EDUS121131 Capacity Tables
SUPER MULTI NX 2/3/4MXS-G/J Series Heat Pump 117
1
CTXS07L +
FDXS09L
68.0 17.01 1.14 17.77 1.16 18.54 1.19 18.92 1.20 20.07 1.23 20.83 1.25
77.0 16.23 1.21 17.00 1.23 17.76 1.25 18.15 1.27 19.29 1.30 20.06 1.32
86.0 15.46 1.28 16.23 1.31 16.99 1.33 17.37 1.34 18.52 1.37 19.28 1.40
89.6 15.15 1.32 15.92 1.34 16.68 1.36 17.06 1.37 18.21 1.41 18.98 1.43
95.0 14.69 1.36 15.45 1.39 16.22 1.41
16.60 1.42 17.75 1.46 18.51 1.48
104.0 13.92 1.45 14.68 1.47 15.44 1.50 15.83 1.51 16.97 1.54 17.74 1.57
109.4 13.45 1.51 14.22 1.53 14.98 1.55 15.36 1.56 16.51 1.60 17.28 1.62
114.8 9.34 0.98 9.75 0.98 10.14 0.98 10.33 0.98 10.90 0.98 11.26 0.98
CTXS07L +
CTXS12H
68.0 21.82 1.53 22.80 1.56 23.78 1.59 24.28 1.60 25.75 1.65 26.73 1.68
77.0 20.83 1.62 21.81 1.65 22.79 1.68 23.28 1.69 24.76 1.74 25.74 1.77
86.0 19.84 1.72 20.82 1.75 21.80 1.78 22.29 1.79 23.76 1.84 24.75 1.87
89.6 19.44 1.76 20.42 1.79 21.40 1.82 21.90 1.84 23.37 1.88 24.35 1.91
95.0 18.85 1.83 19.83 1.86 20.81 1.89
21.30 1.90 22.77 1.95 23.75 1.98
104.0 17.85 1.94 18.84 1.97 19.82 2.00 20.31 2.02 21.78 2.06 22.76 2.09
109.4 16.06 1.77 16.79 1.77 17.51 1.77 17.86 1.77 18.89 1.77 19.55 1.77
114.8 10.07 0.98 10.48 0.98 10.87 0.98 11.07 0.98 11.63 0.98 12.00 0.98
CTXS07L +
FDXS12L
68.0 20.29 1.51 21.20 1.54 22.11 1.57 22.57 1.58 23.93 1.63 24.85 1.66
77.0 19.36 1.60 20.28 1.63 21.19 1.66 21.64 1.68 23.01 1.72 23.92 1.75
86.0 18.44 1.70 19.35 1.73 20.27 1.76 20.72 1.77 22.09 1.82 23.00 1.85
89.6 18.07 1.74 18.98 1.77 19.90 1.80 20.35 1.82 21.72 1.86 22.63 1.89
95.0 17.52 1.81 18.43 1.84 19.34 1.87
19.80 1.88 21.17 1.93 22.08 1.96
104.0 16.60 1.92 17.51 1.95 18.42 1.98 18.88 2.00 20.25 2.04 21.16 2.07
109.4 15.06 1.77 15.76 1.77 16.43 1.77 16.77 1.77 17.74 1.77 18.37 1.77
114.8 9.55 0.98 9.94 0.98 10.31 0.98 10.49 0.98 11.03 0.98 11.38 0.98
CTXS07L +
FTXS15L
68.0 26.74 2.22 27.94 2.26 29.14 2.30 29.75 2.33 31.55 2.39 32.75 2.44
77.0 25.52 2.35 26.73 2.39 27.93 2.44 28.53 2.46 30.33 2.53 31.54 2.57
86.0 24.31 2.50 25.51 2.54 26.71 2.58 27.32 2.61 29.12 2.67 30.32 2.72
89.6 23.82 2.56 25.03 2.60 26.23 2.64 26.83 2.67 28.63 2.73 29.84 2.78
95.0 23.09 2.65 24.30 2.70 25.50 2.74
26.10 2.76 27.90 2.83 29.11 2.87
104.0 21.22 2.56 22.22 2.56 23.20 2.56 23.67 2.56 25.08 2.56 25.99 2.56
109.4 16.99 1.77 17.68 1.77 18.35 1.77 18.68 1.77 19.65 1.77 20.28 1.77
114.8 10.76 0.98 11.13 0.98 11.50 0.98 11.69 0.98 12.22 0.98 12.57 0.98
CTXS07L +
CDXS15L
68.0 23.97 1.90 25.05 1.93 26.13 1.97 26.67 1.99 28.29 2.05 29.36 2.08
77.0 22.88 2.01 23.96 2.05 25.04 2.08 25.58 2.10 27.20 2.16 28.27 2.20
86.0 21.79 2.13 22.87 2.17 23.95 2.21 24.49 2.23 26.11 2.28 27.18 2.32
89.6 21.36 2.19 22.44 2.22 23.51 2.26 24.05 2.28 25.67 2.34 26.75 2.37
95.0 20.70 2.27 21.78 2.31 22.86 2.34
23.40 2.36 25.02 2.42 26.10 2.46
104.0 19.62 2.41 20.69 2.45 21.77 2.49 22.31 2.51 23.91 2.56 24.82 2.56
109.4 16.07 1.77 16.76 1.77 17.43 1.77 17.77 1.77 18.74 1.77 19.36 1.77
114.8 10.19 0.98 10.57 0.98 10.94 0.98 11.12 0.98 11.66 0.98 12.00 0.98
CTXS07L +
FTXS18L
68.0 27.25 2.27 28.48 2.32 29.70 2.36 30.32 2.39 32.15 2.45 33.38 2.50
77.0 26.01 2.41 27.24 2.45 28.46 2.50 29.08 2.52 30.92 2.59 32.14 2.64
86.0 24.77 2.56 26.00 2.60 27.23 2.65 27.84 2.67 29.68 2.74 30.90 2.78
89.6 24.28 2.62 25.50 2.67 26.73 2.71 27.34 2.73 29.18 2.80 30.41 2.85
95.0 23.54 2.72 24.76 2.77 25.99 2.81
26.60 2.83 28.44 2.90 29.66 2.95
104.0 21.47 2.56 22.47 2.56 23.45 2.56 23.93 2.56 25.34 2.56 26.26 2.56
109.4 17.18 1.77 17.87 1.77 18.54 1.77 18.87 1.77 19.84 1.77 20.47 1.77
114.8 10.87 0.98 11.25 0.98 11.62 0.98 11.80 0.98 12.34 0.98 12.69 0.98
Combination
(Capacity)
Outdoor air
temp.
EDB (°F)
Indoor air temp. EWB (°F)
57.2 60.8 64.4 67.0 71.6 75.2
TC PI TC PI TC PI TC PI TC PI TC PI
kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW
