Daikin RXR28EV1B8 - Humidifying Duct

Humidifying Duct Si001275
12 Removal Procedure
6. Humidifying Duct
Warning

Be sure to wait for 10 minutes or more after turning off all power supplies before
disassembling work.
Step Procedure Points
1
Remove the screw and
remove the stop valve
cover.
2
Remove the screw and
remove the humidifying
duct.

When reassembling, make
sure to catch the hook.
(R18771)
Stop valve
cover
(R14004)
Humidifying duct
