PCB Si001275
16 Removal Procedure
5
6
Remove the 2 screws.
Unfasten the 3 hooks
of the electrical box.
7
8
Remove the PCB from
the electrical box.
Disconnect the
connectors.
Step Procedure Points
(R18481)
Hook
(R5867)
