Heating Mode
ID DB
Outdoor WB
-9°C -6°C -5°C 6°C 12°C 15°C 18°C
TC (kW) SC (kW) TC (kW) SC (kW) TC (kW) SC (kW) TC (kW) SC (kW) TC (kW) SC (kW) TC (kW) SC (kW) TC (kW) SC (kW)
15°C 1.595 1.595 1.805 1.805 1.875 1.875 2.646 2.646 3.066 3.066 3.276 3.276 3.486 3.486
17°C 1.553 1.553 1.775 1.775 1.828 1.828 2.642 2.642 2.996 2.996 3.202 3.202 3.409 3.409
19°C 1.511 1.511 1.744 1.744 1.781 1.781 2.639 2.639 2.926 2.926 3.128 3.128 3.331 3.331
21°C 1.469 1.469 1.701 1.701 1.733 1.733 2.586 2.586 2.856 2.856 3.054 3.054 3.253 3.253
23°C 1.427 1.427 1.644 1.644 1.686 1.686 2.482 2.482 2.786 2.786 2.981 2.981 3.175 3.175
25°C 1.386 1.386 1.587 1.587 1.639 1.639 2.378 2.378 2.716 2.716 2.907 2.907 3.097 3.097
27°C 1.344 1.344 1.530 1.530 1.592 1.592 2.274 2.274 2.647 2.647 2.833 2.833 3.019 3.019
Frost Region
Remark:
AFR: Air fl ow rate (CFM)
EWB: Entering Wet Bulb Temp. (°C)
EDB: Entering Dry Bulb Temp. (°C)
TC: Total Cooling / Heating Capacity (kW)
SC: Sensible Cooling / Heating Capacity (kW)
PI: Power Input (kW)
Notes:
1. Ratings shown are net capacities.
2. shows nominal capacities.
3. Direct interpolation is permissible. Do not extrapolate.
4. Unit is able to operate at ambient from 19°C to 46°C DB (cooling) / -9°C to 18°C WB (heating) without pressure trip.
