Daikin Super multi NX E Series User Manual

Heat Pump SiBE121135_A
39 Specifications
Ceiling Mounted Cassette Type
50 Hz, 220 - 230 - 240 V
Model
FCQG35FVEB FCQG50FVEB
Cooling Heating Cooling Heating
Rated Capacity 3.5 kW Class 5.0 kW Class
Decoration
Panel
Model BYCQ140D7W1 / BYCQ140D7W1W / BYCQ140D7GW1 BYCQ140D7W1 / BYCQ140D7W1W / BYCQ140D7GW1
Color Fresh White Fresh White
Dimensions (H × W × D) mm 60 × 950 × 950 / 60 × 950 × 950 / 145 × 950 × 950 60 × 950 × 950 / 60 × 950 × 950 / 145 × 950 × 950
Weight (Mass) kg 5.4 / 5.4 / 10.3 5.4 / 5.4 / 10.3
Air Filter Resin net with mold resistance Resin net with mold resistance
Airflow Rate
H
m³/min
12.5 12.5 12.6 12.6
M 10.6 10.6 10.7 10.7
L 8.7 8.7 8.7 8.7
Fan
Type Turbo Fan Turbo Fan
Motor Output W 48 48
Speed Steps 3 Steps 3 Steps
Dimensions (H × W × D) mm 204 × 840 × 840 204 × 840 × 840
Packaged Dimensions (H × W × D) mm 220 × 880 × 880 220 × 880 × 880
Weight (Mass) kg 18 19
Gross Weight (Gross Mass) kg 22 23
Sound
Pressure
Level
H / M / L dB(A) 31 / 29 / 27 31 / 29 / 27
Sound Power
Level
HdB 49 49
Heat Insulation Foamed polystyrene / Foamed polyethylene Foamed polystyrene / Foamed polyethylene
Piping
Connection
Liquid mm
φ
6.35 (Flare)
φ
6.35 (Flare)
Gas mm
φ 9.52
(Flare)
φ 12.7
(Flare)
Drain mm VP25 (O.D.
φ 32 / I.D. φ 25) VP25 (O.D. φ 32 / I.D. φ 25)
Drawing No. 3D076994 3D076994
Model
FCQG60FVEB
Cooling Heating
Rated Capacity 6.0 kW Class
Decoration
Panel
Model BYCQ140D7W1 / BYCQ140D7W1W / BYCQ140D7GW1
Color Fresh White
Dimensions (H × W × D) mm 60 × 950 × 950 / 60 × 950 × 950 / 145 × 950 × 950
Weight (Mass) kg 5.4 / 5.4 / 10.3
Air Filter Resin net with mold resistance
Airflow Rate
H
m³/min
13.6 13.6
M 11.2 11.2
L8.78.7
Fan
Type Turbo Fan
Motor Output W 48
Speed Steps 3 Steps
Dimensions (H × W × D) mm 204 × 840 × 840
Packaged Dimensions (H × W × D) mm 220 × 880 × 880
Weight (Mass) kg 19
Gross Weight (Gross Mass) kg 23
Sound
Pressure
Level
H / M / L dB(A) 33 / 31 / 28
Sound Power
Level
HdB 51
Heat Insulation Foamed polystyrene / Foamed polyethylene
Piping
Connection
Liquid mm
φ
6.35 (Flare)
Gas mm
φ 12.7
(Flare)
Drain mm VP25 (O.D.
φ 32 / I.D. φ 25)
Drawing No. 3D076994
Conversion Formulae
kcal/h = kW × 860
Btu/h = kW × 3412
cfm = m³/min × 35.3
