Figure 6 continued: Commission Unit – Keypad/Display Menu Structure
See page 56
Evap Cond Set-Up
Cond Fan Spd= XXX%
CFan Spd Cmd= XXX%
Min Fan Speed= 33%
EvCond Stg Tm= 10min
Sump Temp= XXX°F
Min Sump T= 75.0°F
Max Sump T= 85.0°F
Sump Dump Spt= 35.0°F
Cndtvy= XXXS/CM
Hi Cndtvy Spt= XXXS/CM
SmpWtrLvDly= 5min
PostClgTime= 10min
SepFlshtime= 1min
Dolphin Sys= No
OA Fan Set-Up
OA FAN STATUS
OA Fan1 Spd= XXX%
OA Fan1 Cmd= XXX%
OA Fan1Amps= XX.XA
Fault Code Details
►
OA Fan2 Spd= XXX%
OA Fan2 Cmd= XXX%
OA Fan2Amps= XX.XA
Fault Code Details
►
REFRIG CIRCUIT STATUS
PTS= XXX.Xpsi
PTD= XXX.Xpsi
Disch Sat Tmp= XXX.X°F
EffDshSatTSpt= XXX.X°F
OA Temp= XXX°F
INV Fin Temp= XXX°F
OA FAN SET UP
DischSatTDiff= 15°F
DischSatTDB= 2.0°F
OA Fan Period= 25s
OA Fan Gain= 2.5
OA Fan PAT= 75s
OA Fan Max= 90%
IFB COMM STATUS
►
1
1
2
See page 33 – 58
Commission Unit
Unit Set-Up
►
Timer Settings
►
SAF Set-Up
►
RF/EF Set-Up
►
Htg/Clg ChgOvr Set-Up
►
Cooling Set-Up
►
Cooling Set-Up (2)
►
INV Cmp Set-Up
►
Var Cmp Set-Up
►
Econo Set-Up
►
Min OA Set-Up
►
Heating Set-Up
►
OA Fan Set-Up
►
Exp Valve Set-Up
►
Defrost Set-Up
►
Dehum Set-Up
►
Energy Rec Set-Up
►
Head Pressure Set-Up
►
Evap Cond Set-Up
►
D3 Set-Up
►
Alarm Conguration
►
See page 57
Alarm Conguration
ALARM LIMITS
Hi Disch Temp= 170°F
Lo Disch Temp= 40°F
Hi Return Temp= 120°F
ALARM OUT CONFIG
Faults= Fast
Problems= Slow
Warnings= Off
ALARM DELAYS
Frz Delay Time= 30s
LP Delay= 2s
LP Comp Delay=
5s (410A)
65s (R22)
Air Flw Ing=120s
Sens Alm Dly= 30s
Temp AlmDly= 30s
ALARM CONFIG
Emerg Stop= ManClr
Exp Valve Set-Up
EXP VALVE STATUS EXP VALVE SETUP
EVI Pos= XXX% SSH DB= 2.0ºF
EVO Pos= XXX%
SH Lo Base=
6.0ºF/5.0ºF/2.0ºF
(15THP/3–12THP/ClgOnly)
EVStatus=____________
REFRIG CIRCUIT STATUS
PTS= XXX.Xpsi SH Hi Base= 9.0ºF
PTD= XXX.Xpsi Htg EVI Meth= SbC
Suction SH= XX.XºF IC SC Spt= 9.0ºF
Discharge SH= XX.XºF IC SC DB= 2.0ºF
Subcooling= XX.X°F
HtgSC EVI Min=
12% (Unit Size≤6)
50% (Unit Size>6)
Eff SSH Spt= XX.X°F
EffSH Base= XX.X°F
Eff SC Spt= XX.X°F Clg EVO Meth= SbC
Eff SC Lo Lmt= XXX% OC SC Spt= 9.0ºF
SRT= XXX°F OC SC DB= 2.0ºF
Disch Sat Tmp= XXX.X°F ClgSC EVO Min= 12%
Sucn Sat Tmp= XXX.X°F ManCtrl EV Op= Auto
IRT= XXX°F
ORT= XXX°F
D3 Set-Up
Itouch Vers= __________
Unit D3 Addr= Jan–00
Set D3 Addr= No
OA Unit Num= 0
OA Unit Amps= 0
OA Unit Addr= 0
Set OA Unit= No
Rst All OA= No
Min Load= 20%
Max Load= 50%
HiCapReset= No
DATLoDiff= 10.0ºF
Eco Method= None
DATHiDiff= 5.0ºF
OA Enth Max= 24.5 BTU/lb
OA Hum Max= 0.0107lb/lb
(Units not displayed on HMI)
OAT Max= 84ºF
Temp Display= DAT
Low Speed= 33%
Med Speed= 60%
Hi Speed= 100%
See page 29 and
49 – 50
Heating Set-Up
Htg Stage Time= 5min
Htg DB= 2.0°F
Htg Period= 60s
Htg Gain= 0.8
Htg PAT= 120s
Htg Max Chg= 10%
Htg Lo OAT Lk=
0.0°F – 45.0°F
(100% OA w/o ER)
Htg Hi OAT Lk= 55.0°F
EffHtgOATLk= 55.0°F
SplHtgOATLk= 55.0°F
OAT Diff= 2.0°F
Htg Reset= None
Min Htg Spt= 55.0°F
Min Htg Spt @= 0
Max Htg Spt= 120.0°F
Max Htg Spt@= 100
Min DAT Ctrl= Yes
Min DAT Limit= 55.0°F
F&BP Method= OpenVlv
F&BP ChgOvrT= 37°F
Occ Heating= Yes
Unocc Diff= 55.0°F
Htg Wmup Tm= 60s
Htg Hld Period= 240s
Max Purge Hld= 20s
Gas Derate V= 10.0v
MWUSensor= RAT
1, 2 See the expansion
information on page 19
OM 920-6 • MICROTECH UNIT CONTROLLER 14 www.DaikinApplied.com
Keypad/dIsplay Menu sTruCTure
To Next Page
