Daikin SUPER MULTI NX G Series User Manual

EDUS121131 Specifications
SUPER MULTI NX 2/3/4MXS-G/J Series Heat Pump 31
1
07+09+09+15 Wall Wall Duct Wall 5.13 6.42 6.42 12.83 30.80 15.40 ~ 30.80 3080 940 ~ 3080 15.1 4.6 ~ 15.1 98
07+09+09+15 Wall Wall Duct Duct 4.91 6.15 6.15 12.29 29.50 15.20 ~ 29.50 2810 1070 ~ 2810 13.8 5.2 ~ 13.8 98
07+09+09+15 Wall Duct Duct Wall 5.07 6.33 6.33 12.67 30.40 15.10 ~ 30.40 3170 990 ~ 3170 15.6 4.9 ~ 15.6 98
07+09+09+15 Wall Duct Duct Duct 4.82 6.02 6.02 12.04 28.90 14.80 ~ 28.90 2840 1120 ~ 2840 13.9 5.5 ~ 13.9 98
07+09+09+18 Wall Wall Wall Wall 4.83 6.04 6.04 14.49 31.40 15.80 ~ 31.40 3120 880 ~ 3120 15.3 4.3 ~ 15.3 98
07+09+09+18 Wall Wall Wall Duct 4.64 5.81 5.81 13.94 30.20 15.60 ~ 30.20 2850 1020 ~ 2850 14.0 5.0 ~ 14.0 98
07+09+09+18 Wall Wall Duct Wall 4.77 5.96 5.96 14.31 31.00 15.50 ~ 31.00 3140 940 ~ 3140 15.4 4.6 ~ 15.4 98
07+09+09+18 Wall Wall Duct Duct 4.57 5.71 5.71 13.71 29.70 15.20 ~ 29.70 2870 1070 ~ 2870 14.1 5.2 ~ 14.1 98
07+09+09+18 Wall Duct Duct Wall 4.71 5.88 5.88 14.13 30.60 15.10 ~ 30.60 3170 990 ~ 3170 15.6 4.9 ~ 15.6 98
07+09+09+18 Wall Duct Duct Duct 4.48 5.62 5.62 13.48 29.20 14.80 ~ 29.20 2960 1120 ~ 2960 14.5 5.5 ~ 14.5 98
07+09+12+12 Wall Wall Wall Wall 5.39 6.74 9.43 9.44 31.00 15.40 ~ 31.00 3100 890 ~ 3100 15.2 4.4 ~ 15.2 98
07+09+12+12 Wall Wall Wall Duct 5.36 6.70 9.37 9.37 30.80 15.10 ~ 30.80 3260 950 ~ 3260 16.0 4.7 ~ 16.0 98
07+09+12+12 Wall Wall Duct Duct 5.25 6.57 9.19 9.19 30.20 14.70 ~ 30.20 3280 1000 ~ 3280 16.1 4.9 ~ 16.1 98
07+09+12+12 Wall Duct Wall Wall 5.36 6.70 9.37 9.37 30.80 15.10 ~ 30.80 3260 950 ~ 3260 16.0 4.7 ~ 16.0 98
07+09+12+12 Wall Duct Wall Duct 5.25 6.57 9.19 9.19 30.20 14.70 ~ 30.20 3280 1000 ~ 3280 16.1 4.9 ~ 16.1 98
07+09+12+12 Wall Duct Duct Duct 5.18 6.48 9.07 9.07 29.80 14.20 ~ 29.80 3430 1040 ~ 3430 16.8 5.1 ~ 16.8 98
07+09+12+15 Wall Wall Wall Wall 4.83 6.04 8.45 12.08 31.40 15.80 ~ 31.40 3180 880 ~ 3180 15.6 4.3 ~ 15.6 98
07+09+12+15 Wall Wall Wall Duct 4.65 5.81 8.12 11.62 30.20 15.60 ~ 30.20 2850 1020 ~ 2850 14.0 5.0 ~ 14.0 98
07+09+12+15 Wall Wall Duct Wall 4.77 5.96 8.35 11.92 31.00 15.40 ~ 31.00 3140 940 ~ 3140 15.4 4.6 ~ 15.4 98
07+09+12+15 Wall Wall Duct Duct 4.57 5.71 8.00 11.42 29.70 15.20 ~ 29.70 2870 1070 ~ 2870 14.1 5.2 ~ 14.1 98
07+09+12+15 Wall Duct Wall Wall 4.77 5.96 8.35 11.92 31.00 15.40 ~ 31.00 3140 940 ~ 3140 15.4 4.6 ~ 15.4 98
07+09+12+15 Wall Duct Wall Duct 4.57 5.71 8.00 11.42 29.70 15.20 ~ 29.70 2870 1070 ~ 2870 14.1 5.2 ~ 14.1 98
07+09+12+15 Wall Duct Duct Wall 4.71 5.88 8.24 11.77 30.60 15.10 ~ 30.60 3230 990 ~ 3230 15.8 4.9 ~ 15.8 98
07+09+12+15 Wall Duct Duct Duct 4.49 5.62 7.86 11.23 29.20 14.80 ~ 29.20 2960 1120 ~ 2960 14.5 5.5 ~ 14.5 98
07+12+12+12 Wall Wall Wall Wall 4.97 8.71 8.71 8.71 31.10 15.40 ~ 31.10 3160 890 ~ 3160 15.5 4.4 ~ 15.5 98
07+12+12+12 Wall Wall Wall Duct 4.90 8.60 8.60 8.60 30.70 15.10 ~ 30.70 3260 950 ~ 3260 16.0 4.7 ~ 16.0 98
07+12+12+12 Wall Wall Duct Duct 4.86 8.48 8.48 8.48 30.30 14.70 ~ 30.30 3340 1000 ~ 3340 16.4 4.9 ~ 16.4 98
07+12+12+12 Wall Duct Duct Duct 4.79 8.37 8.37 8.37 29.90 14.20 ~ 29.90 3430 1040 ~ 3430 16.8 5.1 ~ 16.8 98
09+09+09+09 Wall Wall Wall Wall 7.68 7.68 7.68 7.68 30.70 15.40 ~ 30.70 2970 890 ~ 2970 14.6 4.4 ~ 14.6 98
09+09+09+09 Wall Wall Wall Duct 7.55 7.55 7.55 7.55 30.20 12.60 ~ 30.20 2990 800 ~ 2990 14.7 3.9 ~ 14.7 98
09+09+09+09 Wall Wall Duct Duct 7.48 7.48 7.48 7.48 29.90 12.30 ~ 29.90 3140 850 ~ 3140 15.4 4.2 ~ 15.4 98
09+09+09+09 Wall Duct Duct Duct 7.40 7.40 7.40 7.40 29.60 12.00 ~ 29.60 3300 900 ~ 3300 16.2 4.4 ~ 16.2 98
09+09+09+09 Duct Duct Duct Duct 7.28 7.28 7.28 7.28 29.10 11.60 ~ 29.10 3450 950 ~ 3450 16.9 4.7 ~ 16.9 98
09+09+09+12 Wall Wall Wall Wall 7.05 7.05 7.05 9.85 31.00 15.40 ~ 31.00 3100 890 ~ 3100 15.2 4.4 ~ 15.2 98
09+09+09+12 Wall Wall Wall Duct 6.93 6.93 6.93 9.71 30.50 15.10 ~ 30.50 3120 950 ~ 3120 15.3 4.7 ~ 15.3 98
09+09+09+12 Wall Wall Duct Wall 6.93 6.93 6.93 9.71 30.50 15.10 ~ 30.50 3120 950 ~ 3120 15.3 4.7 ~ 15.3 98
09+09+09+12 Wall Wall Duct Duct 6.84 6.84 6.84 9.58 30.10 14.70 ~ 30.10 3210 1000 ~ 3210 15.7 4.9 ~ 15.7 98
09+09+09+12 Wall Duct Duct Wall 6.84 6.84 6.84 9.58 30.10 14.70 ~ 30.10 3210 1000 ~ 3210 15.7 4.9 ~ 15.7 98
09+09+09+12 Wall Duct Duct Duct 6.75 6.75 6.75 9.45 29.70 14.20 ~ 29.70 3360 1040 ~ 3360 16.5 5.1 ~ 16.5 98
09+09+09+12 Duct Duct Duct Wall 6.75 6.75 6.75 9.45 29.70 14.20 ~ 29.70 3360 1040 ~ 3360 16.5 5.1 ~ 16.5 98
09+09+09+12 Duct Duct Duct Duct 6.68 6.68 6.68 9.36 29.40 13.70 ~ 29.40 3580 1090 ~ 3580 17.6 5.3 ~ 17.6 98
09+09+09+15 Wall Wall Wall Wall 6.22 6.22 6.22 12.44 31.10 15.80 ~ 31.10 2980 880 ~ 2980 14.6 4.3 ~ 14.6 98
09+09+09+15 Wall Wall Wall Duct 6.14 6.14 6.14 12.28 30.70 15.60 ~ 30.70 3040 1020 ~ 3040 14.9 5.0 ~ 14.9 98
09+09+09+15 Wall Wall Duct Wall 6.14 6.14 6.14 12.28 30.70 15.40 ~ 30.70 3010 940 ~ 3010 14.8 4.6 ~ 14.8 98
09+09+09+15 Wall Wall Duct Duct 6.06 6.06 6.06 12.12 30.30 15.20 ~ 30.30 3130 1070 ~ 3130 15.4 5.2 ~ 15.4 98
09+09+09+15 Wall Duct Duct Wall 6.06 6.06 6.06 12.12 30.30 15.10 ~ 30.30 3100 990 ~ 3100 15.2 4.9 ~ 15.2 98
09+09+09+15 Wall Duct Duct Duct 5.98 5.98 5.98 11.96 29.90 14.80 ~ 29.90 3150 1120 ~ 3150 15.5 5.5 ~ 15.5 98
09+09+09+15 Duct Duct Duct Wall 5.98 5.98 5.98 11.96 29.90 14.70 ~ 29.90 3190 1040 ~ 3190 15.6 5.1 ~ 15.6 98
09+09+09+15 Duct Duct Duct Duct 5.90 5.90 5.90 11.80 29.50 14.40 ~ 29.50 3310 1170 ~ 3310 16.2 5.7 ~ 16.2 98
09+09+09+18 Wall Wall Wall Wall 5.81 5.81 5.81 13.97 31.40 15.80 ~ 31.40 3120 880 ~ 3120 15.3 4.3 ~ 15.3 98
09+09+09+18 Wall Wall Wall Duct 5.74 5.74 5.74 13.78 31.00 15.60 ~ 31.00 3170 1020 ~ 3170 15.6 5.0 ~ 15.6 98
09+09+09+18 Wall Wall Duct Wall 5.74 5.74 5.74 13.78 31.00 15.50 ~ 31.00 3140 940 ~ 3140 15.4 4.6 ~ 15.4 98
09+09+09+18 Wall Wall Duct Duct 5.67 5.67 5.67 13.59 30.60 15.20 ~ 30.60 3190 1070 ~ 3190 15.6 5.2 ~ 15.6 98
09+09+09+18 Wall Duct Duct Wall 5.67 5.67 5.67 13.59 30.60 15.10 ~ 30.60 3170 990 ~ 3170 15.6 4.9 ~ 15.6 98
09+09+09+18 Wall Duct Duct Duct 5.59 5.59 5.59 13.43 30.20 14.80 ~ 30.20 3280 1120 ~ 3280 16.1 5.5 ~ 16.1 98
09+09+09+18 Duct Duct Duct Wall 5.59 5.59 5.59 13.43 30.20 14.70 ~ 30.20 3260 1040 ~ 3260 16.0 5.1 ~ 16.0 98
09+09+09+18 Duct Duct Duct Duct 5.52 5.52 5.52 13.24 29.80 14.40 ~ 29.80 3440 1170 ~ 3440 16.9 5.7 ~ 16.9 98
09+09+12+12 Wall Wall Wall Wall 6.48 6.48 9.07 9.07 31.10 15.40 ~ 31.10 3160 890 ~ 3160 15.5 4.4 ~ 15.5 98
09+09+12+12 Wall Wall Wall Duct 6.42 6.42 8.98 8.98 30.80 15.10 ~ 30.80 3260 950 ~ 3260 16.0 4.7 ~ 16.0 98
09+09+12+12 Wall Wall Duct Duct 6.33 6.33 8.87 8.87 30.40 14.70 ~ 30.40 3340 1000 ~ 3340 16.4 4.9 ~ 16.4 98
09+09+12+12 Wall Duct Wall Wall 6.42 6.42 8.98 8.98 30.80 15.10 ~ 30.80 3260 950 ~ 3260 16.0 4.7 ~ 16.0 98
Combination
of
indoor unit
Type of indoor unit
Capacity of each indoor unit
Each capacity (kBtu/h) Total capacity (kBtu/h) Total input (W) Total current (A)
Power
factor (%)
A room B room C room D room A room B room C room D room Rating (min ~ max) Rating (min ~ max) Rating (min ~ max) Rating

Daikin SUPER MULTI NX G Series Specifications

General

Brand	Daikin
Model	SUPER MULTI NX G Series
Category	Air Conditioner
Language	English
