Daikin MicroTech III User Manual

Min OA Set-Up
Table 27: Min OA Damper Menu
Item Display Name Default Setting Range Password Level
Apply Changes No No, Yes 4
Min OA Reset= None
None
Network
Ext VDC
Ext mA
IAQ VDC
IAQ mA
4
BSP OA Ovrd No No/Yes 2
Rst Lmt Snsr None
None
DAT
EFT
MAT
2
OA @ MinV/mA= 0% 0–100% 4
OA @ MaxV/mA= 100% 0–100% 4
Min V/mA=
0.0/
V
0.0–20.0/
V
mA
4
Max V/mA=
10.0/
V
0.0–20.0/
V
mA
4
PPM @DCV Lmt= 800ppm 0–5000ppm 4
PPM @Vnt Lmt= 1000ppm 0-5000ppm 4
IAQ PPM= - 0–5000ppm 4
Min PPM= 0ppm 0–5000ppm 4
Max PPM= 2000ppm 0–5000ppm 4
V/A @Min PPM=
0.0/
V
0.0–20.0/
V
mA
4
V/A @Max PPM=
10.0/
V
0.0–20.0/
V
mA 4
Min CFM 0CFM 0–60000CFM 4
Max CFM 10000CFM 0–60000CFM 4
V/A @ Min CFM
0.0/
V
0.0–20.0/
V
mA
4
V/A @ Max CFM
10.0/
V
0.0–20.0/
V
mA
4
Min Fan Diff= 20% 0–100% 4
Max Fan Diff= 50% 0–100% 4
Min Clg Spd= 40% 0–100% 4
Des Clg Spd 100% 0–100% 4
DesignFlow= Yes Yes, No 4
Field AO Stn None
None
VDC
mA
4
OA Flow= - 0–60000CFM 4
Min OA Flw Spt= 2000CFM 0–60000CFM 4
Des Flo DB= 3% 0–100% 4
DF Period= 30s 0–999s 4
Des Flo Gain= 0.1 0.0–100.0 4
DF Max Chg= 5% 0–100% 4
OA CFM DB 3% 0–100% 4
OA CFMPerod 30s 0–999s 4
OA CFM Gain 0.1 0.0–100.0 4
OA CFM Max Chg 5% 0–100% 4
LH Lvl Pos= - 0.00–100.00% 4
RH Lvl Pos= - 0.00–100.00% 4
MinRFEFTm= 120sec 0–3600sec 2
BSPOvdST= 5sec 0–999sec 2
BSPOvdGain= 0.2 0–999 2
BSPOvdMxChg= 4% 0–100% 2
ResetTLmt= 32.0°F 0–100°F 2
RstTSmplT= 5sec 0–999sec 2
RstTGain= 0.2 0–999 2
RstTPAT= 60sec 0-999sec 2
RstTMaxChg= 4% 0–100% 2
Min Inc Rate= 0.03 0.0–100.0 2
Max Inc Rate= 1.0 0.0–100.0 2
0-30% OA Max= 30% 0–100% 2
