Si-71A For FHYC71K
Removal Procedure 129
1.3 Removal of Suction Grille
Procedure
Warning Be sure to turn off all power supplies before disassembling work.
Step Procedure Points
1 Push the two buttons
simultaneously and pull the
suction grille down slowly.
∗
When closing, push up the grille
slowly.
2 With the suction grille open
at an angle of 45º, lift it up to
remove it.
To Next Page
