EDUS121131 Specifications
SUPER MULTI NX 2/3/4MXS-G/J Series Heat Pump 15
1
3.4 Combination Capacity: 3MXS24JVJU
Cooling [60 Hz, 208 V]
Combination
of
indoor unit
Type of indoor unit
Capacity of each indoor unit
Each capacity (kBtu/h) Total capacity (kBtu/h) Total input (W) Total current (A)
Power
factor (%)
A room B room C room — A room B room C room — Rating (min ~ max) Rating (min ~ max) Rating (min ~ max) Rating
07 Wall — — — 7.60 — — — 7.60 6.50 ~ 7.60 670 590 ~ 670 3.3 2.9 ~ 3.3 98
09 Wall — — — 9.70 — — — 9.70 6.50 ~ 9.70 820 590 ~ 820 4.0 2.9 ~ 4.0 98
09 Duct — — — 9.40 — — — 9.40 6.00 ~ 9.40 880 620 ~ 880 4.3 3.0 ~ 4.3 98
12 Wall — — — 13.00 — — — 13.00 6.50 ~ 13.00 1130 590 ~ 1130 5.5 2.9 ~ 5.5 98
12 Duct — — — 12.10 — — — 12.10 6.00 ~ 12.10 1160 620 ~ 1160 5.7 3.0 ~ 5.7 98
15 Wall — — — 16.20 — — — 16.20 7.00 ~ 16.20 1430 600 ~ 1430 7.0 2.9 ~ 7.0 98
15 Duct — — — 15.10 — — — 15.10 6.70 ~ 15.10 1510 730 ~ 1510 7.4 3.6 ~ 7.4 98
18 Wall — — — 19.50 — — — 19.50 7.50 ~ 19.50 1950 630 ~ 1950 9.6 3.1 ~ 9.6 98
18 Duct — — — 18.10 — — — 18.10 7.20 ~ 18.10 1960 750 ~ 1960 9.6 3.7 ~ 9.6 98
07+07 Wall Wall — — 8.30 8.30 — — 16.60 7.90 ~ 16.60 1310 620 ~ 1310 6.4 3.0 ~ 6.4 98
07+09 Wall Wall — — 8.09 10.11 — — 18.20 7.90 ~ 18.20 1480 620 ~ 1480 7.3 3.0 ~ 7.3 98
07+09 Wall Duct — — 7.38 9.22 — — 16.60 7.50 ~ 16.60 1420 660 ~ 1420 7.0 3.2 ~ 7.0 98
07+12 Wall Wall — — 7.75 13.55 — — 21.30 7.90 ~ 21.30 1900 620 ~ 1900 9.3 3.0 ~ 9.3 98
07+12 Wall Duct — — 7.20 12.60 — — 19.80 7.50 ~ 19.80 1880 660 ~ 1880 9.2 3.2 ~ 9.2 98
07+15 Wall Wall — — 6.80 17.00 — — 23.80 9.30 ~ 23.80 2190 680 ~ 2190 10.7 3.3 ~ 10.7 98
07+15 Wall Duct — — 6.46 16.14 — — 22.60 9.10 ~ 22.60 2200 810 ~ 2200 10.8 4.0 ~ 10.8 98
07+18 Wall Wall — — 6.00 18.00 — — 24.00 9.90 ~ 24.70 2240 710 ~ 2360 11.0 3.5 ~ 11.6 98
07+18 Wall Duct — — 5.85 17.55 — — 23.40 9.60 ~ 23.40 2360 840 ~ 2360 11.6 4.1 ~ 11.6 98
09+09 Wall Wall — — 9.90 9.90 — — 19.80 7.90 ~ 19.80 1660 620 ~ 1660 8.1 3.0 ~ 8.1 98
09+09 Wall Duct — — 9.10 9.10 — — 18.20 7.50 ~ 18.20 1640 660 ~ 1640 8.0 3.2 ~ 8.0 98
09+09 Duct Duct — — 8.25 8.25 — — 16.50 7.10 ~ 16.50 1530 690 ~ 1530 7.5 3.4 ~ 7.5 98
09+12 Wall Wall — — 9.50 13.30 — — 22.80 8.40 ~ 22.80 2160 650 ~ 2160 10.6 3.2 ~ 10.6 98
09+12 Wall Duct — — 8.88 12.42 — — 21.30 8.00 ~ 21.30 2130 680 ~ 2130 10.4 3.3 ~ 10.4 98
09+12 Duct Wall — — 8.88 12.42 — — 21.30 8.00 ~ 21.30 2130 680 ~ 2130 10.4 3.3 ~ 10.4 98
09+12 Duct Duct — — 8.21 11.49 — — 19.70 7.60 ~ 19.70 2040 720 ~ 2040 10.0 3.5 ~ 10.0 98
09+15 Wall Wall — — 8.00 16.00 — — 24.00 9.90 ~ 24.40 2240 710 ~ 2300 11.0 3.5 ~ 11.3 98
09+15 Wall Duct — — 7.73 15.47 — — 23.20 9.60 ~ 23.20 2300 840 ~ 2300 11.3 4.1 ~ 11.3 98
09+15 Duct Wall — — 8.00 16.00 — — 24.00 9.40 ~ 24.00 2480 750 ~ 2480 12.2 3.7 ~ 12.2 98
09+15 Duct Duct — — 7.63 15.27 — — 22.90 9.20 ~ 22.90 2490 880 ~ 2490 12.2 4.3 ~ 12.2 98
09+18 Wall Wall — — 7.06 16.94 — — 24.00 9.90 ~ 25.10 2240 710 ~ 2470 11.0 3.5 ~ 12.1 98
09+18 Wall Duct — — 7.06 16.94 — — 24.00 9.60 ~ 24.00 2470 840 ~ 2470 12.1 4.1 ~ 12.1 98
09+18 Duct Wall — — 7.06 16.94 — — 24.00 9.50 ~ 24.70 2490 750 ~ 2660 12.2 3.7 ~ 13.0 98
09+18 Duct Duct — — 6.91 16.59 — — 23.50 9.20 ~ 23.50 2650 880 ~ 2650 13.0 4.3 ~ 13.0 98
12+12 Wall Wall — — 12.00 12.00 — — 24.00 8.90 ~ 24.00 2440 670 ~ 2440 12.0 3.3 ~ 12.0 98
12+12 Duct Wall — — 11.85 11.85 — — 23.70 8.50 ~ 23.70 2680 710 ~ 2680 13.1 3.5 ~ 13.1 98
12+12 Duct Duct — — 11.50 11.50 — — 23.00 8.00 ~ 23.00 2870 750 ~ 2870 14.1 3.7 ~ 14.1 98
12+15 Wall Wall — — 9.88 14.12 — — 24.00 9.90 ~ 25.10 2240 710 ~ 2470 11.0 3.5 ~ 12.1 98
12+15 Wall Duct — — 9.88 14.12 — — 24.00 9.60 ~ 24.00 2470 840 ~ 2470 12.1 4.1 ~ 12.1 98
12+15 Duct Wall — — 9.88 14.12 — — 24.00 9.40 ~ 24.40 2480 750 ~ 2600 12.2 3.7 ~ 12.8 98
12+15 Duct Duct — — 9.59 13.71 — — 23.30 9.20 ~ 23.30 2600 880 ~ 2600 12.8 4.3 ~ 12.8 98
12+18 Wall Wall — — 8.84 15.16 — — 24.00 12.90 ~ 25.80 2240 900 ~ 2650 11.0 4.4 ~ 13.0 98
12+18 Wall Duct — — 8.84 15.16 — — 24.00 12.50 ~ 24.50 2470 1030 ~ 2580 12.1 5.1 ~ 12.7 98
12+18 Duct Wall — — 8.84 15.16 — — 24.00 12.40 ~ 25.00 2490 940 ~ 2720 12.2 4.6 ~ 13.3 98
12+18 Duct Duct — — 8.77 15.03 — — 23.80 11.90 ~ 23.80 2710 1060 ~ 2710 13.3 5.2 ~ 13.3 98
15+15 Wall Wall — — 12.00 12.00 — — 24.00 13.40 ~ 26.20 2100 910 ~ 2550 10.3 4.5 ~ 12.5 98
15+15 Duct Wall — — 12.00 12.00 — — 24.00 13.10 ~ 25.20 2270 1030 ~ 2550 11.1 5.1 ~ 12.5 98
15+15 Duct Duct — — 12.00 12.00 — — 24.00 12.80 ~ 24.60 2550 1160 ~ 2670 12.5 5.7 ~ 13.1 98
15+18 Wall Wall — — 10.91 13.09 — — 24.00 13.50 ~ 26.90 2050 910 ~ 2680 10.1 4.5 ~ 13.1 98
15+18 Wall Duct — — 10.91 13.09 — — 24.00 13.10 ~ 25.60 2270 1030 ~ 2670 11.1 5.1 ~ 13.1 98
15+18 Duct Wall — — 10.91 13.09 — — 24.00 13.20 ~ 25.60 2280 1030 ~ 2610 11.2 5.1 ~ 12.8 98
15+18 Duct Duct — — 10.91 13.09 — — 24.00 12.80 ~ 25.00 2550 1160 ~ 2720 12.5 5.7 ~ 13.3 98
18+18 Wall Wall — — 12.00 12.00 — — 24.00 13.50 ~ 27.60 2050 910 ~ 2860 10.1 4.5 ~ 14.0 98
18+18 Duct Wall — — 12.00 12.00 — — 24.00 13.20 ~ 26.40 2280 1030 ~ 2850 11.2 5.1 ~ 14.0 98
18+18 Duct Duct — — 12.00 12.00 — — 24.00 12.80 ~ 25.80 2550 1160 ~ 2960 12.5 5.7 ~ 14.5 98
07+07+07 Wall Wall Wall — 7.77 7.77 7.77 — 23.30 9.50 ~ 23.30 1810 640 ~ 1810 8.9 3.1 ~ 8.9 98
07+07+09 Wall Wall Wall — 7.26 7.26 9.08 — 23.60 10.10 ~ 23.60 1860 670 ~ 1860 9.1 3.3 ~ 9.1 98
07+07+09 Wall Wall Duct — 7.08 7.08 8.84 — 23.00 9.80 ~ 23.00 1940 720 ~ 1940 9.5 3.5 ~ 9.5 98
