Menu desCrIpTIons
Quick Menu
Items in the Quick Menu contain basic unit operating status
and control set point parameters. The items shown in the Quick
Menu are Read Only if a valid password has not been entered.
The following are brief descriptions of the Quick Menu items.
No password is required to view the Quick Menu.
Table 1: Quick Menu
Menu Display Name Default Setting Range Password Level
Unit State= —
Off
Start
Recirc
FanOnly
MinDAT
Htg
Econo
Clg
None
Unit Status= —
Enable
OffMan
OffMnCtl
OffNet
OffAlm
OffFnRty
6
MWU Status= —
Inactive
Active
6
Dehum Status= — Active/Inactive 6
Ctrl Mode= Off
Off
HeatOnly
CoolOnly
FanOnly
HeatCool
Auto/Net
6
Occ Mode= Auto/Net
Occ
Unocc
TntOvrd
Auto/Net
6
Clg Capacity= — 0–100% None
OAD/Econo Cap= — 0–100% None
Htg Capacity= — 0–100% None
Reheat Capacity= — 0–100% None
Control Temp= — -50.0–200.0°F None
Occ Clg Spt = 72.0°F 0.0–100.0°F None
Occ Htg Spt = 68.0°F 0.0–100.0°F None
Disch Air= — -50.0–250.0°F None
DAT Clg Spt= 55.0°F 40.0–100.0°F None
DAT Htg Spt= 85.0°F 40.0–140.0°F None
Min DAT Limit= 55.0°F 0.0–70.0°F None
SAF Capacity= — 0–100% None
DSP — 0.2–4.0 in None
DuctSP Spt= 1.0 in 0.2–4.0 in None
RF/EF Capacity= — 0–100% None
BSP= — -0.25–0.25 in None
BldgSP Spt= 0.050 in -0.25–0.25 in None
OA Temp= — -50.0–200.0°F None
EW Temp= — -50.0–150.0°F None
Rel Humidity= — 0–100% None
