Daikin SUPER MULTI NX G Series User Manual

EDUS121131 Specifications
SUPER MULTI NX 2/3/4MXS-G/J Series Heat Pump 9
1
60 Hz, 208 - 230 V
Note:
 See page 13 ~ 50 “Combination Capacity”.
Model
CDXS15LVJU CDXS18LVJU
Cooling Heating Cooling Heating
Rated Capacity  15 kBtu/h Class 18 kBtu/h Class
External Static Pressure inAq (Pa) 0.16 (40) 0.16 (40)
Airflow Rate
H
cfm
(m³/min)
424 (12.0) 424 (12.0) 424 (12.0) 424 (12.0)
M 388 (11.0) 388 (11.0) 388 (11.0) 388 (11.0)
L 353 (10.0) 353 (10.0) 353 (10.0) 353 (10.0)
SL 297 (8.4) 297 (8.4) 297 (8.4) 297 (8.4)
Fan
Type Sirocco Fan Sirocco Fan
Motor Output W 130 130
Speed Steps 5 Steps, Quiet, Auto 5 Steps, Quiet, Auto
Air Filter Removable / Washable / Mildew Proof Removable / Washable / Mildew Proof
Running Current (Rated) A 0.79 0.79 0.79 0.79
Power Consumption (Rated) W 172 172 172 172
Power Factor (Rated) % 94.4 94.4 94.4 94.4
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H × W × D) in. (mm) 7-7/8 × 35-7/16 × 24-7/16 (200 × 900 × 620) 7-7/8 × 35-7/16 × 24-7/16 (200 × 900 × 620)
Packaged Dimensions (H × W × D) in. (mm) 10-1/2 × 43-9/16 × 29-9/16 (266 × 1,106 × 751) 10-1/2 × 43-9/16 × 29-9/16 (266 × 1,106 × 751)
Weight (Mass) Lbs (kg) 60 (27) 60 (27)
Gross Weight (Gross Mass) Lbs (kg) 75 (34) 75 (34)
Sound Pressure
Level
H / M / L / SL dB(A) 37 / 35 / 33 / 31 37 / 35 / 33 / 31 37 / 35 / 33 / 31 37 / 35 / 33 / 31
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Piping
Connections
Liquid in. (mm) 1/4 (6.4) 1/4 (6.4)
Gas in. (mm)  1/2 (12.7)  1/2 (12.7)
Drain in. (mm) VP20 (O.D.  1-1/32 (26.0), I.D. 25/32 (20.0)) VP20 (O.D.  1-1/32 (26.0), I.D. 25/32 (20.0))
Drawing No. C: 3D075721 C: 3D075722
Conversion Formulae
kcal/h = kW × 860
Btu/h = kW × 3412
cfm = m³/min × 35.3
