Daikin SUPER MULTI NX G Series User Manual

Capacity Tables EDUS121131
70 SUPER MULTI NX 2/3/4MXS-G/J Series Heat Pump
FTXS15L 68.0 16.60 1.15 17.34 1.17 18.09 1.19 18.46 1.21 19.58 1.24 20.33 1.26
77.0 15.84 1.22 16.59 1.24 17.34 1.26 17.71 1.27 18.83 1.31 19.57 1.33
86.0 15.09 1.29 15.83 1.32 16.58 1.34 16.95 1.35 18.07 1.38 18.82 1.41
89.6 14.79 1.32 15.53 1.35 16.28 1.37 16.65 1.38 17.77 1.42 18.52 1.44
95.0 14.33 1.37 15.08 1.40 15.83 1.42
16.20 1.43 17.32 1.47 18.07 1.49
104.0 13.58 1.46 14.33 1.49 15.07 1.51 15.45 1.52 16.57 1.55 17.31 1.58
109.4 13.13 1.52 13.87 1.54 14.62 1.56 14.99 1.58 16.11 1.61 16.86 1.63
114.8 9.11 0.98 9.51 0.98 9.89 0.98 10.08 0.98 10.63 0.98 10.98 0.98
CDXS15L 68.0 14.36 1.09 16.17 1.24 16.86 1.26 17.21 1.27 18.25 1.31 18.95 1.33
77.0 14.36 1.23 15.46 1.31 16.16 1.33 16.51 1.35 17.55 1.38 18.25 1.41
86.0 14.06 1.37 14.76 1.39 15.46 1.41 15.80 1.43 16.85 1.46 17.54 1.49
89.6 13.78 1.40 14.48 1.42 15.17 1.45 15.52 1.46 16.57 1.50 17.26 1.52
95.0 13.36 1.45 14.06 1.48 14.75 1.50
15.10 1.51 16.14 1.55 16.84 1.57
104.0 12.66 1.54 13.35 1.57 14.05 1.59 14.40 1.60 15.44 1.64 16.14 1.66
109.4 12.24 1.60 12.93 1.63 13.63 1.65 13.98 1.66 15.02 1.70 15.71 1.72
114.8 8.36 0.98 8.72 0.98 9.06 0.98 9.23 0.98 9.73 0.98 10.05 0.98
FTXS18L 68.0 19.12 1.46 20.88 1.60 21.77 1.63 22.22 1.64 23.57 1.69 24.47 1.72
77.0 19.07 1.66 19.97 1.69 20.87 1.72 21.32 1.74 22.66 1.78 23.56 1.82
86.0 18.16 1.76 19.06 1.79 19.96 1.83 20.41 1.84 21.76 1.89 22.65 1.92
89.6 17.80 1.81 18.70 1.84 19.60 1.87 20.04 1.88 21.39 1.93 22.29 1.96
95.0 17.25 1.87 18.15 1.91 19.05 1.94
19.50 1.95 20.85 2.00 21.75 2.03
104.0 16.35 1.99 17.24 2.03 18.14 2.06 18.59 2.07 19.94 2.12 20.84 2.15
109.4 14.61 1.77 15.28 1.77 15.93 1.77 16.25 1.77 17.20 1.77 17.80 1.77
114.8 9.34 0.98 9.71 0.98 10.07 0.98 10.24 0.98 10.76 0.98 11.10 0.98
CDXS18L 68.0 14.16 1.04 17.39 1.35 20.21 1.64 20.63 1.65 21.88 1.70 22.71 1.73
77.0 14.16 1.17 17.39 1.53 19.37 1.73 19.79 1.75 21.04 1.79 21.87 1.83
86.0 14.16 1.33 17.39 1.75 18.53 1.83 18.94 1.85 20.19 1.90 21.03 1.93
89.6 14.16 1.40 17.35 1.85 18.19 1.88 18.61 1.89 19.86 1.94 20.69 1.97
95.0 14.16 1.52 16.85 1.92 17.68 1.95
18.10 1.96 19.35 2.01 20.18 2.04
104.0 14.16 1.77 16.01 2.04 16.84 2.07 17.26 2.08 18.51 2.13 19.34 2.16
109.4 13.61 1.77 14.24 1.77 14.85 1.77 15.15 1.77 16.04 1.77 16.61 1.77
114.8 8.82 0.98 9.17 0.98 9.51 0.98 9.67 0.98 10.16 0.98 10.48 0.98
CTXS07L +
CTXS07L
68.0 17.01 1.05 17.77 1.07 18.54 1.09 18.92 1.10 20.07 1.14 20.83 1.16
77.0 16.23 1.12 17.00 1.14 17.76 1.16 18.15 1.17 19.29 1.20 20.06 1.22
86.0 15.46 1.18 16.23 1.21 16.99 1.23 17.37 1.24 18.52 1.27 19.28 1.29
89.6 15.15 1.21 15.92 1.23 16.68 1.26 17.06 1.27 18.21 1.30 18.98 1.32
95.0 14.69 1.26 15.45 1.28 16.22 1.30
16.60 1.31 17.75 1.34 18.51 1.36
104.0 13.92 1.34 14.68 1.36 15.44 1.38 15.83 1.39 16.97 1.42 17.74 1.44
109.4 13.45 1.39 14.22 1.41 14.98 1.43 15.36 1.44 16.51 1.47 17.28 1.50
114.8 9.79 0.98 10.22 0.98 10.63 0.98 10.84 0.98 11.44 0.98 11.83 0.98
CTXS07L +
CTXS09H
68.0 18.65 1.19 19.48 1.21 20.32 1.24 20.74 1.25 22.00 1.28 22.84 1.31
77.0 17.80 1.26 18.64 1.28 19.48 1.31 19.89 1.32 21.15 1.35 21.99 1.38
86.0 16.95 1.34 17.79 1.36 18.63 1.39 19.05 1.40 20.31 1.43 21.14 1.46
89.6 16.61 1.37 17.45 1.39 18.29 1.42 18.71 1.43 19.97 1.47 20.80 1.49
95.0 16.10 1.42 16.94 1.45 17.78 1.47
18.20 1.48 19.46 1.52 20.30 1.54
104.0 15.26 1.51 16.09 1.54 16.93 1.56 17.35 1.57 18.61 1.61 19.45 1.63
109.4 14.75 1.57 15.59 1.59 16.42 1.62 16.84 1.63 18.10 1.67 18.94 1.69
114.8 9.90 0.98 10.32 0.98 10.74 0.98 10.94 0.98 11.53 0.98 11.92 0.98
Combination
(Capacity)
Outdoor air
temp.
EDB (°F)
Indoor air temp. EWB (°F)
57.2 60.8 64.4 67.0 71.6 75.2
TC PI TC PI TC PI TC PI TC PI TC PI
kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW
