Daikin SUPER MULTI NX G Series User Manual

EDUS121131 Specifications
SUPER MULTI NX 2/3/4MXS-G/J Series Heat Pump 25
1
07+07+12 Wall Wall Duct — 7.95 7.95 13.90 — 29.80 7.00 ~ 30.00 2850 720 ~ 2850 12.6 3.2 ~ 12.6 98
07+07+15 Wall Wall Wall — 6.67 6.67 16.66 — 30.00 9.80 ~ 30.70 2520 760 ~ 2610 11.2 3.4 ~ 11.6 98
07+07+15 Wall Wall Duct — 6.67 6.67 16.66 — 30.00 9.80 ~ 30.20 2740 920 ~ 2790 12.2 4.1 ~ 12.4 98
07+07+18 Wall Wall Wall — 6.00 6.00 18.00 — 30.00 9.70 ~ 31.10 2500 750 ~ 2690 11.1 3.3 ~ 11.9 98
07+07+18 Wall Wall Duct — 6.00 6.00 18.00 — 30.00 9.80 ~ 30.80 2740 920 ~ 2890 12.2 4.1 ~ 12.8 98
07+09+09 Wall Wall Wall — 8.58 10.71 10.71 — 30.00 5.80 ~ 30.00 2710 600 ~ 2710 12.0 2.7 ~ 12.0 98
07+09+09 Wall Wall Duct — 8.48 10.61 10.61 — 29.70 5.80 ~ 30.00 2850 660 ~ 2850 12.6 2.9 ~ 12.6 98
07+09+09 Wall Duct Duct — 8.34 10.43 10.43 — 29.20 5.90 ~ 29.50 2950 720 ~ 2950 13.1 3.2 ~ 13.1 98
07+09+12 Wall Wall Wall — 7.50 9.38 13.12 — 30.00 7.00 ~ 30.40 2710 650 ~ 2760 12.0 2.9 ~ 12.2 98
07+09+12 Wall Wall Duct — 7.50 9.38 13.12 — 30.00 7.00 ~ 30.20 2850 720 ~ 2900 12.6 3.2 ~ 12.9 98
07+09+12 Wall Duct Wall — 7.50 9.38 13.12 — 30.00 7.00 ~ 30.20 2850 720 ~ 2900 12.6 3.2 ~ 12.9 98
07+09+12 Wall Duct Duct — 7.40 9.25 12.95 — 29.60 7.10 ~ 29.80 3010 790 ~ 3010 13.4 3.5 ~ 13.4 98
07+09+15 Wall Wall Wall — 6.32 7.89 15.79 — 30.00 9.80 ~ 30.90 2520 760 ~ 2660 11.2 3.4 ~ 11.8 98
07+09+15 Wall Wall Duct — 6.32 7.89 15.79 — 30.00 9.80 ~ 30.40 2740 920 ~ 2840 12.2 4.1 ~ 12.6 98
07+09+15 Wall Duct Wall — 6.32 7.89 15.79 — 30.00 9.80 ~ 30.40 2630 820 ~ 2730 11.7 3.6 ~ 12.1 98
07+09+15 Wall Duct Duct — 6.32 7.89 15.79 — 30.00 9.90 ~ 30.00 2870 980 ~ 2920 12.7 4.3 ~ 13.0 98
07+09+18 Wall Wall Wall — 5.71 7.14 17.15 — 30.00 9.70 ~ 31.30 2500 750 ~ 2690 11.1 3.3 ~ 11.9 98
07+09+18 Wall Wall Duct — 5.71 7.14 17.15 — 30.00 9.80 ~ 30.70 2740 920 ~ 2890 12.2 4.1 ~ 12.8 98
07+09+18 Wall Duct Wall — 5.71 7.14 17.15 — 30.00 9.80 ~ 30.70 2600 820 ~ 2750 11.5 3.6 ~ 12.2 98
07+09+18 Wall Duct Duct — 5.71 7.14 17.15 — 30.00 9.90 ~ 30.30 2870 980 ~ 2970 12.7 4.3 ~ 13.2 98
07+12+12 Wall Wall Wall — 6.66 11.67 11.67 — 30.00 9.90 ~ 30.70 2710 800 ~ 2810 12.0 3.5 ~ 12.5 98
07+12+12 Wall Wall Duct — 6.66 11.67 11.67 — 30.00 9.90 ~ 30.30 2850 870 ~ 2900 12.6 3.9 ~ 12.9 98
07+12+12 Wall Duct Duct — 6.66 11.67 11.67 — 30.00 10.00 ~ 30.00 3060 950 ~ 3060 13.6 4.2 ~ 13.6 98
07+12+15 Wall Wall Wall — 5.71 10.00 14.29 — 30.00 9.80 ~ 31.30 2520 760 ~ 2710 11.2 3.4 ~ 12.0 98
07+12+15 Wall Wall Duct — 5.71 10.00 14.29 — 30.00 9.80 ~ 30.70 2740 920 ~ 2890 12.2 4.1 ~ 12.8 98
07+12+15 Wall Duct Wall — 5.71 10.00 14.29 — 30.00 9.80 ~ 30.70 2630 820 ~ 2780 11.7 3.6 ~ 12.3 98
07+12+15 Wall Duct Duct — 5.71 10.00 14.29 — 30.00 9.90 ~ 30.30 2870 980 ~ 2970 12.7 4.3 ~ 13.2 98
07+12+18 Wall Wall Wall — 5.22 9.13 15.65 — 30.00 12.00 ~ 31.60 2500 870 ~ 2740 11.1 3.9 ~ 12.2 98
07+12+18 Wall Wall Duct — 5.22 9.13 15.65 — 30.00 12.10 ~ 31.30 2740 1040 ~ 2990 12.2 4.6 ~ 13.3 98
07+12+18 Wall Duct Wall — 5.22 9.13 15.65 — 30.00 12.00 ~ 31.30 2600 930 ~ 2850 11.5 4.1 ~ 12.6 98
07+12+18 Wall Duct Duct — 5.22 9.13 15.65 — 30.00 12.10 ~ 30.90 2870 1110 ~ 3080 12.7 4.9 ~ 13.7 98
07+15+15 Wall Wall Wall — 5.00 12.50 12.50 — 30.00 11.90 ~ 31.80 2440 850 ~ 2680 10.8 3.8 ~ 11.9 98
07+15+15 Wall Wall Duct — 5.00 12.50 12.50 — 30.00 12.00 ~ 31.40 2610 990 ~ 2810 11.6 4.4 ~ 12.5 98
07+15+15 Wall Duct Duct — 5.00 12.50 12.50 — 30.00 12.00 ~ 31.00 2820 1150 ~ 3020 12.5 5.1 ~ 13.4 98
09+09+09 Wall Wall Wall — 10.00 10.00 10.00 — 30.00 7.00 ~ 30.20 2710 650 ~ 2710 12.0 2.9 ~ 12.0 98
09+09+09 Wall Wall Duct — 10.00 10.00 10.00 — 30.00 7.00 ~ 30.00 2850 720 ~ 2850 12.6 3.2 ~ 12.6 98
09+09+09 Wall Duct Duct — 9.83 9.83 9.83 — 29.50 7.10 ~ 29.70 2950 790 ~ 3010 13.1 3.5 ~ 13.4 98
09+09+09 Duct Duct Duct — 9.67 9.67 9.67 — 29.00 7.20 ~ 29.20 3070 860 ~ 3130 13.6 3.8 ~ 13.9 98
09+09+12 Wall Wall Wall — 8.82 8.82 12.36 — 30.00 7.00 ~ 30.50 2710 650 ~ 2810 12.0 2.9 ~ 12.5 98
09+09+12 Wall Wall Duct — 8.82 8.82 12.36 — 30.00 7.00 ~ 30.20 2850 720 ~ 2900 12.6 3.2 ~ 12.9 98
09+09+12 Wall Duct Wall — 8.82 8.82 12.36 — 30.00 7.00 ~ 30.20 2850 720 ~ 2900 12.6 3.2 ~ 12.9 98
09+09+12 Wall Duct Duct — 8.82 8.82 12.36 — 30.00 7.10 ~ 30.00 3060 790 ~ 3060 13.6 3.5 ~ 13.6 98
09+09+12 Duct Duct Wall — 8.82 8.82 12.36 — 30.00 7.10 ~ 30.00 3060 790 ~ 3060 13.6 3.5 ~ 13.6 98
09+09+12 Duct Duct Duct — 8.68 8.68 12.14 — 29.50 7.20 ~ 29.70 3180 860 ~ 3240 14.1 3.8 ~ 14.4 98
09+09+15 Wall Wall Wall — 7.50 7.50 15.00 — 30.00 9.80 ~ 31.10 2520 760 ~ 2710 11.2 3.4 ~ 12.0 98
09+09+15 Wall Wall Duct — 7.50 7.50 15.00 — 30.00 9.80 ~ 30.60 2740 920 ~ 2890 12.2 4.1 ~ 12.8 98
09+09+15 Wall Duct Wall — 7.50 7.50 15.00 — 30.00 9.80 ~ 30.60 2630 820 ~ 2730 11.7 3.6 ~ 12.1 98
09+09+15 Wall Duct Duct — 7.50 7.50 15.00 — 30.00 9.90 ~ 30.20 2870 980 ~ 2970 12.7 4.3 ~ 13.2 98
09+09+15 Duct Duct Wall — 7.50 7.50 15.00 — 30.00 9.90 ~ 30.20 2800 890 ~ 2850 12.4 3.9 ~ 12.6 98
09+09+15 Duct Duct Duct — 7.50 7.50 15.00 — 30.00 10.00 ~ 30.00 3070 1060 ~ 3120 13.6 4.7 ~ 13.8 98
09+09+18 Wall Wall Wall — 6.82 6.82 16.36 — 30.00 12.00 ~ 31.50 2500 870 ~ 2740 11.1 3.9 ~ 12.2 98
09+09+18 Wall Wall Duct — 6.82 6.82 16.36 — 30.00 12.10 ~ 31.20 2740 1040 ~ 2990 12.2 4.6 ~ 13.3 98
09+09+18 Wall Duct Wall — 6.82 6.82 16.36 — 30.00 12.00 ~ 31.20 2600 930 ~ 2800 11.5 4.1 ~ 12.4 98
09+09+18 Wall Duct Duct — 6.82 6.82 16.36 — 30.00 12.10 ~ 30.80 2870 1110 ~ 3080 12.7 4.9 ~ 13.7 98
09+09+18 Duct Duct Wall — 6.82 6.82 16.36 — 30.00 12.10 ~ 30.80 2770 1000 ~ 2870 12.3 4.4 ~ 12.7 98
09+09+18 Duct Duct Duct — 6.82 6.82 16.36 — 30.00 12.20 ~ 30.10 3070 1190 ~ 3120 13.6 5.3 ~ 13.8 98
09+12+12 Wall Wall Wall — 7.90 11.05 11.05 — 30.00 9.90 ~ 30.90 2710 800 ~ 2860 12.0 3.5 ~ 12.7 98
09+12+12 Wall Wall Duct — 7.90 11.05 11.05 — 30.00 9.90 ~ 30.60 2850 870 ~ 3010 12.6 3.9 ~ 13.4 98
09+12+12 Wall Duct Duct — 7.90 11.05 11.05 — 30.00 10.00 ~ 30.20 3060 950 ~ 3120 13.6 4.2 ~ 13.8 98
09+12+12 Duct Wall Wall — 7.90 11.05 11.05 — 30.00 9.90 ~ 30.60 2850 870 ~ 3010 12.6 3.9 ~ 13.4 98
09+12+12 Duct Wall Duct — 7.90 11.05 11.05 — 30.00 10.00 ~ 30.20 3060 950 ~ 3120 13.6 4.2 ~ 13.8 98
Combination
of
indoor unit
Type of indoor unit
Capacity of each indoor unit
Each capacity (kBtu/h) Total capacity (kBtu/h) Total input (W) Total current (A)
Power
factor (%)
A room B room C room — A room B room C room — Rating ( min ~ max ) Rating ( min ~ max ) Rating ( min ~ max ) Rating
