46
Wiring Diagram
Heatpump
Indoor Unit
Model: FTY09/15JXV1
Outdoor Unit
Model: RY09/15CXV1
FM
NOTATION
FM : FAN MOTOR
AS : AIR SWING MOTOR
Z1C : FERRITE CORE
TH1 : INDOOR COIL THERMISTOR
TH2 : ROOM THERMISTOR
PART NO: 08 02 4 121387
AS
BLACK
CN_FAN
CN_ODCOIL
TH1
TH2
DISPLAY BOARD
GREEN/YELLOW
TO OUTDOOR
THERMISTOR
POWER
SUPPLY
L
N
E
CN_STP
CN_
FAN FB
N
L
COMP
ODFAN
CN_DISP.
BLACK
BROWN
BLUE
RED
BLUE
4WV OF
COMP
N1 N L
Z1C
N=4
PURPLE
CN_IDCOIL
4WV
WHITE
BROWN
BLACK (LIVE)
RED (FAN CAP)
WHITE (NEUTRAL)
BLACK
TH2
BLACK
C
S
R
CM
4WV
4WV
OF COMP N
FM
CAPACITOR
CAPACITOR
GREEN/YELLOW
BLUE
BLUE
BLUE
KEY:
CM - COMPRESSOR MOTOR
FM - FAN MOTOR
4WV - 4 WAY VALVE
TH2 - OUTDOOR THERMISTOR
FIELD SUPPLY WIRING
PART NO. : 08 02 4 059666A
OLP - OVERLOAD PROTECTOR
BLUE
RED
BLACK
BLACK
BLACK
RED
WHITEWHITE
OLP
DAIKIN_FT(Y).indb 46DAIKIN_FT(Y).indb 46 10/15/2012 4:27:17 PM10/15/2012 4:27:17 PM
