SiBE121135_A Heat Pump
Specifications 40
50 Hz, 230 V
Note: ( ) : dimension including control box
Model
FFQ25B9V1B FFQ35B9V1B
Cooling Heating Cooling Heating
Rated Capacity 2.5 kW Class 3.5 kW Class
Decoration
Panel
Model BYFQ60B8W1 BYFQ60B8W1
Color White White
Dimensions (H × W × D) mm 55 × 700 × 700 55 × 700 × 700
Weight (Mass) kg 2.7 2.7
Airflow Rate
H
m³/min
(cfm)
9.0 (318) 9.0 (318) 10.0 (353) 10.0 (353)
L 6.5 (230) 6.5 (230) 6.5 (230) 6.5 (230)
Fan
Type Turbo Fan Turbo Fan
Motor Output W 55 55
Speed Steps 2 Steps 2 Steps
Air Direction Control Horizontal, Downward Horizontal, Downward
Running Current (Rated) A 0.37 0.32 0.40 0.36
Power Consumption (Rated) W 73 64 84 76
Power Factor (Rated) % 85.8 87.0 91.3 91.8
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H × W × D) mm 260 (286) × 575 × 575 260 (286) × 575 × 575
Packaged Dimensions (H × W × D) mm 370 × 687 × 674 370 × 687 × 674
Weight (Mass) kg 17.5 17.5
Gross Weight (Gross Mass) kg 21 21
Sound
Pressure
Level
H / L dB(A) 29.5 / 24.5 32.0 / 25.0
Sound Power Level dB 46.5 49.0
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Piping
Connection
Liquid mm
φ
6.4
φ
6.4
Gas mm
φ 9.5 φ 9.5
Drain mm VP20 (O.D
φ 26 / I.D φ 20) VP20 (O.D φ 26 / I.D φ 20)
Drawing No. 3D060405 3D060407
Model
FFQ50B9V1B FFQ60B9V1B
Cooling Heating Cooling Heating
Rated Capacity 5.0 kW Class 6.0 kW Class
Decoration
Panel
Model BYFQ60B8W1 BYFQ60B8W1
Color White White
Dimensions (H × W × D) mm 55 × 700 × 700 55 × 700 × 700
Weight (Mass) kg 2.7 2.7
Airflow Rate
H
m³/min
(cfm)
12.0 (424) 12.0 (424) 15.0 (530) 15.0 (530)
L 8.0 (283) 8.0 (283) 10.0 (353) 10.0 (353)
Fan
Type Turbo Fan Turbo Fan
Motor Output W 55 55
Speed Steps 2 Steps 2 Steps
Air Direction Control Horizontal, Downward Horizontal, Downward
Running Current (Rated) A 0.49 0.45 0.61 0.56
Power Consumption (Rated) W 97 89 120 111
Power Factor (Rated) % 86.1 86.0 85.5 86.2
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H × W × D) mm 260 (286) × 575 × 575 260 (286) × 575 × 575
Packaged Dimensions (H × W × D) mm 370 × 687 × 674 370 × 687 × 674
Weight (Mass) kg 17.5 17.5
Gross Weight (Gross Mass) kg 21 21
Sound
Pressure
Level
H / L dB(A) 36.0 / 27.0 41.0 / 32.0 41.0 / 32.0
Sound Power Level dB 53.0
—
58.0
—
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Piping
Connection
Liquid mm
φ
6.4
φ
6.4
Gas mm
φ 12.7 φ 12.7
Drain mm VP20 (O.D
φ 26 / I.D φ 20) VP20 (O.D φ 26 / I.D φ 20)
Drawing No. 3D060409 3D040436
Conversion Formulae
kcal/h = kW × 860
Btu/h = kW × 3412
cfm = m³/min × 35.3
