Daikin SUPER MULTI NX G Series User Manual

Capacity Tables EDUS121131
118 SUPER MULTI NX 2/3/4MXS-G/J Series Heat Pump
CTXS07L +
CDXS18L
68.0 24.28 1.94 25.37 1.97 26.46 2.01 27.01 2.03 28.65 2.09 29.74 2.13
77.0 23.18 2.05 24.27 2.09 25.36 2.13 25.91 2.15 27.54 2.21 28.64 2.24
86.0 22.07 2.18 23.17 2.22 24.26 2.26 24.80 2.28 26.44 2.33 27.53 2.37
89.6 21.63 2.23 22.72 2.27 23.82 2.31 24.36 2.33 26.00 2.39 27.09 2.43
95.0 20.97 2.32 22.06 2.35 23.15 2.39
23.70 2.41 25.34 2.47 26.43 2.51
104.0 19.87 2.46 20.96 2.50 22.05 2.54 22.60 2.56 24.00 2.56 24.91 2.56
109.4 16.16 1.77 16.84 1.77 17.51 1.77 17.84 1.77 18.81 1.77 19.44 1.77
114.8 10.24 0.98 10.62 0.98 10.99 0.98 11.17 0.98 11.71 0.98 12.05 0.98
CTXS09H +
CTXS09H
68.0 20.29 1.33 21.20 1.36 22.11 1.39 22.57 1.40 23.93 1.44 24.85 1.47
77.0 19.36 1.41 20.28 1.44 21.19 1.47 21.64 1.48 23.01 1.52 23.92 1.55
86.0 18.44 1.50 19.35 1.53 20.27 1.55 20.72 1.57 22.09 1.61 23.00 1.63
89.6 18.07 1.54 18.98 1.56 19.90 1.59 20.35 1.60 21.72 1.64 22.63 1.67
95.0 17.52 1.60 18.43 1.62 19.34 1.65
19.80 1.66 21.17 1.70 22.08 1.73
104.0 16.60 1.70 17.51 1.72 18.42 1.75 18.88 1.76 20.25 1.80 21.16 1.83
109.4 16.04 1.76 16.86 1.77 17.60 1.77 17.97 1.77 19.03 1.77 19.72 1.77
114.8 10.04 0.98 10.46 0.98 10.87 0.98 11.07 0.98 11.66 0.98 12.03 0.98
CTXS09H +
FDXS09L
68.0 18.65 1.32 19.48 1.34 20.32 1.37 20.74 1.38 22.00 1.42 22.84 1.45
77.0 17.80 1.40 18.64 1.42 19.48 1.45 19.89 1.46 21.15 1.50 21.99 1.53
86.0 16.95 1.48 17.79 1.51 18.63 1.54 19.05 1.55 20.31 1.59 21.14 1.61
89.6 16.61 1.52 17.45 1.55 18.29 1.57 18.71 1.58 19.97 1.62 20.80 1.65
95.0 16.10 1.58 16.94 1.60 17.78 1.63
18.20 1.64 19.46 1.68 20.30 1.71
104.0 15.26 1.68 16.09 1.70 16.93 1.73 17.35 1.74 18.61 1.78 19.45 1.81
109.4 14.75 1.74 15.59 1.77 16.31 1.77 16.65 1.77 17.65 1.77 18.30 1.77
114.8 9.42 0.98 9.81 0.98 10.19 0.98 10.38 0.98 10.93 0.98 11.29 0.98
FDXS09L +
FDXS09L
68.0 16.90 1.23 17.66 1.25 18.42 1.28 18.80 1.29 19.95 1.33 20.71 1.35
77.0 16.14 1.30 16.90 1.33 17.66 1.35 18.04 1.36 19.18 1.40 19.94 1.42
86.0 15.37 1.38 16.13 1.41 16.89 1.43 17.27 1.44 18.41 1.48 19.17 1.51
89.6 15.06 1.42 15.82 1.44 16.58 1.47 16.96 1.48 18.10 1.52 18.86 1.54
95.0 14.60 1.47 15.36 1.49 16.12 1.52
16.50 1.53 17.64 1.57 18.40 1.59
104.0 13.83 1.56 14.59 1.59 15.35 1.61 15.73 1.63 16.87 1.66 17.63 1.69
109.4 13.37 1.62 14.13 1.65 14.89 1.67 15.27 1.69 16.41 1.72 17.17 1.75
114.8 8.95 0.98 9.33 0.98 9.70 0.98 9.88 0.98 10.42 0.98 10.76 0.98
CTXS09H +
CTXS12H
68.0 23.36 1.73 24.41 1.77 25.46 1.80 25.98 1.82 27.56 1.87 28.61 1.91
77.0 22.30 1.84 23.35 1.87 24.40 1.91 24.92 1.93 26.50 1.98 27.55 2.01
86.0 21.24 1.95 22.29 1.99 23.34 2.02 23.86 2.04 25.44 2.09 26.49 2.13
89.6 20.81 2.00 21.86 2.04 22.91 2.07 23.44 2.09 25.01 2.14 26.06 2.17
95.0 20.17 2.08 21.22 2.11 22.27 2.15
22.80 2.16 24.38 2.21 25.43 2.25
104.0 19.11 2.21 20.16 2.24 21.21 2.28 21.74 2.29 23.31 2.35 24.36 2.38
109.4 16.17 1.77 16.88 1.77 17.58 1.77 17.92 1.77 18.92 1.77 19.57 1.77
114.8 10.19 0.98 10.58 0.98 10.97 0.98 11.16 0.98 11.71 0.98 12.07 0.98
CTXS09H +
FDXS12L
68.0 21.82 1.71 22.80 1.74 23.78 1.78 24.28 1.80 25.75 1.85 26.73 1.88
77.0 20.83 1.81 21.81 1.85 22.79 1.88 23.28 1.90 24.76 1.95 25.74 1.98
86.0 19.84 1.93 20.82 1.96 21.80 1.99 22.29 2.01 23.76 2.06 24.75 2.10
89.6 19.44 1.97 20.42 2.01 21.40 2.04 21.90 2.06 23.37 2.11 24.35 2.14
95.0 18.85 2.05 19.83 2.08 20.81 2.12
21.30 2.13 22.77 2.18 23.75 2.22
104.0 17.85 2.18 18.84 2.21 19.82 2.25 20.31 2.26 21.78 2.31 22.76 2.35
109.4 15.30 1.77 15.98 1.77 16.65 1.77 16.97 1.77 17.93 1.77 18.55 1.77
114.8 9.74 0.98 10.11 0.98 10.48 0.98 10.66 0.98 11.18 0.98 11.53 0.98
Combination
(Capacity)
Outdoor air
temp.
EDB (°F)
Indoor air temp. EWB (°F)
57.2 60.8 64.4 67.0 71.6 75.2
TC PI TC PI TC PI TC PI TC PI TC PI
kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW
