Specifications EDUS121131
10 SUPER MULTI NX 2/3/4MXS-G/J Series Heat Pump
3.2 Outdoor Unit
60 Hz, 208 - 230 V
Note:
1. See page 13 “Combination Capacity”.
2. The data are based on the conditions shown in the table below.
Model
2MXS18GVJU
Cooling Heating
Capacity kW —
Power Consumption W—
Running Current A—
Casing Color Ivory White
Compressor
Type Hermetically Sealed Swing Type
Model 2YC45EXD
Motor Output W 1,380
Refrigerant Oil
Model FVC50K
Charge oz (L) 26.5 (0.75)
Refrigerant
Type R-410A
Charge Lbs (kg) 5.73 (2.6)
Airflow Rate
H
cfm
1,730 1,448
L 1,518 1,377
H
m³/min
49 41
L4339
Fan
Type Propeller
Motor Output W 53
Running Current A H: 0.31 / L: 0.28 H: 0.27 / L: 0.25
Power Consumption W H: 65 / L: 57 H: 55 / L: 52
Starting Current A 10.6
Dimension (H W D)
in. (mm)
28-15/16 32-1/2 11-13/16 (735 825 300)
Packaged Dimension (H W D)
in. (mm)
31-7/16 39-5/16 15-3/8 (806 999 390)
Weight (Mass)
Lbs (kg)
139 (63)
Gross Weight (Gross Mass)
Lbs (kg)
144 (65)
Sound Pressure Level dB(A) 50 51
Piping
Connections
Liquid
in. (mm)
1/4 2 (6.4 2)
Gas
in. (mm)
3/8 2 (9.5 2)
Drain
in. (mm)
11/16 (18.0)
Heat Insulation Both Liquid and Gas Pipes
No. of Wiring Connection 3 for Power Supply, 4 for Interunit Wiring
Max. Interunit Piping Length ft (m)
164 (50) (for Total of Each Room)
82 (25) (for One Room)
Amount of Additional Charge of
Refrigerant
oz/ft
(g/m)
0.22 (20) (98.4 ft (30 m) or more)
Max. Installation Height Difference ft (m)
49.2 (15) (between Indoor Unit and Outdoor Unit)
24.6 (7.5) (between Indoor Units)
Drawing No. 3D058840
Conversion Formulae
kcal/h = kW × 860
Btu/h = kW × 3412
cfm = m³/min × 35.3
Cooling Heating Piping Length
Indoor ; 80°FDB (26.7°CDB) / 67°FWB (19.4°CWB)
Outdoor ; 95°FDB (35°CDB) / 75°FWB (24°CWB)
Indoor ; 70°FDB (21°CDB) / 60°FWB (15.6°CWB)
Outdoor ; 47°FDB (8.3°CDB) / 43°FWB (6°CWB)
25 ft (7.5 m)
