RF/EF Set-Up
Table 22: Return Fan/Exhaust Fan Set-up Menu
Item Display Name Default Setting Range Password Level
RF/EF Ctrl= Tracking
None
4
Tracking
BldgP
Spd/Net
OA Damper
Rem RAF Cap= 5% 0-100% 4
Rem ExhF Cap= 5% 0-100% 4
BSP DB= 0.01in 0.0-0.1in 4
BSP Period= 5s 0-999s 4
BSP Gain= 0.2 0.0-100.0s 4
Max Spd Chg= 4% 0-100% 4
Sup Fan Max= 100% 0-100% 4
RF @ SF Max 95% 0-100% 4
Sup Fan Min= 30% 0-100% 4
RF @ SF Min= 25% 0-100% 4
Lo Fan Diff= 75% 0-100% 4
Hi Fan Diff= 75% 0-100% 4
RFEF Ctrl Dly= 30s 0-999s 4
Min Speed=
5% With Exhaust Fan
0-100% 4
33% With Return Fan
MinExStrtTime= 120s 60-300s 4
MinExStopTime= 120s 60-300s 4
MinExhOAPos= 5% 0-100% 4
MinExhSAFCap= 10% 0-100% 4
ExhOnOAPos= 40% 0-100% 4
ExhMxOAPos= 100% 0-100% 4
Exh Stg 1 On= 40% 0-100% 4
Exh Stg 1 Off= 30% 0-100% 4
Exh Stg 2 On= 55% 0-100% 4
Exh Stg 2 Off= 40% 0-100% 4
Exh Stg 3 On= 70% 0-100% 4
Exh Stg 3 Off= 50% 0-100% 4
Max RF/EF Hz= 60Hz 0-100Hz N/A
Max RF/EF Hz= 60Hz 0-100Hz N/A
Max RF/EF Hz= 60Hz 0-100Hz N/A
MaxVentSpd= 100% 0-100% 2
Max RFEF RPM= 2600 0-5000 2
ECM Status= — OK 2
