Daikin SUPER MULTI NX G Series User Manual

EDUS121131 Capacity Tables
SUPER MULTI NX 2/3/4MXS-G/J Series Heat Pump 71
1
CTXS07L +
FDXS09L
68.0 17.01 1.14 17.77 1.16 18.54 1.19 18.92 1.20 20.07 1.23 20.83 1.25
77.0 16.23 1.21 17.00 1.23 17.76 1.25 18.15 1.27 19.29 1.30 20.06 1.32
86.0 15.46 1.28 16.23 1.31 16.99 1.33 17.37 1.34 18.52 1.37 19.28 1.40
89.6 15.15 1.32 15.92 1.34 16.68 1.36 17.06 1.37 18.21 1.41 18.98 1.43
95.0 14.69 1.36 15.45 1.39 16.22 1.41
16.60 1.42 17.75 1.46 18.51 1.48
104.0 13.92 1.45 14.68 1.47 15.44 1.50 15.83 1.51 16.97 1.54 17.74 1.57
109.4 13.45 1.51 14.22 1.53 14.98 1.55 15.36 1.56 16.51 1.60 17.28 1.62
114.8 9.34 0.98 9.75 0.98 10.14 0.98 10.33 0.98 10.90 0.98 11.26 0.98
CTXS07L +
CTXS12H
68.0 21.82 1.53 22.80 1.56 23.78 1.59 24.28 1.60 25.75 1.65 26.73 1.68
77.0 20.83 1.62 21.81 1.65 22.79 1.68 23.28 1.69 24.76 1.74 25.74 1.77
86.0 19.84 1.72 20.82 1.75 21.80 1.78 22.29 1.79 23.76 1.84 24.75 1.87
89.6 19.44 1.76 20.42 1.79 21.40 1.82 21.90 1.84 23.37 1.88 24.35 1.91
95.0 18.85 1.83 19.83 1.86 20.81 1.89
21.30 1.90 22.77 1.95 23.75 1.98
104.0 17.85 1.94 18.84 1.97 19.82 2.00 20.31 2.02 21.78 2.06 22.76 2.09
109.4 16.06 1.77 16.79 1.77 17.51 1.77 17.86 1.77 18.89 1.77 19.55 1.77
114.8 10.07 0.98 10.48 0.98 10.87 0.98 11.07 0.98 11.63 0.98 12.00 0.98
CTXS07L +
FDXS12L
68.0 20.29 1.51 21.20 1.54 22.11 1.57 22.57 1.58 23.93 1.63 24.85 1.66
77.0 19.36 1.60 20.28 1.63 21.19 1.66 21.64 1.68 23.01 1.72 23.92 1.75
86.0 18.44 1.70 19.35 1.73 20.27 1.76 20.72 1.77 22.09 1.82 23.00 1.85
89.6 18.07 1.74 18.98 1.77 19.90 1.80 20.35 1.82 21.72 1.86 22.63 1.89
95.0 17.52 1.81 18.43 1.84 19.34 1.87
19.80 1.88 21.17 1.93 22.08 1.96
104.0 16.60 1.92 17.51 1.95 18.42 1.98 18.88 2.00 20.25 2.04 21.16 2.07
109.4 15.06 1.77 15.76 1.77 16.43 1.77 16.77 1.77 17.74 1.77 18.37 1.77
114.8 9.55 0.98 9.94 0.98 10.31 0.98 10.49 0.98 11.03 0.98 11.38 0.98
CTXS07L +
FTXS15L
68.0 24.38 1.76 25.48 1.79 26.58 1.83 27.12 1.85 28.77 1.90 29.87 1.93
77.0 23.28 1.86 24.37 1.90 25.47 1.93 26.02 1.95 27.66 2.00 28.76 2.04
86.0 22.17 1.98 23.26 2.01 24.36 2.05 24.91 2.07 26.55 2.12 27.65 2.15
89.6 21.72 2.03 22.82 2.06 23.92 2.10 24.46 2.12 26.11 2.17 27.21 2.20
95.0 21.06 2.10 22.16 2.14 23.25 2.17
23.80 2.19 25.44 2.24 26.54 2.28
104.0 19.95 2.24 21.05 2.27 22.14 2.31 22.69 2.33 24.34 2.38 25.43 2.41
109.4 16.71 1.77 17.44 1.77 18.15 1.77 18.51 1.77 19.53 1.77 20.20 1.77
114.8 10.48 0.98 10.88 0.98 11.27 0.98 11.47 0.98 12.03 0.98 12.40 0.98
CTXS07L +
CDXS15L
68.0 23.15 1.77 24.20 1.80 25.24 1.84 25.76 1.85 27.32 1.91 28.36 1.94
77.0 22.10 1.87 23.14 1.91 24.18 1.94 24.70 1.96 26.27 2.01 27.31 2.05
86.0 21.05 1.99 22.09 2.02 23.13 2.06 23.65 2.08 25.21 2.13 26.26 2.16
89.6 20.63 2.04 21.67 2.07 22.71 2.11 23.23 2.13 24.79 2.18 25.83 2.21
95.0 20.00 2.11 21.04 2.15 22.08 2.18
22.60 2.20 24.16 2.26 25.20 2.29
104.0 18.94 2.25 19.99 2.28 21.03 2.32 21.55 2.34 23.11 2.39 24.15 2.43
109.4 15.94 1.77 16.64 1.77 17.32 1.77 17.66 1.77 18.64 1.77 19.28 1.77
114.8 10.08 0.98 10.47 0.98 10.84 0.98 11.03 0.98 11.57 0.98 11.92 0.98
CTXS07L +
FTXS18L
68.0 25.31 1.90 26.44 1.93 27.58 1.97 28.15 1.99 29.86 2.05 31.00 2.08
77.0 24.16 2.01 25.29 2.05 26.43 2.08 27.00 2.10 28.71 2.16 29.85 2.20
86.0 23.01 2.13 24.14 2.17 25.28 2.21 25.85 2.23 27.56 2.28 28.70 2.32
89.6 22.55 2.19 23.68 2.22 24.82 2.26 25.39 2.28 27.10 2.34 28.23 2.37
95.0 21.86 2.27 22.99 2.31 24.13 2.34
24.70 2.36 26.41 2.42 27.54 2.46
104.0 20.70 2.41 21.84 2.45 22.98 2.49 23.55 2.51 25.24 2.56 26.19 2.56
109.4 16.82 1.77 17.54 1.77 18.24 1.77 18.59 1.77 19.60 1.77 20.25 1.77
114.8 10.57 0.98 10.97 0.98 11.36 0.98 11.55 0.98 12.11 0.98 12.47 0.98
Combination
(Capacity)
Outdoor air
temp.
EDB (°F)
Indoor air temp. EWB (°F)
57.2 60.8 64.4 67.0 71.6 75.2
TC PI TC PI TC PI TC PI TC PI TC PI
kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW
