Daikin SUPER MULTI NX G Series User Manual

EDUS121131 Specifications
SUPER MULTI NX 2/3/4MXS-G/J Series Heat Pump 49
1
07+09+09+15 Wall Wall Duct Duct 5.32 6.65 6.65 13.28 31.90 11.90 ~ 33.70 2900 1020 ~ 3200 12.9 4.5 ~ 14.2 98
07+09+09+15 Wall Duct Duct Wall 5.32 6.65 6.65 13.28 31.90 11.90 ~ 33.70 2810 930 ~ 3110 12.5 4.1 ~ 13.8 98
07+09+09+15 Wall Duct Duct Duct 5.25 6.56 6.56 13.13 31.50 11.90 ~ 33.20 2930 1080 ~ 3230 13.0 4.8 ~ 14.3 98
07+09+09+18 Wall Wall Wall Wall 5.12 6.40 6.40 15.38 33.30 11.70 ~ 34.60 2920 850 ~ 3190 13.0 3.8 ~ 14.2 98
07+09+09+18 Wall Wall Wall Duct 5.06 6.33 6.33 15.18 32.90 11.80 ~ 34.20 2990 970 ~ 3250 13.3 4.3 ~ 14.4 98
07+09+09+18 Wall Wall Duct Wall 5.06 6.33 6.33 15.18 32.90 11.80 ~ 34.20 2900 890 ~ 3160 12.9 3.9 ~ 14.0 98
07+09+09+18 Wall Wall Duct Duct 5.00 6.25 6.25 15.00 32.50 11.90 ~ 33.80 3000 1020 ~ 3260 13.3 4.5 ~ 14.5 98
07+09+09+18 Wall Duct Duct Wall 5.00 6.25 6.25 15.00 32.50 11.80 ~ 33.80 2900 930 ~ 3110 12.9 4.1 ~ 13.8 98
07+09+09+18 Wall Duct Duct Duct 4.92 6.15 6.15 14.78 32.00 11.90 ~ 33.30 2980 1080 ~ 3230 13.2 4.8 ~ 14.3 98
07+09+12+12 Wall Wall Wall Wall 5.69 7.11 9.95 9.95 32.70 11.90 ~ 34.50 2810 840 ~ 3180 12.5 3.7 ~ 14.1 98
07+09+12+12 Wall Wall Wall Duct 5.62 7.02 9.83 9.83 32.30 11.90 ~ 34.10 2840 900 ~ 3250 12.6 4.0 ~ 14.4 98
07+09+12+12 Wall Wall Duct Duct 5.55 6.93 9.71 9.71 31.90 12.00 ~ 33.70 2880 960 ~ 3240 12.8 4.3 ~ 14.4 98
07+09+12+12 Wall Duct Wall Wall 5.62 7.02 9.83 9.83 32.30 11.90 ~ 34.10 2840 900 ~ 3250 12.6 4.0 ~ 14.4 98
07+09+12+12 Wall Duct Wall Duct 5.55 6.93 9.71 9.71 31.90 12.00 ~ 33.70 2880 960 ~ 3240 12.8 4.3 ~ 14.4 98
07+09+12+12 Wall Duct Duct Duct 5.48 6.84 9.59 9.59 31.50 12.00 ~ 33.20 2930 1020 ~ 3300 13.0 4.5 ~ 14.6 98
07+09+12+15 Wall Wall Wall Wall 5.12 6.40 8.97 12.81 33.30 11.70 ~ 34.60 2910 840 ~ 3180 12.9 3.7 ~ 14.1 98
07+09+12+15 Wall Wall Wall Duct 5.06 6.33 8.86 12.65 32.90 11.80 ~ 34.20 2990 970 ~ 3250 13.3 4.3 ~ 14.4 98
07+09+12+15 Wall Wall Duct Wall 5.06 6.33 8.86 12.65 32.90 11.80 ~ 34.20 2900 890 ~ 3160 12.9 3.9 ~ 14.0 98
07+09+12+15 Wall Wall Duct Duct 5.00 6.25 8.75 12.50 32.50 11.90 ~ 33.80 3000 1020 ~ 3260 13.3 4.5 ~ 14.5 98
07+09+12+15 Wall Duct Wall Wall 5.06 6.33 8.86 12.65 32.90 11.80 ~ 34.20 2900 890 ~ 3160 12.9 3.9 ~ 14.0 98
07+09+12+15 Wall Duct Wall Duct 5.00 6.25 8.75 12.50 32.50 11.90 ~ 33.80 3000 1020 ~ 3260 13.3 4.5 ~ 14.5 98
07+09+12+15 Wall Duct Duct Wall 5.00 6.25 8.75 12.50 32.50 11.90 ~ 33.80 2910 930 ~ 3110 12.9 4.1 ~ 13.8 98
07+09+12+15 Wall Duct Duct Duct 4.92 6.15 8.62 12.31 32.00 11.90 ~ 33.30 2980 1080 ~ 3230 13.2 4.8 ~ 14.3 98
07+12+12+12 Wall Wall Wall Wall 5.34 9.32 9.32 9.32 33.30 11.90 ~ 34.50 2970 840 ~ 3180 13.2 3.7 ~ 14.1 98
07+12+12+12 Wall Wall Wall Duct 5.27 9.21 9.21 9.21 32.90 11.90 ~ 34.20 2940 900 ~ 3250 13.0 4.0 ~ 14.4 98
07+12+12+12 Wall Wall Duct Duct 5.20 9.10 9.10 9.10 32.50 12.00 ~ 33.80 2980 960 ~ 3240 13.2 4.3 ~ 14.4 98
07+12+12+12 Wall Duct Duct Duct 5.12 8.96 8.96 8.96 32.00 12.00 ~ 33.30 3030 1020 ~ 3300 13.4 4.5 ~ 14.6 98
09+09+09+09 Wall Wall Wall Wall 8.03 8.03 8.03 8.03 32.10 9.60 ~ 34.50 2710 730 ~ 3180 12.0 3.2 ~ 14.1 98
09+09+09+09 Wall Wall Wall Duct 7.93 7.93 7.93 7.93 31.70 9.70 ~ 34.10 2740 790 ~ 3200 12.2 3.5 ~ 14.2 98
09+09+09+09 Wall Wall Duct Duct 7.83 7.83 7.83 7.83 31.30 9.70 ~ 33.70 2780 840 ~ 3240 12.3 3.7 ~ 14.4 98
09+09+09+09 Wall Duct Duct Duct 7.70 7.70 7.70 7.70 30.80 9.80 ~ 33.20 2830 900 ~ 3300 12.6 4.0 ~ 14.6 98
09+09+09+09 Duct Duct Duct Duct 7.60 7.60 7.60 7.60 30.40 9.90 ~ 32.80 2900 970 ~ 3380 12.9 4.3 ~ 15.0 98
09+09+09+12 Wall Wall Wall Wall 7.41 7.41 7.41 10.37 32.60 11.90 ~ 34.50 2810 840 ~ 3180 12.5 3.7 ~ 14.1 98
09+09+09+12 Wall Wall Wall Duct 7.32 7.32 7.32 10.24 32.20 11.90 ~ 34.10 2840 900 ~ 3200 12.6 4.0 ~ 14.2 98
09+09+09+12 Wall Wall Duct Wall 7.32 7.32 7.32 10.24 32.20 11.90 ~ 34.10 2840 900 ~ 3200 12.6 4.0 ~ 14.2 98
09+09+09+12 Wall Wall Duct Duct 7.23 7.23 7.23 10.11 31.80 12.00 ~ 33.70 2880 960 ~ 3240 12.8 4.3 ~ 14.4 98
09+09+09+12 Wall Duct Duct Wall 7.23 7.23 7.23 10.11 31.80 12.00 ~ 33.70 2880 960 ~ 3240 12.8 4.3 ~ 14.4 98
09+09+09+12 Wall Duct Duct Duct 7.11 7.11 7.11 9.97 31.30 12.00 ~ 33.20 2930 1020 ~ 3300 13.0 4.5 ~ 14.6 98
09+09+09+12 Duct Duct Duct Wall 7.11 7.11 7.11 9.97 31.30 12.00 ~ 33.20 2930 1020 ~ 3300 13.0 4.5 ~ 14.6 98
09+09+09+12 Duct Duct Duct Duct 7.02 7.02 7.02 9.84 30.90 12.10 ~ 32.80 3000 1090 ~ 3380 13.3 4.8 ~ 15.0 98
09+09+09+15 Wall Wall Wall Wall 6.62 6.62 6.62 13.24 33.10 11.70 ~ 34.60 2910 840 ~ 3180 12.9 3.7 ~ 14.1 98
09+09+09+15 Wall Wall Wall Duct 6.54 6.54 6.54 13.08 32.70 11.80 ~ 34.20 2940 970 ~ 3250 13.0 4.3 ~ 14.4 98
09+09+09+15 Wall Wall Duct Wall 6.54 6.54 6.54 13.08 32.70 11.80 ~ 34.20 2850 890 ~ 3160 12.6 3.9 ~ 14.0 98
09+09+09+15 Wall Wall Duct Duct 6.46 6.46 6.46 12.92 32.30 11.90 ~ 33.80 2950 1020 ~ 3260 13.1 4.5 ~ 14.5 98
09+09+09+15 Wall Duct Duct Wall 6.46 6.46 6.46 12.92 32.30 11.90 ~ 33.80 2860 930 ~ 3110 12.7 4.1 ~ 13.8 98
09+09+09+15 Wall Duct Duct Duct 6.36 6.36 6.36 12.72 31.80 11.90 ~ 33.30 2980 1080 ~ 3230 13.2 4.8 ~ 14.3 98
09+09+09+15 Duct Duct Duct Wall 6.36 6.36 6.36 12.72 31.80 11.90 ~ 33.30 2880 990 ~ 3130 12.8 4.4 ~ 13.9 98
09+09+09+15 Duct Duct Duct Duct 6.28 6.28 6.28 12.56 31.40 12.00 ~ 32.90 3020 1140 ~ 3280 13.4 5.1 ~ 14.6 98
09+09+09+18 Wall Wall Wall Wall 6.22 6.22 6.22 14.94 33.60 11.70 ~ 34.60 3030 850 ~ 3190 13.4 3.8 ~ 14.2 98
09+09+09+18 Wall Wall Wall Duct 6.15 6.15 6.15 14.75 33.20 11.80 ~ 34.20 3040 970 ~ 3250 13.5 4.3 ~ 14.4 98
09+09+09+18 Wall Wall Duct Wall 6.15 6.15 6.15 14.75 33.20 11.80 ~ 34.20 2950 890 ~ 3160 13.1 3.9 ~ 14.0 98
09+09+09+18 Wall Wall Duct Duct 6.07 6.07 6.07 14.59 32.80 11.90 ~ 33.80 3050 1020 ~ 3260 13.5 4.5 ~ 14.5 98
09+09+09+18 Wall Duct Duct Wall 6.07 6.07 6.07 14.59 32.80 11.80 ~ 33.80 2950 930 ~ 3110 13.1 4.1 ~ 13.8 98
09+09+09+18 Wall Duct Duct Duct 5.98 5.98 5.98 14.36 32.30 11.90 ~ 33.30 3030 1080 ~ 3230 13.4 4.8 ~ 14.3 98
09+09+09+18 Duct Duct Duct Wall 5.98 5.98 5.98 14.36 32.30 11.90 ~ 33.30 2920 980 ~ 3120 13.0 4.3 ~ 13.8 98
09+09+09+18 Duct Duct Duct Duct 5.91 5.91 5.91 14.17 31.90 12.00 ~ 32.90 3070 1140 ~ 3280 13.6 5.1 ~ 14.6 98
09+09+12+12 Wall Wall Wall Wall 6.90 6.90 9.65 9.65 33.10 11.90 ~ 34.50 2920 840 ~ 3180 13.0 3.7 ~ 14.1 98
09+09+12+12 Wall Wall Wall Duct 6.81 6.81 9.54 9.54 32.70 11.90 ~ 34.20 2940 900 ~ 3200 13.0 4.0 ~ 14.2 98
09+09+12+12 Wall Wall Duct Duct 6.73 6.73 9.42 9.42 32.30 12.00 ~ 33.80 2980 960 ~ 3240 13.2 4.3 ~ 14.4 98
09+09+12+12 Wall Duct Wall Wall 6.81 6.81 9.54 9.54 32.70 11.90 ~ 34.20 2940 900 ~ 3200 13.0 4.0 ~ 14.2 98
09+09+12+12 Wall Duct Wall Duct 6.73 6.73 9.42 9.42 32.30 12.00 ~ 33.80 2980 960 ~ 3240 13.2 4.3 ~ 14.4 98
Combination
of
indoor unit
Type of indoor unit
Capacity of each indoor unit
Each capacity (kBtu/h) Total capacity (kBtu/h) Total input (W) Total current (A)
Power
factor (%)
A room B room C room D room A room B room C room D room Rating ( min ~ max ) Rating ( min ~ max ) Rating ( min ~ max ) Rating
