Daikin RY50G - Page 155

For FHY71F Si-71A
144 Removal Procedure
3 Pull open the control box
and let it hang by the 2
locations in the rear.
Electrical parts can now be
removed.
4 Disconnect the connector
mounted on the PC board.
5 Remove the PC board
installation screw.
6 Slide the PC board to the left
away from the tabs on the
right, and remove the PC
board.
Step Procedure Points
