EDUS121131 Specifications
SUPER MULTI NX 2/3/4MXS-G/J Series Heat Pump 11
1
60 Hz, 208 - 230 V
Note:
1. See page 15 “Combination Capacity”.
2. The data are based on the conditions shown in the table below.
Model
3MXS24JVJU
Cooling Heating
Capacity kW —
Power Consumption W—
Running Current A—
Casing Color Ivory White
Compressor
Type Hermetically Sealed Swing Type
Model 2YC63EXD
Motor Output W 1,920
Refrigerant Oil
Model FVC50K
Charge oz (L) 26.5 (0.75)
Refrigerant
Type R-410A
Charge Lbs (kg) 6.61 (3.0)
Airflow Rate
H
cfm
2,062 1,840
M 1,840 1,840
L 1,642 459
H
m³/min
58.4 52.1
M 52.1 52.1
L 46.5 13.0
Fan
Type Propeller
Motor Output W 66
Running Current A H: 1.02 / M: 0.87 / L: 0.69 H: 0.87 / M: 0.87 / L: 0.05
Power Consumption W H: 95 / M: 74 / L: 55 H: 74 / M: 74 / L: 9
Starting Current A 17.8
Dimension (H W D)
in. (mm)
30-5/16 35-7/16 12-5/8 (770 900 320)
Packaged Dimension (H W D)
in. (mm)
35-7/8 37-11/16 15-15/16 (911 958 405)
Weight (Mass)
Lbs (kg)
168 (76)
Gross Weight (Gross Mass)
Lbs (kg)
196 (89)
Sound Pressure Level dB(A) 52 54
Piping
Connections
Liquid
in. (mm)
1/4 3 (6.4 3)
Gas
in. (mm)
3/8 1, 1/2 1, 5/8 1 (9.5 1, 12.7 1, 16.0 1)
Drain
in. (mm)
1 (25)
Heat Insulation Both Liquid and Gas Pipes
No. of Wiring Connection 3 for Power Supply, 4 for Interunit Wiring
Max. Interunit Piping Length ft (m)
230 (70) (for Total of Each Room)
82 (25) (for One Room)
Amount of Additional Charge of
Refrigerant
oz/ft
(g/m)
0.22 (20) (131.6 ft (40 m) or more)
Max. Installation Height Difference ft (m)
49.2 (15) (between Indoor Unit and Outdoor Unit)
24.6 (7.5) (between Indoor Units)
Drawing No. 3D066155
Conversion Formulae
kcal/h = kW × 860
Btu/h = kW × 3412
cfm = m³/min × 35.3
Cooling Heating Piping Length
Indoor ; 80°FDB (26.7°CDB) / 67°FWB (19.4°CWB)
Outdoor ; 95°FDB (35°CDB) / 75°FWB (24°CWB)
Indoor ; 70°FDB (21°CDB) / 60°FWB (15.6°CWB)
Outdoor ; 47°FDB (8.3°CDB) / 43°FWB (6°CWB)
25 ft (7.5 m)
