Daikin SUPER MULTI NX G Series User Manual

EDUS121131 Capacity Tables
SUPER MULTI NX 2/3/4MXS-G/J Series Heat Pump 67
1
Heating [60 Hz, 208 - 230 V]
Combination
(Capacity)
Indoor air
temp.
EDB (°F)
Outdoor air temp. EWB (°F)
5.0 14.0 23.0 32.0 43.0 50.0 59.0
TC PI TC PI TC PI TC PI TC PI TC PI TC PI
kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW
CTXS07L 60.8 5.16 0.57 6.20 0.60 7.24 0.63 8.28 0.66 9.52 0.69 10.36 0.72 11.39 0.75
64.4 5.03 0.58 6.07 0.61 7.11 0.64 8.15 0.66 9.40 0.70 10.23 0.72 11.27 0.75
68.0 4.91 0.58 5.95 0.61 6.99 0.64 8.02 0.67 9.27 0.71 10.10 0.73 11.14 0.76
70.0 4.84 0.59 5.88 0.62 6.91 0.65 7.95 0.67
9.20 0.71 10.03 0.73 11.07 0.76
71.6 4.78 0.59 5.82 0.62 6.86 0.65 7.90 0.68 9.14 0.71 9.97 0.74 11.01 0.77
75.2 4.65 0.60 5.69 0.63 6.73 0.65 7.77 0.68 9.02 0.72 9.85 0.74 10.89 0.77
CTXS09H 60.8 6.62 0.79 7.95 0.83 9.29 0.87 10.62 0.91 12.22 0.96 13.28 0.99 14.61 1.03
64.4 6.46 0.80 7.79 0.84 9.12 0.88 10.45 0.92 12.05 0.97 13.12 1.00 14.45 1.04
68.0 6.29 0.81 7.63 0.85 8.96 0.89 10.29 0.93 11.89 0.98 12.96 1.01 14.29 1.05
70.0 6.20 0.81 7.54 0.85 8.87 0.89 10.20 0.93
11.80 0.98 12.87 1.01 14.20 1.05
71.6 6.13 0.81 7.46 0.85 8.80 0.90 10.13 0.94 11.73 0.98 12.79 1.02 14.13 1.06
75.2 5.97 0.82 7.30 0.86 8.63 0.90 9.97 0.94 11.56 0.99 12.63 1.03 13.96 1.07
FDXS09L 60.8 6.45 0.84 7.75 0.89 9.05 0.93 10.35 0.97 11.91 1.03 12.94 1.06 14.24 1.10
64.4 6.29 0.85 7.59 0.90 8.89 0.94 10.19 0.98 11.75 1.04 12.79 1.07 14.08 1.11
68.0 6.13 0.86 7.43 0.91 8.73 0.95 10.03 0.99 11.59 1.04 12.63 1.08 13.93 1.12
70.0 6.05 0.87 7.34 0.91 8.64 0.95 9.94 1.00
11.50 1.05 12.54 1.08 13.84 1.13
71.6 5.98 0.87 7.27 0.92 8.57 0.96 9.87 1.00 11.43 1.05 12.47 1.09 13.77 1.13
75.2 5.82 0.88 7.12 0.93 8.41 0.97 9.71 1.01 11.27 1.06 12.31 1.10 13.50 1.13
CTXS07L +
CTXS07L
60.8 10.55 1.15 12.67 1.21 14.79 1.27 16.92 1.33 19.46 1.40 21.16 1.44 23.28 1.50
64.4 10.29 1.16 12.41 1.22 14.53 1.28 16.66 1.34 19.20 1.41 20.90 1.46 23.02 1.52
68.0 10.03 1.18 12.15 1.23 14.27 1.29 16.40 1.35 18.94 1.42 20.64 1.47 22.77 1.53
70.0 9.88 1.18 12.01 1.24 14.13 1.30 16.25 1.36
18.80 1.43 20.50 1.48 22.62 1.54
71.6 9.77 1.19 11.89 1.25 14.01 1.31 16.14 1.37 18.68 1.44 20.38 1.48 22.51 1.54
75.2 9.51 1.20 11.63 1.26 13.75 1.32 15.88 1.38 18.43 1.45 20.12 1.50 22.25 1.55
CTXS07L +
CTXS09H
60.8 12.01 1.37 14.42 1.45 16.84 1.52 19.26 1.59 22.16 1.67 24.09 1.73 26.50 1.80
64.4 11.71 1.39 14.13 1.46 16.54 1.53 18.96 1.60 21.86 1.69 23.79 1.74 26.21 1.81
68.0 11.42 1.41 13.83 1.48 16.25 1.55 18.66 1.62 21.56 1.70 23.50 1.76 25.91 1.83
70.0 11.25 1.41 13.67 1.48 16.08 1.56 18.50 1.63
21.40 1.71 23.33 1.77 25.75 1.84
71.6 11.12 1.42 13.54 1.49 15.95 1.56 18.37 1.63 21.27 1.72 23.20 1.77 25.62 1.84
75.2 10.82 1.44 13.24 1.51 15.66 1.58 18.07 1.65 20.97 1.73 22.91 1.79 25.32 1.86
CTXS07L +
FDXS09L
60.8 11.78 1.52 14.15 1.60 16.52 1.68 18.90 1.75 21.74 1.85 23.64 1.91 26.01 1.99
64.4 11.49 1.54 13.86 1.61 16.23 1.69 18.61 1.77 21.45 1.86 23.35 1.93 25.72 2.00
68.0 11.20 1.55 13.57 1.63 15.94 1.71 18.32 1.79 21.16 1.88 23.06 1.94 25.43 2.02
70.0 11.04 1.56 13.41 1.64 15.78 1.72 18.15 1.80
21.00 1.89 22.90 1.95 25.27 2.03
71.6 10.91 1.57 13.28 1.65 15.65 1.73 18.03 1.80 20.87 1.90 22.77 1.96 25.14 2.04
75.2 10.62 1.59 12.99 1.67 15.36 1.74 17.74 1.82 20.58 1.91 22.48 1.98 24.85 2.05
CTXS09H +
CTXS09H
60.8 13.46 1.58 16.17 1.67 18.88 1.75 21.59 1.83 24.85 1.92 27.01 1.99 29.72 2.07
64.4 13.13 1.60 15.84 1.68 18.55 1.76 21.26 1.85 24.52 1.94 26.68 2.01 29.39 2.09
68.0 12.80 1.62 15.51 1.70 18.22 1.78 20.93 1.86 24.18 1.96 26.35 2.03 29.06 2.11
70.0 12.62 1.63 15.33 1.71 18.04 1.79 20.75 1.87
24.00 1.97 26.17 2.03 28.88 2.12
71.6 12.47 1.64 15.18 1.72 17.89 1.80 20.60 1.88 23.85 1.98 26.02 2.04 28.73 2.12
75.2 12.14 1.65 14.85 1.74 17.56 1.82 20.27 1.90 23.52 2.00 25.69 2.06 28.40 2.14
CTXS09H +
FDXS09L
60.8 13.24 1.71 15.91 1.80 18.57 1.89 21.23 1.98 24.43 2.08 26.56 2.15 29.23 2.24
64.4 12.91 1.73 15.58 1.82 18.24 1.91 20.91 1.99 24.11 2.10 26.24 2.17 28.90 2.26
68.0 12.59 1.75 15.25 1.84 17.92 1.93 20.58 2.01 23.78 2.12 25.91 2.19 28.58 2.28
70.0 12.41 1.76 15.07 1.85 17.74 1.94 20.40 2.02
23.60 2.13 25.73 2.20 28.40 2.29
71.6 12.26 1.77 14.93 1.86 17.59 1.95 20.26 2.03 23.46 2.14 25.59 2.21 28.25 2.30
75.2 11.94 1.79 14.60 1.88 17.27 1.96 19.93 2.05 23.13 2.16 25.26 2.23 27.93 2.32
