Daikin Super multi NX E Series

Heat Pump SiBE121135_A
41 Specifications
Ceiling Suspended Type
50 Hz, 220 - 230 - 240 V
Model
FHQ35BWV1B FHQ50BWV1B
Cooling Heating Cooling Heating
Rated Capacity 3.5 kW Class 5.0 kW Class
Panel Color White White
Airflow Rate
H
m³/min
13.0 (459) 13.0 (459) 13.0 (459) 13.0 (459)
L 10.0 (353) 10.0 (353) 10.0 (353) 10.0 (353)
Fan
Type Sirocco Fan Sirocco Fan
Motor Output W 62 62
Speed Steps 2 Steps 2 Steps
Air Direction Control Right, Left, Horizontal, Downward Right, Left, Horizontal, Downward
Air Filter Removable / Washable / Mildew Proof Removable / Washable / Mildew Proof
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H × W × D) mm 195 × 960 × 680 195 × 960 × 680
Packaged Dimensions (H × W × D) mm 279 × 1,046 × 818 279 × 1,046 × 818
Weight (Mass) kg 24 25
Gross Weight (Gross Mass) kg 31 32
Sound
Pressure
Level
H / L dB(A) 37 / 32 38 / 33
Sound Power Level dB 53 54
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Piping
Connection
Liquid mm
φ
6.4
φ
6.4
Gas mm
φ
9.5
φ 12.7
Drain mm VP20 (O.D.
φ 26 / I.D. φ 20) VP20 (O.D. φ 26 / I.D. φ 20)
Drawing No. 3D075705 3D075706
Model
FHQ60BWV1B
Cooling Heating
Rated Capacity 6.0 kW Class
Panel Color White
Airflow Rate
H
m³/min
17.0 (600) 16.0 (565)
L 13.0 (459) 13.0 (459)
Fan
Type Sirocco Fan
Motor Output W 62
Speed Steps 2 Steps
Air Direction Control Right, Left, Horizontal, Downward
Air Filter Removable / Washable / Mildew Proof
Temperature Control Microcomputer Control
Dimensions (H × W × D) mm 195 × 1,160 × 680
Packaged Dimensions (H × W × D) mm 279 × 1,246 × 818
Weight (Mass) kg 27
Gross Weight (Gross Mass) kg 35
Sound
Pressure
Level
H / L dB(A) 39 / 33
Sound Power Level dB 55
Heat Insulation Both Liquid and Gas Pipes
Piping
Connection
Liquid mm
φ
6.4
Gas mm
φ 12.7
Drain mm VP20 (O.D.
φ 26 / I.D. φ 20)
Drawing No. 3D075707
Conversion Formulae
kcal/h = kW × 860
Btu/h = kW × 3412
cfm = m³/min × 35.3
