Daikin SUPER MULTI NX G Series - Removal of the Compressor

SiUS12-928 Outdoor Unit – 3MXS24JVJU / 4MXS32GVJU
Removal Procedure 214
2.7 Removal of the Compressor
Procedure Warning Be sure to wait 10 minutes or more after turning off all power supplies
before disassembling work.
Step
Procedure Points
1
Remove the terminal
cover.
2
Disconnect the
compressor lead wires.
 U : red, V : yellow, W : blue
3
Remove the overload
protector.
4
Remove the 2 nuts.  Disconnect the pipings,
referring to page 177.
(R6466)
Terminal
cover
(R9471)
W(blue)
U(red)
V(yellow)
Overload
protector
(R10440)
