Commission Unit
Unit Setup
Table 19: Unit Setup Menu
Item Display Name Default Setting Range Password Level
Apply Changes= No No, Yes 4
RAT Sensor= Yes No, Yes 4
OAT Sensor= Yes No, Yes 4
Space Sensor Digtl/Net
None
Anlog/Net
Digtl/Net
4
Eng Units= English English, SI 4
Unit Name= — — 4
Rapid Start= No No, Yes 2
Rapid Start Tm= 10 min 0–20 min 2
DO10 Cfg= FanOp
FanOp
VAVBox
2
100% OA SCU is an adjustable item used to select whether or
not a self contained unit will be congured for 100% outside air
operation.
Space Sensor is an adjustable item to indicate if a space
sensor is connected to the unit controller, or provided via a
network signal.
Eng Units is an adjustable item to indicate if the unit is to
display English or Metric units of measure.
Unit Name is an adjustable item that allows each controller
to be given a unique name. This may be useful when multiple
units are connected to a single remote HMI.
Rapid Start is an adjustable item that allows the user to select
to initiate a rapid startup sequence at unit power up.
Rapid Start Tm is an adjustable item that allows the user to
set the Rapid Start timing whenever the power is reset to the
controller and the controller nishes its startup sequence.
DO10 Cfg is an adjustable item that redenes the functionality
of the digital output (DO10) on the main control board. The
output is either a supply fan operation indication or a VAV box
signal depending on how this parameter is set.
Timer Settings Menu
Table 20: Timer Settings Menu
Item Display Name Default Setting Range Password Level
Service Time 0 min 0–240min 4
Start Up 180s 1800s 4
Recirculate 180s 3600s 4
Zero OA Time 0 min 0–240min 4
Tnt Override 120 min 0–300min 4
Post Heat 0s 0–180s 4
Pwd Timeout 10 min 3–30min 4
Low DAT 6 min 0–60min 4
ClgStateDelay 300s 0–600s 4
Clg Stg Time 5 min 5–60min 4
Htg Stg Time 5 min 2–60min 4
Min Ex Strt Tm 120s 60–300s 4
Min Ex Stop Tm 120s 60–300s 4
ER Whl Stg Tm 5 min 1–100min 4
ER Whl Off Tm 5 min 1–100min 4
Air Flw Ign 120s 0–999S 2
Htg Wrmup Tm 240s 0–999s 2
Htg Hld Period 240s 0–999s 2
Srvc Time Inc 20s 0–300s 2
Off HtCl Delay 120s 0–999s 2
Menu desCrIpTIons
www.DaikinApplied.com 33 OM 920-6 • MICROTECH UNIT CONTROLLER
