Daikin SUPER MULTI NX G Series User Manual

Specifications EDUS121131
48 SUPER MULTI NX 2/3/4MXS-G/J Series Heat Pump
12+15+15 Wall Wall Duct — 8.42 12.04 12.04 — 32.50 12.00 ~ 34.00 3010 990 ~ 3380 13.4 4.4 ~ 15.0 98
12+15+15 Wall Duct Duct — 8.30 11.85 11.85 — 32.00 12.00 ~ 33.50 3180 1150 ~ 3500 14.1 5.1 ~ 15.5 98
12+15+15 Duct Wall Wall — 8.42 12.04 12.04 — 32.50 11.90 ~ 34.00 2910 900 ~ 3230 12.9 4.0 ~ 14.3 98
12+15+15 Duct Wall Duct — 8.30 11.85 11.85 — 32.00 12.00 ~ 33.50 3070 1060 ~ 3390 13.6 4.7 ~ 15.0 98
12+15+15 Duct Duct Duct — 8.14 11.63 11.63 — 31.40 12.10 ~ 32.90 3250 1220 ~ 3580 14.4 5.4 ~ 15.9 98
12+15+18 Wall Wall Wall — 8.11 11.59 13.90 — 33.60 11.90 ~ 34.50 3020 850 ~ 3180 13.4 3.8 ~ 14.1 98
12+15+18 Wall Wall Duct — 7.96 11.38 13.66 — 33.00 12.00 ~ 34.00 3120 990 ~ 3330 13.8 4.4 ~ 14.8 98
12+15+18 Wall Duct Wall — 7.96 11.38 13.66 — 33.00 11.90 ~ 34.00 3100 990 ~ 3310 13.8 4.4 ~ 14.7 98
12+15+18 Wall Duct Duct — 7.84 11.21 13.45 — 32.50 12.00 ~ 33.50 3280 1150 ~ 3500 14.6 5.1 ~ 15.5 98
12+15+18 Duct Wall Wall — 7.97 11.38 13.67 — 33.00 11.90 ~ 34.00 3000 900 ~ 3210 13.3 4.0 ~ 14.2 98
12+15+18 Duct Wall Duct — 7.84 11.21 13.45 — 32.50 12.00 ~ 33.50 3170 1060 ~ 3390 14.1 4.7 ~ 15.0 98
12+15+18 Duct Duct Wall — 7.84 11.21 13.45 — 32.50 12.00 ~ 33.50 3150 1050 ~ 3360 14.0 4.7 ~ 14.9 98
12+15+18 Duct Duct Duct — 7.70 11.00 13.20 — 31.90 12.10 ~ 32.90 3360 1220 ~ 3580 14.9 5.4 ~ 15.9 98
07+07+07+07 Wall Wall Wall Wall 7.68 7.68 7.68 7.68 30.70 6.70 ~ 33.20 2520 610 ~ 2970 11.2 2.7 ~ 13.2 98
07+07+07+09 Wall Wall Wall Wall 7.29 7.29 7.29 9.13 31.00 6.70 ~ 33.50 2570 610 ~ 2970 11.4 2.7 ~ 13.2 98
07+07+07+09 Wall Wall Wall Duct 7.20 7.20 7.20 9.00 30.60 6.80 ~ 33.10 2590 660 ~ 2990 11.5 2.9 ~ 13.3 98
07+07+07+12 Wall Wall Wall Wall 6.63 6.63 6.63 11.61 31.50 9.60 ~ 34.00 2620 730 ~ 3070 11.6 3.2 ~ 13.6 98
07+07+07+12 Wall Wall Wall Duct 6.55 6.55 6.55 11.45 31.10 9.70 ~ 33.60 2640 790 ~ 3090 11.7 3.5 ~ 13.7 98
07+07+07+15 Wall Wall Wall Wall 5.84 5.84 5.84 14.58 32.10 11.70 ~ 34.50 2710 840 ~ 3180 12.0 3.7 ~ 14.1 98
07+07+07+15 Wall Wall Wall Duct 5.76 5.76 5.76 14.42 31.70 11.80 ~ 34.10 2790 970 ~ 3250 12.4 4.3 ~ 14.4 98
07+07+07+18 Wall Wall Wall Wall 5.43 5.43 5.43 16.31 32.60 11.70 ~ 34.50 2820 850 ~ 3190 12.5 3.8 ~ 14.2 98
07+07+07+18 Wall Wall Wall Duct 5.37 5.37 5.37 16.09 32.20 11.80 ~ 34.10 2890 970 ~ 3250 12.8 4.3 ~ 14.4 98
07+07+09+09 Wall Wall Wall Wall 6.98 6.98 8.72 8.72 31.40 9.60 ~ 33.80 2620 730 ~ 3020 11.6 3.2 ~ 13.4 98
07+07+09+09 Wall Wall Wall Duct 6.89 6.89 8.61 8.61 31.00 9.70 ~ 33.40 2640 790 ~ 3040 11.7 3.5 ~ 13.5 98
07+07+09+09 Wall Wall Duct Duct 6.80 6.80 8.50 8.50 30.60 9.70 ~ 33.00 2680 840 ~ 3130 11.9 3.7 ~ 13.9 98
07+07+09+12 Wall Wall Wall Wall 6.38 6.38 7.98 11.16 31.90 9.60 ~ 34.30 2710 730 ~ 3130 12.0 3.2 ~ 13.9 98
07+07+09+12 Wall Wall Wall Duct 6.30 6.30 7.88 11.02 31.50 9.70 ~ 33.90 2740 790 ~ 3150 12.2 3.5 ~ 14.0 98
07+07+09+12 Wall Wall Duct Wall 6.30 6.30 7.88 11.02 31.50 9.70 ~ 33.90 2740 790 ~ 3150 12.2 3.5 ~ 14.0 98
07+07+09+12 Wall Wall Duct Duct 6.22 6.22 7.78 10.88 31.10 9.70 ~ 33.50 2730 840 ~ 3190 12.1 3.7 ~ 14.2 98
07+07+09+15 Wall Wall Wall Wall 5.63 5.63 7.04 14.10 32.40 11.70 ~ 34.50 2760 840 ~ 3180 12.2 3.7 ~ 14.1 98
07+07+09+15 Wall Wall Wall Duct 5.57 5.57 6.96 13.90 32.00 11.80 ~ 34.10 2840 970 ~ 3250 12.6 4.3 ~ 14.4 98
07+07+09+15 Wall Wall Duct Wall 5.57 5.57 6.96 13.90 32.00 11.80 ~ 34.10 2750 890 ~ 3160 12.2 3.9 ~ 14.0 98
07+07+09+15 Wall Wall Duct Duct 5.50 5.50 6.87 13.73 31.60 11.90 ~ 33.70 2850 1020 ~ 3260 12.6 4.5 ~ 14.5 98
07+07+09+18 Wall Wall Wall Wall 5.26 5.26 6.58 15.80 32.90 11.70 ~ 34.60 2870 850 ~ 3190 12.7 3.8 ~ 14.2 98
07+07+09+18 Wall Wall Wall Duct 5.20 5.20 6.50 15.60 32.50 11.80 ~ 34.20 2940 970 ~ 3250 13.0 4.3 ~ 14.4 98
07+07+09+18 Wall Wall Duct Wall 5.20 5.20 6.50 15.60 32.50 11.80 ~ 34.20 2850 890 ~ 3210 12.6 3.9 ~ 14.2 98
07+07+09+18 Wall Wall Duct Duct 5.14 5.14 6.42 15.40 32.10 11.90 ~ 33.80 2900 1020 ~ 3260 12.9 4.5 ~ 14.5 98
07+07+12+12 Wall Wall Wall Wall 5.89 5.89 10.31 10.31 32.40 11.90 ~ 34.50 2760 840 ~ 3180 12.2 3.7 ~ 14.1 98
07+07+12+12 Wall Wall Wall Duct 5.82 5.82 10.18 10.18 32.00 11.90 ~ 34.10 2790 900 ~ 3250 12.4 4.0 ~ 14.4 98
07+07+12+12 Wall Wall Duct Duct 5.75 5.75 10.05 10.05 31.60 12.00 ~ 33.70 2830 960 ~ 3240 12.6 4.3 ~ 14.4 98
07+07+12+15 Wall Wall Wall Wall 5.26 5.26 9.21 13.17 32.90 11.70 ~ 34.60 2860 840 ~ 3180 12.7 3.7 ~ 14.1 98
07+07+12+15 Wall Wall Wall Duct 5.20 5.20 9.10 13.00 32.50 11.80 ~ 34.20 2940 970 ~ 3250 13.0 4.3 ~ 14.4 98
07+07+12+15 Wall Wall Duct Wall 5.20 5.20 9.10 13.00 32.50 11.80 ~ 34.20 2850 890 ~ 3210 12.6 3.9 ~ 14.2 98
07+07+12+15 Wall Wall Duct Duct 5.14 5.14 8.99 12.83 32.10 11.90 ~ 33.80 2900 1020 ~ 3260 12.9 4.5 ~ 14.5 98
07+07+12+18 Wall Wall Wall Wall 4.95 4.95 8.66 14.84 33.40 11.70 ~ 34.60 2970 850 ~ 3190 13.2 3.8 ~ 14.2 98
07+07+12+18 Wall Wall Wall Duct 4.89 4.89 8.56 14.66 33.00 11.80 ~ 34.20 2990 970 ~ 3250 13.3 4.3 ~ 14.4 98
07+07+12+18 Wall Wall Duct Wall 4.89 4.89 8.56 14.66 33.00 11.80 ~ 34.20 2900 890 ~ 3210 12.9 3.9 ~ 14.2 98
07+07+12+18 Wall Wall Duct Duct 4.83 4.83 8.45 14.49 32.60 11.90 ~ 33.80 3000 1020 ~ 3260 13.3 4.5 ~ 14.5 98
07+09+09+09 Wall Wall Wall Wall 6.68 8.34 8.34 8.34 31.70 9.60 ~ 34.20 2660 730 ~ 3130 11.8 3.2 ~ 13.9 98
07+09+09+09 Wall Wall Wall Duct 6.58 8.24 8.24 8.24 31.30 9.70 ~ 33.80 2690 790 ~ 3150 11.9 3.5 ~ 14.0 98
07+09+09+09 Wall Wall Duct Duct 6.51 8.13 8.13 8.13 30.90 9.70 ~ 33.40 2730 840 ~ 3190 12.1 3.7 ~ 14.2 98
07+09+09+09 Wall Duct Duct Duct 6.41 8.03 8.03 8.03 30.50 9.80 ~ 32.90 2780 900 ~ 3250 12.3 4.0 ~ 14.4 98
07+09+09+12 Wall Wall Wall Wall 6.13 7.67 7.67 10.73 32.20 9.60 ~ 34.50 2760 730 ~ 3180 12.2 3.2 ~ 14.1 98
07+09+09+12 Wall Wall Wall Duct 6.06 7.57 7.57 10.60 31.80 9.70 ~ 34.10 2790 790 ~ 3200 12.4 3.5 ~ 14.2 98
07+09+09+12 Wall Wall Duct Wall 6.06 7.57 7.57 10.60 31.80 9.70 ~ 34.10 2790 790 ~ 3200 12.4 3.5 ~ 14.2 98
07+09+09+12 Wall Wall Duct Duct 5.98 7.48 7.48 10.46 31.40 9.70 ~ 33.70 2780 840 ~ 3240 12.3 3.7 ~ 14.4 98
07+09+09+12 Wall Duct Duct Wall 5.98 7.48 7.48 10.46 31.40 9.70 ~ 33.70 2780 840 ~ 3240 12.3 3.7 ~ 14.4 98
07+09+09+12 Wall Duct Duct Duct 5.90 7.38 7.38 10.34 31.00 9.80 ~ 33.20 2880 900 ~ 3300 12.8 4.0 ~ 14.6 98
07+09+09+15 Wall Wall Wall Wall 5.45 6.81 6.81 13.63 32.70 11.70 ~ 34.50 2810 840 ~ 3180 12.5 3.7 ~ 14.1 98
07+09+09+15 Wall Wall Wall Duct 5.38 6.73 6.73 13.46 32.30 11.80 ~ 34.10 2890 970 ~ 3250 12.8 4.3 ~ 14.4 98
07+09+09+15 Wall Wall Duct Wall 5.38 6.73 6.73 13.46 32.30 11.80 ~ 34.10 2800 890 ~ 3160 12.4 3.9 ~ 14.0 98
Combination
of
indoor unit
Type of indoor unit
Capacity of each indoor unit
Each capacity (kBtu/h) Total capacity (kBtu/h) Total input (W) Total current (A)
Power
factor (%)
A room B room C room D room A room B room C room D room Rating ( min ~ max ) Rating ( min ~ max ) Rating ( min ~ max ) Rating

Daikin SUPER MULTI NX G Series Specifications

General

Brand	Daikin
Model	SUPER MULTI NX G Series
Category	Air Conditioner
Language	English
