Daikin SUPER MULTI NX G Series User Manual

Specifications EDUS121131
26 SUPER MULTI NX 2/3/4MXS-G/J Series Heat Pump
09+12+12 Duct Duct Duct — 7.90 11.05 11.05 — 30.00 10.10 ~ 30.00 3300 1030 ~ 3300 14.6 4.6 ~ 14.6 98
09+12+15 Wall Wall Wall — 6.82 9.55 13.63 — 30.00 12.00 ~ 31.50 2520 880 ~ 2760 11.2 3.9 ~ 12.2 98
09+12+15 Wall Wall Duct — 6.82 9.55 13.63 — 30.00 12.10 ~ 31.20 2740 1040 ~ 2990 12.2 4.6 ~ 13.3 98
09+12+15 Wall Duct Wall — 6.82 9.55 13.63 — 30.00 12.10 ~ 31.20 2630 940 ~ 2830 11.7 4.2 ~ 12.6 98
09+12+15 Wall Duct Duct — 6.82 9.55 13.63 — 30.00 12.10 ~ 30.80 2870 1110 ~ 3080 12.7 4.9 ~ 13.7 98
09+12+15 Duct Wall Wall — 6.82 9.55 13.63 — 30.00 12.10 ~ 31.20 2630 940 ~ 2830 11.7 4.2 ~ 12.6 98
09+12+15 Duct Wall Duct — 6.82 9.55 13.63 — 30.00 12.10 ~ 30.80 2870 1110 ~ 3080 12.7 4.9 ~ 13.7 98
09+12+15 Duct Duct Wall — 6.82 9.55 13.63 — 30.00 12.10 ~ 30.80 2800 1020 ~ 2960 12.4 4.5 ~ 13.1 98
09+12+15 Duct Duct Duct — 6.82 9.55 13.63 — 30.00 12.20 ~ 30.30 3070 1190 ~ 3170 13.6 5.3 ~ 14.1 98
09+12+18 Wall Wall Wall — 6.25 8.75 15.00 — 30.00 12.00 ~ 31.80 2500 870 ~ 2790 11.1 3.9 ~ 12.4 98
09+12+18 Wall Wall Duct — 6.25 8.75 15.00 — 30.00 12.10 ~ 31.50 2740 1040 ~ 3040 12.2 4.6 ~ 13.5 98
09+12+18 Wall Duct Wall — 6.25 8.75 15.00 — 30.00 12.00 ~ 31.50 2600 930 ~ 2850 11.5 4.1 ~ 12.6 98
09+12+18 Wall Duct Duct — 6.25 8.75 15.00 — 30.00 12.10 ~ 31.10 2870 1110 ~ 3130 12.7 4.9 ~ 13.9 98
09+12+18 Duct Wall Wall — 6.25 8.75 15.00 — 30.00 12.00 ~ 31.50 2600 930 ~ 2850 11.5 4.1 ~ 12.6 98
09+12+18 Duct Wall Duct — 6.25 8.75 15.00 — 30.00 12.10 ~ 31.10 2870 1110 ~ 3130 12.7 4.9 ~ 13.9 98
09+12+18 Duct Duct Wall — 6.25 8.75 15.00 — 30.00 12.10 ~ 31.10 2770 1000 ~ 2920 12.3 4.4 ~ 13.0 98
09+12+18 Duct Duct Duct — 6.25 8.75 15.00 — 30.00 12.20 ~ 30.70 3070 1190 ~ 3230 13.6 5.3 ~ 14.3 98
09+15+15 Wall Wall Wall — 6.00 12.00 12.00 — 30.00 11.90 ~ 32.00 2440 850 ~ 2730 10.8 3.8 ~ 12.1 98
09+15+15 Wall Wall Duct — 6.00 12.00 12.00 — 30.00 12.00 ~ 31.50 2610 990 ~ 2860 11.6 4.4 ~ 12.7 98
09+15+15 Wall Duct Duct — 6.00 12.00 12.00 — 30.00 12.00 ~ 31.50 2820 1150 ~ 3070 12.5 5.1 ~ 13.6 98
09+15+15 Duct Wall Wall — 6.00 12.00 12.00 — 30.00 11.90 ~ 31.50 2510 900 ~ 2760 11.1 4.0 ~ 12.2 98
09+15+15 Duct Wall Duct — 6.00 12.00 12.00 — 30.00 12.00 ~ 31.50 2720 1060 ~ 2960 12.1 4.7 ~ 13.1 98
09+15+15 Duct Duct Duct — 6.00 12.00 12.00 — 30.00 12.10 ~ 31.20 2940 1220 ~ 3200 13.0 5.4 ~ 14.2 98
12+12+12 Wall Wall Wall — 10.00 10.00 10.00 — 30.00 9.90 ~ 31.30 2710 800 ~ 2920 12.0 3.5 ~ 13.0 98
12+12+12 Wall Wall Duct — 10.00 10.00 10.00 — 30.00 9.90 ~ 31.00 2850 870 ~ 3060 12.6 3.9 ~ 13.6 98
12+12+12 Wall Duct Duct — 10.00 10.00 10.00 — 30.00 10.00 ~ 30.40 3060 950 ~ 3170 13.6 4.2 ~ 14.1 98
12+12+12 Duct Duct Duct — 10.00 10.00 10.00 — 30.00 10.10 ~ 30.20 3300 1030 ~ 3350 14.6 4.6 ~ 14.9 98
12+12+15 Wall Wall Wall — 8.75 8.75 12.50 — 30.00 12.00 ~ 31.80 2520 880 ~ 2810 11.2 3.9 ~ 12.5 98
12+12+15 Wall Wall Duct — 8.75 8.75 12.50 — 30.00 12.10 ~ 31.50 2740 1040 ~ 3040 12.2 4.6 ~ 13.5 98
12+12+15 Wall Duct Wall — 8.75 8.75 12.50 — 30.00 12.10 ~ 31.50 2630 940 ~ 2930 11.7 4.2 ~ 13.0 98
12+12+15 Wall Duct Duct — 8.75 8.75 12.50 — 30.00 12.10 ~ 31.10 2870 1110 ~ 3130 12.7 4.9 ~ 13.9 98
12+12+15 Duct Duct Wall — 8.75 8.75 12.50 — 30.00 12.10 ~ 31.10 2800 1020 ~ 3010 12.4 4.5 ~ 13.4 98
12+12+15 Duct Duct Duct — 8.75 8.75 12.50 — 30.00 12.20 ~ 30.70 3070 1190 ~ 3230 13.6 5.3 ~ 14.3 98
Combination
of
indoor unit
Type of indoor unit
Capacity of each indoor unit
Each capacity (kBtu/h) Total capacity (kBtu/h) Total input (W) Total current (A)
Power
factor (%)
A room B room C room — A room B room C room — Rating ( min ~ max ) Rating ( min ~ max ) Rating ( min ~ max ) Rating
Note:
1. Cooling capacity is based on 80°FDB (26.7°CDB) / 67°FWB (19.4°CWB) (Indoor temperature), 95°FDB
(35°CDB) / 75°FWB (24°CWB) (Outdoor temperature).
Heating capacity is based on 70°FDB (21°CDB) / 60°FWB (15.6°CWB) (Indoor temperature), 47°FDB
(8.3°CDB) / 43°FWB (6°CWB) (Outdoor temperature).
2. The total ability of connected indoor units is up to 39.0 kBtu/h.
3. It is impossible to connect only one indoor unit.
4. Wall type of indoor unit: CTXS-L, FTXS-L series
Duct type of indoor unit: CDXS-L, FDXS-L series
3D078967
3D078968
3D078969
3D078970
