Performance Data
Model: FTY30FXV1 - RY28CXV1
Cooling Mode
AFR
(CFM)
EWB EDB
Outdoor temperature
19°C 25°C 30°C 35°C 40°C 46°C
TC SC PI TC SC PI TC SC PI TC SC PI TC SC PI TC SC PI
500
16°C
21°C 7.46 4.93 2.01 7.20 4.80 2.17 6.93 4.67 2.36 6.65 4.54 2.55 6.11 4.22 2.77 5.64 3.97 3.05
24°C 7.47 5.90 2.01 7.21 5.77 2.18 6.94 5.63 2.36 6.66 5.49 2.55 6.12 5.13 2.77 5.66 4.84 3.06
27°C 7.53 6.69 2.01 7.28 6.54 2.18 7.02 6.38 2.36 6.76 6.22 2.56 6.24 5.79 2.78 5.80 5.44 3.07
30°C 7.76 7.76 2.02 7.54 7.54 2.19 7.31 7.31 2.38 7.08 7.08 2.58 6.56 6.56 2.80 6.14 6.14 3.10
19°C
24°C 8.23 4.60 2.04 7.94 4.48 2.21 7.65 4.36 2.40 7.35 4.24 2.60 6.75 3.95 2.82 6.24 3.72 3.11
27°C 8.24 5.26 2.04 7.95 5.15 2.21 7.65 5.03 2.40 7.35 4.91 2.60 6.76 4.59 2.82 6.25 4.35 3.11
30°C 8.25 6.50 2.04 7.96 6.36 2.21 7.68 6.22 2.40 7.39 6.07 2.60 6.80 5.67 2.82 6.31 5.37 3.11
33°C 8.35 8.35 2.05 8.07 8.07 2.22 7.81 7.81 2.41 7.55 7.55 2.61 6.98 6.98 2.84 6.53 6.53 3.13
22°C
27°C 9.05 4.50 2.08 8.74 4.39 2.25 8.42 4.28 2.44 8.09 4.17 2.65 7.44 3.88 2.87 6.89 3.66 3.17
30°C 9.06 5.49 2.08 8.74 5.37 2.25 8.42 5.25 2.44 8.09 5.12 2.65 7.44 4.80 2.87 6.89 4.55 3.17
33°C 9.06 6.41 2.08 8.75 6.29 2.25 8.43 6.16 2.44 8.10 6.04 2.65 7.45 5.67 2.88 6.91 5.38 3.17
36°C 9.09 7.27 2.08 8.79 7.12 2.26 8.49 6.97 2.45 8.18 6.82 2.66 7.54 6.39 2.88 7.01 6.07 3.18
630
16°C
21°C 7.76 5.14 2.03 7.48 5.01 2.19 7.20 4.87 2.38 6.91 4.74 2.58 6.34 4.41 2.79 5.85 4.15 3.08
24°C 7.79 6.24 2.03 7.51 6.09 2.20 7.23 5.95 2.38 6.93 5.80 2.58 6.37 5.41 2.80 5.89 5.11 3.08
27°C 7.88 7.09 2.03 7.62 6.92 2.20 7.35 6.74 2.39 7.09 6.54 2.59 6.55 6.08 2.81 6.10 5.68 3.10
30°C 8.21 8.21 2.05 7.97 7.97 2.22 7.73 7.73 2.41 7.48 7.48 2.61 6.93 6.93 2.84 6.48 6.48 3.13
19°C
24°C 8.55 4.86 2.06 8.25 4.74 2.23 7.94 4.62 2.42 7.62 4.49 2.62 7.00 4.18 2.84 6.46 3.94 3.13
27°C 8.57 5.60 2.06 8.26 5.48 2.23 7.95 5.35 2.42 7.63 5.23 2.62 7.01 4.89 2.85 6.48 4.63 3.14
30°C 8.61 6.91 2.07 8.31 6.76 2.24 8.01 6.61 2.42 7.71 6.45 2.63 7.10 6.03 2.85 6.58 5.70 3.14
33°C 8.75 8.75 2.07 8.49 8.49 2.25 8.22 8.22 2.44 7.94 7.94 2.64 7.36 7.36 2.87 6.88 6.88 3.17
22°C
27°C 9.40 4.76 2.10 9.07 4.65 2.28 8.73 4.53 2.47 8.38 4.41 2.67 7.70 4.11 2.90 7.13 3.88 3.19
30°C 9.41 5.84 2.10 9.08 5.72 2.28 8.74 5.59 2.47 8.39 5.46 2.68 7.71 5.12 2.90 7.14 4.86 3.20
33°C 9.43 6.85 2.10 9.10 6.72 2.28 8.77 6.58 2.47 8.42 6.44 2.68 7.75 6.04 2.90 7.18 5.73 3.20
36°C 9.48 7.74 2.11 9.18 7.59 2.28 8.86 7.44 2.47 8.54 7.26 2.69 7.88 6.80 2.91 7.34 6.41 3.22
660
16°C
21°C 8.05 5.36 2.05 7.76 5.23 2.21 7.46 5.09 2.40 7.15 4.95 2.60 6.56 4.61 2.82 6.04 4.34 3.10
24°C 8.09 6.52 2.05 7.80 6.36 2.21 7.51 6.21 2.40 7.20 6.04 2.60 6.61 5.64 2.82 6.11 5.32 3.11
27°C 8.22 7.47 2.05 7.95 7.27 2.22 7.69 7.07 2.41 7.41 6.85 2.61 6.85 6.35 2.84 6.38 5.93 3.13
30°C 8.63 8.63 2.07 8.38 8.38 2.24 8.12 8.12 2.43 7.86 7.86 2.64 7.27 7.27 2.87 6.79 6.79 3.17
19°C
24°C 8.86 5.14 2.08 8.54 5.02 2.25 8.22 4.89 2.44 7.88 4.76 2.64 7.23 4.43 2.87 6.68 4.18 3.16
27°C 8.89 5.95 2.08 8.57 5.82 2.25 8.25 5.68 2.44 7.91 5.54 2.65 7.27 5.18 2.87 6.71 4.90 3.16
30°C 8.96 7.32 2.08 8.64 7.16 2.26 8.33 7.00 2.45 8.01 6.82 2.65 7.38 6.37 2.88 6.85 6.01 3.17
33°C 9.15 9.15 2.09 8.89 8.89 2.27 8.61 8.61 2.46 8.33 8.33 2.67 7.72 7.72 2.91 7.22 7.22 3.21
22°C
27°C 9.72 5.03 2.12 9.38 4.92 2.29 9.02 4.80 2.49 8.66 4.67 2.70 7.96 4.36 2.92 7.35 4.12 3.22
30°C 9.74 6.20 2.12 9.40 6.09 2.30 9.04 5.95 2.49 8.68 5.82 2.70 7.97 5.45 2.93 7.38 5.16 3.22
33°C 9.78 7.27 2.12 9.44 7.14 2.30 9.09 6.99 2.49 8.73 6.84 2.70 8.04 6.41 2.93 7.44 6.08 3.23
36°C 9.86 8.21 2.13 9.55 8.06 2.31 9.22 7.88 2.50 8.89 7.69 2.71 8.22 7.17 2.95 7.66 6.75 3.25
Model: FTY30FXV1 - RY28CXV1
Heating Mode
ID DB
Outdoor WB
-9°C -6°C -5°C 6°C 12°C 15°C 18°C
TC (kW) SC (kW) TC (kW) SC (kW) TC (kW) SC (kW) TC (kW) SC (kW) TC (kW) SC (kW) TC (kW) SC (kW) TC (kW) SC (kW)
15°C 3.527 3.527 4.422 4.422 4.720 4.720 8.000 8.000 9.790 9.790 10.684 10.684 11.579 11.579
17°C 3.437 3.437 4.332 4.332 4.630 4.630 7.939 7.939 9.523 9.523 10.386 10.386 11.250 11.250
19°C 3.347 3.347 4.241 4.241 4.540 4.540 7.877 7.877 9.256 9.256 10.088 10.088 10.920 10.920
21°C 3.256 3.256 4.151 4.151 4.449 4.449 7.816 7.816 8.989 8.989 9.790 9.790 10.591 10.591
23°C 3.252 3.252 4.082 4.082 4.359 4.359 7.461 7.461 8.722 8.722 9.492 9.492 10.262 10.262
25°C 3.247 3.247 7.014 7.014 4.269 4.269 7.105 7.105 8.455 8.455 9.194 9.194 9.932 9.932
27°C 3.242 3.242 3.945 3.945 4.179 4.179 6.750 6.750 8.188 8.188 8.896 8.896 9.603 9.603
Frost Region
Remark:
AFR: Air fl ow rate (CFM)
EWB: Entering Wet Bulb Temp. (°C)
EDB: Entering Dry Bulb Temp. (°C)
TC: Total Cooling / Heating Capacity (kW)
SC: Sensible Cooling / Heating Capacity (kW)
PI: Power Input (kW)
Notes:
1. Ratings shown are net capacities.
2. shows nominal capacities.
3. Direct interpolation is permissible. Do not extrapolate.
4. Unit is able to operate at ambient from 19°C to 46°C DB (cooling) / -9°C to 18°C WB (heating) without pressure trip.
