26
Performance Data
Model: FT20JXV1- R18CXV1
Cooling Mode
AFR
(CFM)
EWB EDB
Outdoor temperature
19°C 25°C 30°C 35°C 40°C 46°C
TC SC PI TC SC PI TC SC PI TC SC PI TC SC PI TC SC PI
422
16°C
21°C 4.98 3.43 1.24 4.80 3.34 1.34 4.62 3.25 1.45 4.44 3.15 1.57 4.08 2.93 1.71 3.76 2.76 1.88
24°C 4.99 4.10 1.24 4.81 4.01 1.34 4.63 3.91 1.45 4.45 3.82 1.57 4.08 3.57 1.71 3.78 3.36 1.88
27°C 5.02 4.65 1.24 4.86 4.54 1.34 4.69 4.44 1.45 4.51 4.32 1.58 4.16 4.02 1.71 3.87 3.78 1.89
30°C 5.18 5.18 1.25 5.03 5.03 1.35 4.88 4.88 1.46 4.72 4.72 1.59 4.38 4.38 1.73 4.09 4.09 1.91
19°C
24°C 5.49 3.20 1.26 5.30 3.12 1.36 5.10 3.03 1.48 4.90 2.95 1.60 4.51 2.75 1.74 4.17 2.59 1.91
27°C 5.50 3.66 1.26 5.30 3.58 1.36 5.11 3.49 1.48 4.91 3.41 1.60 4.51 3.19 1.74 4.17 3.02 1.91
30°C 5.50 4.52 1.26 5.31 4.42 1.36 5.13 4.32 1.48 4.93 4.22 1.60 4.54 3.94 1.74 4.21 3.73 1.92
33°C 5.57 5.57 1.26 5.39 5.39 1.37 5.21 5.21 1.48 5.04 5.04 1.61 4.66 4.66 1.75 4.36 4.36 1.93
22°C
27°C 6.04 3.13 1.28 5.83 3.05 1.39 5.62 2.98 1.50 5.40 2.90 1.63 4.97 2.70 1.77 4.60 2.54 1.95
30°C 6.04 3.81 1.28 5.84 3.73 1.39 5.62 3.65 1.50 5.40 3.56 1.63 4.97 3.33 1.77 4.60 3.16 1.95
33°C 6.05 4.45 1.28 5.84 4.37 1.39 5.63 4.28 1.50 5.41 4.19 1.63 4.97 3.94 1.77 4.61 3.74 1.95
36°C 6.07 5.05 1.28 5.87 4.95 1.39 5.66 4.85 1.51 5.46 4.74 1.64 5.03 4.44 1.77 4.68 4.22 1.96
474
16°C
21°C 5.18 3.57 1.25 4.99 3.48 1.35 4.80 3.39 1.46 4.61 3.29 1.59 4.23 3.07 1.72 3.90 2.88 1.90
24°C 5.20 4.34 1.25 5.01 4.23 1.35 4.82 4.13 1.46 4.63 4.03 1.59 4.25 3.76 1.72 3.93 3.55 1.90
27°C 5.26 4.92 1.25 5.08 4.81 1.36 4.91 4.69 1.47 4.73 4.55 1.59 4.37 4.22 1.73 4.07 3.95 1.91
30°C 5.48 5.48 1.26 5.32 5.32 1.37 5.16 5.16 1.48 4.99 4.99 1.61 4.62 4.62 1.75 4.32 4.32 1.93
19°C
24°C 5.71 3.38 1.27 5.50 3.29 1.37 5.30 3.21 1.49 5.08 3.12 1.61 4.67 2.91 1.75 4.31 2.74 1.93
27°C 5.72 3.89 1.27 5.51 3.81 1.37 5.31 3.72 1.49 5.09 3.63 1.62 4.68 3.40 1.75 4.33 3.21 1.93
30°C 5.74 4.80 1.27 5.54 4.70 1.38 5.35 4.59 1.49 5.14 4.48 1.62 4.73 4.19 1.76 4.39 3.96 1.94
33°C 5.84 5.84 1.28 5.66 5.66 1.38 5.48 5.48 1.50 5.30 5.30 1.63 4.91 4.91 1.77 4.59 4.59 1.95
22°C
27°C 6.27 3.31 1.29 6.05 3.23 1.40 5.82 3.15 1.52 5.59 3.06 1.65 5.14 2.86 1.79 4.75 2.70 1.97
30°C 6.28 4.06 1.29 6.06 3.98 1.40 5.83 3.89 1.52 5.60 3.80 1.65 5.15 3.56 1.79 4.76 3.37 1.97
33°C 6.29 4.76 1.29 6.07 4.67 1.40 5.85 4.57 1.52 5.62 4.47 1.65 5.17 4.20 1.79 4.79 3.98 1.97
36°C 6.33 5.38 1.30 6.12 5.28 1.41 5.91 5.17 1.52 5.69 5.05 1.65 5.25 4.72 1.79 4.90 4.45 1.98
531
16°C
21°C 5.37 3.73 1.26 5.17 3.63 1.36 4.98 3.54 1.47 4.77 3.44 1.60 4.37 3.20 1.73 4.03 3.01 1.91
24°C 5.40 4.53 1.26 5.20 4.42 1.36 5.01 4.31 1.48 4.81 4.20 1.60 4.41 3.92 1.74 4.08 3.70 1.91
27°C 5.49 5.19 1.26 5.31 5.06 1.37 5.13 4.91 1.48 4.94 4.76 1.61 4.57 4.41 1.75 4.26 4.12 1.93
30°C 5.76 5.76 1.28 5.59 5.59 1.38 5.42 5.42 1.50 5.24 5.24 1.63 4.85 4.85 1.77 4.53 4.53 1.95
19°C
24°C 5.91 3.57 1.28 5.70 3.49 1.39 5.48 3.40 1.50 5.26 3.30 1.63 4.83 3.08 1.77 4.46 2.91 1.94
27°C 5.93 4.14 1.28 5.72 4.04 1.39 5.50 3.95 1.50 5.28 3.85 1.63 4.85 3.60 1.77 4.48 3.41 1.95
30°C 5.98 5.09 1.28 5.77 4.98 1.39 5.56 4.86 1.51 5.35 4.74 1.63 4.92 4.43 1.77 4.57 4.18 1.95
33°C 6.11 6.11 1.29 5.93 5.93 1.40 5.75 5.75 1.52 5.56 5.56 1.65 5.15 5.15 1.79 4.81 4.81 1.98
22°C
27°C 6.49 3.50 1.30 6.26 3.42 1.41 6.02 3.33 1.53 5.78 3.25 1.66 5.31 3.03 1.80 4.91 2.86 1.98
30°C 6.50 4.31 1.31 6.27 4.23 1.41 6.03 4.14 1.53 5.79 4.04 1.66 5.32 3.79 1.80 4.92 3.59 1.98
33°C 6.52 5.05 1.31 6.30 4.96 1.42 6.07 4.86 1.53 5.83 4.75 1.66 5.36 4.45 1.81 4.97 4.23 1.99
36°C 6.58 5.70 1.31 6.38 5.60 1.42 6.16 5.48 1.54 5.93 5.34 1.67 5.48 4.98 1.81 5.11 4.69 2.00
Remark:
AFR: Air fl ow rate (CFM)
EWB: Entering Wet Bulb Temp. (°C)
EDB: Entering Dry Bulb Temp. (°C)
TC: Total Cooling Capacity (kW)
SC: Sensible Cooling Capacity (kW)
PI: Power Input (kW)
Notes:
1. Ratings shown are net capacities.
2.
shows nominal capacities.
3. Direct interpolation is permissible. Do not extrapolate.
4. Unit is able to operate at ambient from 19°C to 46°C DB without pressure trip.
