Engineering & Physical Data
Engineering & Physical Data
Engineering Data - R22 MODEL (Cooling Only)
MODEL
INDOOR UNIT FT10JXV1 FT15JXV1 FT20JXV1 FT25JXV1
OUTDOOR UNIT R09CXV1 R15CXV1 R18CXV1 R25CXV1
NOMINAL COOLING CAPACITY
Btu/h 10000 11800 18000 24000
W 2930 3458 5280 7030
NOMINAL TOTAL INPUT POWER (COOLING) W 980 1192 1630 2530
NOMINAL RUNNING CURRENT (COOLING) A 4.38 5.45 7.16 11.3
EER W/W 2.99 2.90 3.24 2.78
REFRIGERANT CONTROL (EXPANSION DEVICE) OUTDOOR CAP TUBE
REFRIGERANT CHARGE kg 0.60 0.75 0.90 1.50
POWER SOURCE V/Ph/Hz 220-240 / 1 / 50
REFRIGERANT TYPE R22
INDOOR UNIT
CONTROL
AIR DISCHARGE AUTOMATIC LOUVER (UP & DOWN)
OPERATION WIRELESS OR WIRED REMOTE CONTROL
AIR FLOW
TURBO l/s / CFM 169 / 358 176 / 372 280 / 594 303 / 641
HIGH l/s / CFM 161 / 342 168 / 355 251 / 531 290 / 614
MEDIUM l/s / CFM 133 / 282 140 / 298 224 / 474 253 / 537
LOW l/s / CFM 106 / 225 114 / 242 199 / 422 224 / 474
QUIET l/s / CFM 99 / 209 106 / 225 180 / 381 197 / 418
SOUND PRESSURE LEVEL (T/H/M/L/Q) dBA 39 / 38 / 32 / 27 / 25 41 / 40 / 35 / 29 / 28 44 / 42 / 39 / 36 / 35 48 / 46 / 43 / 40 / 37
UNIT DIMENSION HEIGHT X WIDTH X DEPTH mm 288 X 800 X 206 310 X 1065 X 224
PACKING DIMENSION HEIGHT X WIDTH X DEPTH mm 344 X 874 X 274 386 X 1136 X 314
UNIT WEIGHT kg 914
CONDENSATE DRAIN SIZE mm 19.05
FAN
TYPE CROSS FLOW FAN
DRIVE DIRECT
FAN MOTOR
TYPE INDUCTION
INDEX OF PROTECTION (IP) 20 20 44 44
INSULATION GRADE CLASS E
RATED INPUT POWER W 37 42 61 72
RATED RUNNING CURRENT A 0.19 0.21 0.30 0.34
MOTOR OUTPUT W 18 18 26 30
POLES 4
COIL
TUBE
MATERIAL COPPER
DIAMETER mm 7
FIN
MATERIAL ALUMINIUM
FACE AREA m
2
0.18 0.29
ROW 2
AIR QUALITY FILTER
TYPE SARANET
QUANTITY pc 2
CASING COLOUR WHITE
OUTDOOR UNIT
AIR FLOW l/s / CFM 320 / 680 453 / 960 614 / 1300 755 / 1600
SOUND PRESSURE LEVEL dBA 45 49 52 52
UNIT DIMENSION HEIGHT X WIDTH X DEPTH mm 494 X 600 X 245 540 x 700 x 250 651 X 855 X 328 753 X 855 X 328
PACKING DIMENSION HEIGHT X WIDTH X DEPTH mm 535 X 721 X 330 596 x 803 x 323 693 X 990 X 415 793 X 990 X 415
UNIT WEIGHT kg 25 29 43 57
PIPE
CONNECTION
TYPE FLARE VALVE
SIZE
LIQUID mm 6.35 6.35 6.35 9.52
GAS mm 9.52 12.70 15.88 15.88
FAN
TYPE PROPELLER
DRIVE DIRECT
FAN MOTOR
TYPE INDUCTION
INDEX OF PROTECTION (IP) 23 24 23
INSULATION GRADE BBBF
RATED INPUT POWER W 44 70 77 123
RATED RUNNING CURRENT A 0.20 0.31 0.34 0.54
MOTOR OUTPUT W 18 30 43 60
POLES 6
COMPRESSOR
TYPE ROTARY
OIL TYPE
SUNISO - 4GSI /
FREOLK56J
ATMOS NM56M /
SUNISO 4GDID
ATMOS NM56M /
SUNISO 4GDID
ATMOS NM56M /
SUNISO 4GDID
OIL AMOUNT cm
3
330 350 670 700
RATED INPUT POWER (COOLING) W 899 1080 1492 2335
RATED RUNNING CURRENT (COOLING) A 3.99 4.93 6.52 10.4
LOCKED ROTOR AMP. A 18 25 34 56
COIL
TUBE
MATERIAL COPPER
DIAMETER mm 7.00 7.00 7.00 7.00
FIN
MATERIAL ALUMINIUM
FACE AREA m
2
0.29 0.36 0.52 0.62
ROW 1112
CASING COLOUR LIGHT GREY
ALL UNITS ARE BEING TESTED AND COMPLY TO ISO 5151 (NON-DUCTED UNIT) OR ISO 13253 (DUCTED UNIT).
COOLING HEATING
INDOOR: 27°C DB / 19°C WB INDOOR: 20°C DB
OUTDOOR: 35°C DB / 24°C WB OUTDOOR: 7°C DB / 6°C WB
DAIKIN_FT(Y).indb 18DAIKIN_FT(Y).indb 18 10/15/2012 4:27:11 PM10/15/2012 4:27:11 PM
