For FHY71F Si-71A
146 Removal Procedure
2.4 Removal of Fan Rotor an Motor
Procedure
Warning Be sure to turn off all power supplies before disassembling work.
Step Procedure Points
1 Push the 2 tabs of the fan
housing toward the inside
with your fingers, and pull
out the fan housing.
2 Loosen the 2 hexagon set
screws of the intermediate
bearing.
To Next Page
