Daikin SUPER MULTI NX G Series User Manual

Specifications EDUS121131
28 SUPER MULTI NX 2/3/4MXS-G/J Series Heat Pump
07+07+12 Wall Wall Wall — 7.28 7.28 12.74 — 27.30 10.70 ~ 27.30 2520 700 ~ 2520 12.4 3.4 ~ 12.4 98
07+07+12 Wall Wall Duct — 7.09 7.09 12.42 — 26.60 10.40 ~ 26.60 2600 750 ~ 2600 12.8 3.7 ~ 12.8 98
07+07+15 Wall Wall Wall — 6.44 6.44 16.12 — 29.00 14.50 ~ 29.00 2790 910 ~ 2790 13.7 4.5 ~ 13.7 98
07+07+15 Wall Wall Duct — 6.00 6.00 15.00 — 27.00 14.20 ~ 27.00 2550 1040 ~ 2550 12.5 5.1 ~ 12.5 98
07+07+18 Wall Wall Wall — 5.88 5.88 17.64 — 29.40 14.60 ~ 29.40 2920 910 ~ 2920 14.3 4.5 ~ 14.3 98
07+07+18 Wall Wall Duct — 5.50 5.50 16.50 — 27.50 14.20 ~ 27.50 2660 1040 ~ 2660 13.0 5.1 ~ 13.0 98
07+09+09 Wall Wall Wall — 7.66 9.57 9.57 — 26.80 10.10 ~ 26.80 2410 670 ~ 2410 11.8 3.3 ~ 11.8 98
07+09+09 Wall Wall Duct — 7.46 9.32 9.32 — 26.10 9.80 ~ 26.10 2490 720 ~ 2490 12.2 3.5 ~ 12.2 98
07+09+09 Wall Duct Duct — 7.40 9.25 9.25 — 25.90 9.50 ~ 25.90 2680 770 ~ 2680 13.1 3.8 ~ 13.1 98
07+09+12 Wall Wall Wall — 6.98 8.72 12.20 — 27.90 10.70 ~ 27.90 2700 700 ~ 2700 13.2 3.4 ~ 13.2 98
07+09+12 Wall Wall Duct — 6.80 8.50 11.90 — 27.20 10.40 ~ 27.20 2790 750 ~ 2790 13.7 3.7 ~ 13.7 98
07+09+12 Wall Duct Wall — 6.80 8.50 11.90 — 27.20 10.40 ~ 27.20 2790 750 ~ 2790 13.7 3.7 ~ 13.7 98
07+09+12 Wall Duct Duct — 6.75 8.44 11.81 — 27.00 10.00 ~ 27.00 2990 800 ~ 2990 14.7 3.9 ~ 14.7 98
07+09+15 Wall Wall Wall — 6.21 7.76 15.53 — 29.50 14.50 ~ 29.50 2980 910 ~ 2980 14.6 4.5 ~ 14.6 98
07+09+15 Wall Wall Duct — 5.81 7.26 14.53 — 27.60 14.20 ~ 27.60 2660 1040 ~ 2660 13.0 5.1 ~ 13.0 98
07+09+15 Wall Duct Wall — 6.08 7.61 15.21 — 28.90 14.10 ~ 28.90 3070 950 ~ 3070 15.1 4.7 ~ 15.1 98
07+09+15 Wall Duct Duct — 5.66 7.08 14.16 — 26.90 13.80 ~ 26.90 2750 1080 ~ 2750 13.5 5.3 ~ 13.5 98
07+09+18 Wall Wall Wall — 5.75 7.19 17.26 — 30.20 14.60 ~ 30.20 3250 910 ~ 3250 15.9 4.5 ~ 15.9 98
07+09+18 Wall Wall Duct — 5.39 6.74 16.17 — 28.30 14.20 ~ 28.30 2840 1040 ~ 2840 13.9 5.1 ~ 13.9 98
07+09+18 Wall Duct Wall — 5.62 7.02 16.86 — 29.50 14.10 ~ 29.50 3270 950 ~ 3270 16.0 4.7 ~ 16.0 98
07+09+18 Wall Duct Duct — 5.26 6.57 15.77 — 27.60 13.80 ~ 27.60 2930 1080 ~ 2930 14.4 5.3 ~ 14.4 98
07+12+12 Wall Wall Wall — 6.44 11.28 11.28 — 29.00 14.00 ~ 29.00 3090 910 ~ 3090 15.2 4.5 ~ 15.2 98
07+12+12 Wall Wall Duct — 6.32 11.04 11.04 — 28.40 13.60 ~ 28.40 3170 950 ~ 3170 15.6 4.7 ~ 15.6 98
07+12+12 Wall Duct Duct — 6.22 10.89 10.89 — 28.00 13.00 ~ 28.00 3380 990 ~ 3380 16.6 4.9 ~ 16.6 98
07+12+15 Wall Wall Wall — 5.75 10.07 14.38 — 30.20 14.50 ~ 30.20 3250 910 ~ 3250 15.9 4.5 ~ 15.9 98
07+12+15 Wall Wall Duct — 5.39 9.43 13.48 — 28.30 14.20 ~ 28.30 2840 1040 ~ 2840 13.9 5.1 ~ 13.9 98
07+12+15 Wall Duct Wall — 5.62 9.83 14.05 — 29.50 14.10 ~ 29.50 3260 950 ~ 3260 16.0 4.7 ~ 16.0 98
07+12+15 Wall Duct Duct — 5.26 9.20 13.14 — 27.60 13.80 ~ 27.60 2930 1080 ~ 2930 14.4 5.3 ~ 14.4 98
07+12+18 Wall Wall Wall — 5.34 9.34 16.02 — 30.70 14.60 ~ 30.70 3520 910 ~ 3520 17.3 4.5 ~ 17.3 98
07+12+18 Wall Wall Duct — 5.03 8.80 15.07 — 28.90 14.20 ~ 28.90 3030 1040 ~ 3030 14.9 5.1 ~ 14.9 98
07+12+18 Wall Duct Wall — 5.23 9.16 15.71 — 30.10 14.10 ~ 30.10 3540 950 ~ 3540 17.4 4.7 ~ 17.4 98
07+12+18 Wall Duct Duct — 4.90 8.58 14.72 — 28.20 13.80 ~ 28.20 3120 1080 ~ 3120 15.3 5.3 ~ 15.3 98
07+15+15 Wall Wall Wall — 5.13 12.83 12.84 — 30.80 14.90 ~ 30.80 3340 900 ~ 3340 16.4 4.4 ~ 16.4 98
07+15+15 Wall Wall Duct — 4.84 12.08 12.08 — 29.00 14.70 ~ 29.00 2870 1030 ~ 2870 14.1 5.1 ~ 14.1 98
07+15+15 Wall Duct Duct — 4.54 11.33 11.33 — 27.20 14.40 ~ 27.20 2630 1170 ~ 2630 12.9 5.7 ~ 12.9 98
07+15+18 Wall Wall Wall — 4.74 11.85 14.21 — 30.80 15.00 ~ 30.80 3270 900 ~ 3270 16.0 4.4 ~ 16.0 98
07+15+18 Wall Wall Duct — 4.46 11.15 13.39 — 29.00 14.70 ~ 29.00 2870 1030 ~ 2870 14.1 5.1 ~ 14.1 98
07+15+18 Wall Duct Wall — 4.46 11.15 13.39 — 29.00 14.70 ~ 29.00 2870 1030 ~ 2870 14.1 5.1 ~ 14.1 98
07+15+18 Wall Duct Duct — 4.20 10.50 12.60 — 27.30 14.40 ~ 27.30 2680 1170 ~ 2680 13.1 5.7 ~ 13.1 98
07+18+18 Wall Wall Wall — 4.46 13.37 13.37 — 31.20 15.00 ~ 31.20 3480 900 ~ 3480 17.1 4.4 ~ 17.1 98
07+18+18 Wall Wall Duct — 4.38 13.16 13.16 — 30.70 14.70 ~ 30.70 3530 1030 ~ 3530 17.3 5.1 ~ 17.3 98
07+18+18 Wall Duct Duct — 4.32 12.94 12.94 — 30.20 14.40 ~ 30.20 3570 1170 ~ 3570 17.5 5.7 ~ 17.5 98
09+09+09 Wall Wall Wall — 9.10 9.10 9.10 — 27.30 10.70 ~ 27.30 2520 700 ~ 2520 12.4 3.4 ~ 12.4 98
09+09+09 Wall Wall Duct — 8.87 8.87 8.87 — 26.60 10.40 ~ 26.60 2600 750 ~ 2600 12.8 3.7 ~ 12.8 98
09+09+09 Wall Duct Duct — 8.80 8.80 8.80 — 26.40 10.00 ~ 26.40 2800 800 ~ 2800 13.7 3.9 ~ 13.7 98
09+09+09 Duct Duct Duct — 8.57 8.57 8.57 — 25.70 9.60 ~ 25.70 2940 840 ~ 2940 14.4 4.1 ~ 14.4 98
09+09+12 Wall Wall Wall — 8.35 8.35 11.70 — 28.40 10.70 ~ 28.40 2830 700 ~ 2830 13.9 3.4 ~ 13.9 98
09+09+12 Wall Wall Duct — 8.21 8.21 11.48 — 27.90 10.40 ~ 27.90 2970 750 ~ 2970 14.6 3.7 ~ 14.6 98
09+09+12 Wall Duct Wall — 8.21 8.21 11.48 — 27.90 10.40 ~ 27.90 2970 750 ~ 2970 14.6 3.7 ~ 14.6 98
09+09+12 Wall Duct Duct — 8.09 8.09 11.32 — 27.50 10.00 ~ 27.50 3180 800 ~ 3180 15.6 3.9 ~ 15.6 98
09+09+12 Duct Duct Wall — 8.09 8.09 11.32 — 27.50 10.00 ~ 27.50 3180 800 ~ 3180 15.6 3.9 ~ 15.6 98
09+09+12 Duct Duct Duct — 7.91 7.91 11.08 — 26.90 9.60 ~ 26.90 3390 840 ~ 3390 16.6 4.1 ~ 16.6 98
09+09+15 Wall Wall Wall — 7.35 7.35 14.70 — 29.40 14.50 ~ 29.40 2920 910 ~ 2920 14.3 4.5 ~ 14.3 98
09+09+15 Wall Wall Duct — 7.23 7.23 14.44 — 28.90 14.20 ~ 28.90 3030 1040 ~ 3030 14.9 5.1 ~ 14.9 98
09+09+15 Wall Duct Wall — 7.25 7.25 14.50 — 29.00 14.10 ~ 29.00 3070 950 ~ 3070 15.1 4.7 ~ 15.1 98
09+09+15 Wall Duct Duct — 7.13 7.13 14.24 — 28.50 13.80 ~ 28.50 3180 1080 ~ 3180 15.6 5.3 ~ 15.6 98
09+09+15 Duct Duct Wall — 7.13 7.13 14.24 — 28.50 13.60 ~ 28.50 3210 1000 ~ 3210 15.7 4.9 ~ 15.7 98
09+09+15 Duct Duct Duct — 7.00 7.00 14.00 — 28.00 13.30 ~ 28.00 3320 1120 ~ 3320 16.3 5.5 ~ 16.3 98
09+09+18 Wall Wall Wall — 6.95 6.95 16.70 — 30.60 14.60 ~ 30.60 3450 910 ~ 3450 16.9 4.5 ~ 16.9 98
09+09+18 Wall Wall Duct — 6.84 6.84 16.42 — 30.10 14.20 ~ 30.10 3500 1040 ~ 3500 17.2 5.1 ~ 17.2 98
09+09+18 Wall Duct Wall — 6.84 6.84 16.42 — 30.10 14.10 ~ 30.10 3540 950 ~ 3540 17.4 4.7 ~ 17.4 98
Combination
of
indoor unit
Type of indoor unit
Capacity of each indoor unit
Each capacity (kBtu/h) Total capacity (kBtu/h) Total input (W) Total current (A)
Power
factor (%)
A room B room C room D room A room B room C room D room Rating (min ~ max) Rating (min ~ max) Rating (min ~ max) Rating

Daikin SUPER MULTI NX G Series Specifications

General

Brand	Daikin
Model	SUPER MULTI NX G Series
Category	Air Conditioner
Language	English
