For FAY71F (A) Si-71A
170 Removal Procedure
3 Remove the air discharge
unit. (7 screws)
Center of air discharge section also
screw fastened.
4 Remove the drain pan. 1 Pull left side toward yourself. 2 Move
the drain hose to the right until it comes
off.
Step Procedure Points
