Daikin SUPER MULTI NX G Series User Manual

EDUS121131 Specifications
SUPER MULTI NX 2/3/4MXS-G/J Series Heat Pump 29
1
09+09+18 Wall Duct Duct — 6.73 6.73 16.14 — 29.60 13.80 ~ 29.60 3650 1080 ~ 3650 17.9 5.3 ~ 17.9 98
09+09+18 Duct Duct Wall — 6.70 6.70 16.10 — 29.50 13.60 ~ 29.50 3620 1000 ~ 3620 17.8 4.9 ~ 17.8 98
09+09+18 Duct Duct Duct — 6.52 6.52 15.66 — 28.70 13.30 ~ 28.70 3660 1120 ~ 3660 18.0 5.5 ~ 18.0 98
09+12+12 Wall Wall Wall — 7.76 10.87 10.87 — 29.50 14.00 ~ 29.50 3220 910 ~ 3220 15.8 4.5 ~ 15.8 98
09+12+12 Wall Wall Duct — 7.60 10.65 10.65 — 28.90 11.50 ~ 28.90 3370 820 ~ 3370 16.5 4.0 ~ 16.5 98
09+12+12 Wall Duct Duct — 7.48 10.46 10.46 — 28.40 11.00 ~ 28.40 3580 860 ~ 3580 17.6 4.2 ~ 17.6 98
09+12+12 Duct Wall Wall — 7.60 10.65 10.65 — 28.90 11.50 ~ 28.90 3370 820 ~ 3370 16.5 4.0 ~ 16.5 98
09+12+12 Duct Wall Duct — 7.48 10.46 10.46 — 28.40 11.00 ~ 28.40 3580 860 ~ 3580 17.6 4.2 ~ 17.6 98
09+12+12 Duct Duct Duct — 7.24 10.13 10.13 — 27.50 10.60 ~ 27.50 3660 900 ~ 3660 18.0 4.4 ~ 18.0 98
09+12+15 Wall Wall Wall — 6.95 9.74 13.91 — 30.60 14.50 ~ 30.60 3520 910 ~ 3520 17.3 4.5 ~ 17.3 98
09+12+15 Wall Wall Duct — 6.84 9.58 13.68 — 30.10 14.20 ~ 30.10 3500 1040 ~ 3500 17.2 5.1 ~ 17.2 98
09+12+15 Wall Duct Wall — 6.84 9.58 13.68 — 30.10 14.10 ~ 30.10 3610 950 ~ 3610 17.7 4.7 ~ 17.7 98
09+12+15 Wall Duct Duct — 6.73 9.42 13.45 — 29.60 13.80 ~ 29.60 3650 1080 ~ 3650 17.9 5.3 ~ 17.9 98
09+12+15 Duct Wall Wall — 6.84 9.58 13.68 — 30.10 14.10 ~ 30.10 3610 950 ~ 3610 17.7 4.7 ~ 17.7 98
09+12+15 Duct Wall Duct — 6.73 9.42 13.45 — 29.60 13.80 ~ 29.60 3650 1080 ~ 3650 17.9 5.3 ~ 17.9 98
09+12+15 Duct Duct Wall — 6.69 9.35 13.36 — 29.40 13.60 ~ 29.40 3620 1000 ~ 3620 17.8 4.9 ~ 17.8 98
09+12+15 Duct Duct Duct — 6.52 9.13 13.05 — 28.70 13.30 ~ 28.70 3660 1120 ~ 3660 18.0 5.5 ~ 18.0 98
09+12+18 Wall Wall Wall — 6.42 8.98 15.40 — 30.80 14.60 ~ 30.80 3600 910 ~ 3600 17.7 4.5 ~ 17.7 98
09+12+18 Wall Wall Duct — 6.31 8.84 15.15 — 30.30 14.20 ~ 30.30 3630 1040 ~ 3630 17.8 5.1 ~ 17.8 98
09+12+18 Wall Duct Wall — 6.29 8.81 15.10 — 30.20 14.10 ~ 30.20 3610 950 ~ 3610 17.7 4.7 ~ 17.7 98
09+12+18 Wall Duct Duct — 6.17 8.63 14.80 — 29.60 13.80 ~ 29.60 3650 1080 ~ 3650 17.9 5.3 ~ 17.9 98
09+12+18 Duct Wall Wall — 6.29 8.81 15.10 — 30.20 14.10 ~ 30.20 3610 950 ~ 3610 17.7 4.7 ~ 17.7 98
09+12+18 Duct Wall Duct — 6.17 8.63 14.80 — 29.60 13.80 ~ 29.60 3650 1080 ~ 3650 17.9 5.3 ~ 17.9 98
09+12+18 Duct Duct Wall — 6.15 8.60 14.75 — 29.50 13.60 ~ 29.50 3620 1000 ~ 3620 17.8 4.9 ~ 17.8 98
09+12+18 Duct Duct Duct — 5.98 8.37 14.35 — 28.70 13.30 ~ 28.70 3660 1120 ~ 3660 18.0 5.5 ~ 18.0 98
09+15+15 Wall Wall Wall — 6.18 12.36 12.36 — 30.90 14.90 ~ 30.90 3340 900 ~ 3340 16.4 4.4 ~ 16.4 98
09+15+15 Wall Wall Duct — 6.08 12.16 12.16 — 30.40 14.70 ~ 30.40 3390 1030 ~ 3390 16.6 5.1 ~ 16.6 98
09+15+15 Wall Duct Duct — 5.98 11.96 11.96 — 29.90 14.40 ~ 29.90 3430 1170 ~ 3430 16.8 5.7 ~ 16.8 98
09+15+15 Duct Wall Wall — 6.08 12.16 12.16 — 30.40 14.50 ~ 30.40 3430 950 ~ 3430 16.8 4.7 ~ 16.8 98
09+15+15 Duct Wall Duct — 5.98 11.96 11.96 — 29.90 14.30 ~ 29.90 3470 1080 ~ 3470 17.0 5.3 ~ 17.0 98
09+15+15 Duct Duct Duct — 5.88 11.76 11.76 — 29.40 14.00 ~ 29.40 3520 1210 ~ 3520 17.3 5.9 ~ 17.3 98
09+15+18 Wall Wall Wall — 5.76 11.52 13.82 — 31.10 15.00 ~ 31.10 3480 900 ~ 3480 17.1 4.4 ~ 17.1 98
09+15+18 Wall Wall Duct — 5.67 11.33 13.60 — 30.60 14.70 ~ 30.60 3460 1030 ~ 3460 17.0 5.1 ~ 17.0 98
09+15+18 Wall Duct Wall — 5.67 11.33 13.60 — 30.60 14.70 ~ 30.60 3460 1030 ~ 3460 17.0 5.1 ~ 17.0 98
09+15+18 Wall Duct Duct — 5.57 11.15 13.38 — 30.10 14.40 ~ 30.10 3500 1170 ~ 3500 17.2 5.7 ~ 17.2 98
09+15+18 Duct Wall Wall — 5.67 11.33 13.60 — 30.60 14.60 ~ 30.60 3500 950 ~ 3500 17.2 4.7 ~ 17.2 98
09+15+18 Duct Wall Duct — 5.57 11.15 13.38 — 30.10 14.30 ~ 30.10 3540 1080 ~ 3540 17.4 5.3 ~ 17.4 98
09+15+18 Duct Duct Wall — 5.57 11.15 13.38 — 30.10 14.30 ~ 30.10 3540 1080 ~ 3540 17.4 5.3 ~ 17.4 98
09+15+18 Duct Duct Duct — 5.46 10.93 13.11 — 29.50 14.00 ~ 29.50 3590 1210 ~ 3590 17.6 5.9 ~ 17.6 98
09+18+18 Wall Wall Wall — 5.40 12.95 12.95 — 31.30 15.00 ~ 31.30 3560 900 ~ 3560 17.5 4.4 ~ 17.5 98
09+18+18 Wall Wall Duct — 5.32 12.74 12.74 — 30.80 14.70 ~ 30.80 3600 1030 ~ 3600 17.7 5.1 ~ 17.7 98
09+18+18 Wall Duct Duct — 5.22 12.54 12.54 — 30.30 14.40 ~ 30.30 3640 1170 ~ 3640 17.9 5.7 ~ 17.9 98
09+18+18 Duct Wall Wall — 5.32 12.79 12.79 — 30.90 14.60 ~ 30.90 3640 950 ~ 3640 17.9 4.7 ~ 17.9 98
09+18+18 Duct Wall Duct — 5.22 12.54 12.54 — 30.30 14.30 ~ 30.30 3610 1080 ~ 3610 17.7 5.3 ~ 17.7 98
09+18+18 Duct Duct Duct — 5.10 12.25 12.25 — 29.60 14.00 ~ 29.60 3650 1210 ~ 3650 17.9 5.9 ~ 17.9 98
12+12+12 Wall Wall Wall — 10.07 10.07 10.07 — 30.20 14.00 ~ 30.20 3630 910 ~ 3630 17.8 4.5 ~ 17.8 98
12+12+12 Wall Wall Duct — 9.83 9.83 9.83 — 29.50 11.50 ~ 29.50 3640 820 ~ 3640 17.9 4.0 ~ 17.9 98
12+12+12 Wall Duct Duct — 9.50 9.50 9.50 — 28.50 11.00 ~ 28.50 3650 860 ~ 3650 17.9 4.2 ~ 17.9 98
12+12+12 Duct Duct Duct — 9.17 9.17 9.17 — 27.50 10.60 ~ 27.50 3660 900 ~ 3660 18.0 4.4 ~ 18.0 98
12+12+15 Wall Wall Wall — 8.98 8.98 12.84 — 30.80 14.50 ~ 30.80 3660 910 ~ 3660 18.0 4.5 ~ 18.0 98
12+12+15 Wall Wall Duct — 8.84 8.84 12.62 — 30.30 14.20 ~ 30.30 3630 1040 ~ 3630 17.8 5.1 ~ 17.8 98
12+12+15 Wall Duct Wall — 8.78 8.78 12.54 — 30.10 14.10 ~ 30.10 3610 950 ~ 3610 17.7 4.7 ~ 17.7 98
12+12+15 Wall Duct Duct — 8.63 8.63 12.34 — 29.60 13.80 ~ 29.60 3650 1080 ~ 3650 17.9 5.3 ~ 17.9 98
12+12+15 Duct Duct Wall — 8.58 8.58 12.24 — 29.40 13.60 ~ 29.40 3620 1000 ~ 3620 17.8 4.9 ~ 17.8 98
12+12+15 Duct Duct Duct — 8.37 8.37 11.96 — 28.70 13.30 ~ 28.70 3660 1120 ~ 3660 18.0 5.5 ~ 18.0 98
12+12+18 Wall Wall Wall — 8.29 8.29 14.22 — 30.80 14.60 ~ 30.80 3600 910 ~ 3600 17.7 4.5 ~ 17.7 98
12+12+18 Wall Wall Duct — 8.16 8.16 13.98 — 30.30 14.20 ~ 30.30 3630 1040 ~ 3630 17.8 5.1 ~ 17.8 98
12+12+18 Wall Duct Wall — 8.13 8.13 13.94 — 30.20 14.10 ~ 30.20 3610 950 ~ 3610 17.7 4.7 ~ 17.7 98
12+12+18 Wall Duct Duct — 7.97 7.97 13.66 — 29.60 13.80 ~ 29.60 3650 1080 ~ 3650 17.9 5.3 ~ 17.9 98
12+12+18 Duct Duct Wall — 7.94 7.94 13.62 — 29.50 13.60 ~ 29.50 3620 1000 ~ 3620 17.8 4.9 ~ 17.8 98
12+12+18 Duct Duct Duct — 7.73 7.73 13.24 — 28.70 13.30 ~ 28.70 3660 1120 ~ 3660 18.0 5.5 ~ 18.0 98
Combination
of
indoor unit
Type of indoor unit
Capacity of each indoor unit
Each capacity (kBtu/h) Total capacity (kBtu/h) Total input (W) Total current (A)
Power
factor (%)
A room B room C room D room A room B room C room D room Rating (min ~ max) Rating (min ~ max) Rating (min ~ max) Rating

Daikin SUPER MULTI NX G Series Specifications

General

Brand	Daikin
Model	SUPER MULTI NX G Series
Category	Air Conditioner
Language	English
