SUPER MULTI NX 2/3/4MXS-G/J Series Heat Pump 27
1
3.5 Combination Capacity: 4MXS32GVJU
Cooling [60 Hz, 208 V]
Combination
of
indoor unit
Type of indoor unit
Capacity of each indoor unit
Each capacity (kBtu/h) Total capacity (kBtu/h) Total input (W) Total current (A)
Power
factor (%)
A room B room C room D room A room B room C room D room Rating (min ~ max) Rating (min ~ max) Rating (min ~ max) Rating
07 Wall — — — 7.60 — — — 7.60 6.50 ~ 7.60 670 590 ~ 670 3.3 2.9 ~ 3.3 98
09 Wall — — — 9.70 — — — 9.70 6.50 ~ 9.70 820 590 ~ 820 4.0 2.9 ~ 4.0 98
09 Duct — — — 9.40 — — — 9.40 6.00 ~ 9.40 880 620 ~ 880 4.3 3.0 ~ 4.3 98
12 Wall — — — 13.00 — — — 13.00 6.50 ~ 13.00 1130 590 ~ 1130 5.5 2.9 ~ 5.5 98
12 Duct — — — 12.10 — — — 12.10 6.00 ~ 12.10 1160 620 ~ 1160 5.7 3.0 ~ 5.7 98
15 Wall — — — 16.20 — — — 16.20 7.00 ~ 16.20 1430 600 ~ 1430 7.0 2.9 ~ 7.0 98
15 Duct — — — 15.10 — — — 15.10 6.70 ~ 15.10 1510 730 ~ 1510 7.4 3.6 ~ 7.4 98
18 Wall — — — 19.50 — — — 19.50 7.50 ~ 19.50 1950 630 ~ 1950 9.6 3.1 ~ 9.6 98
18 Duct — — — 18.10 — — — 18.10 7.20 ~ 18.10 1960 750 ~ 1960 9.6 3.7 ~ 9.6 98
07+07 Wall Wall — — 8.30 8.30 — — 16.60 7.90 ~ 16.60 1310 620 ~ 1310 6.4 3.0 ~ 6.4 98
07+09 Wall Wall — — 8.09 10.11 — — 18.20 7.90 ~ 18.20 1480 620 ~ 1480 7.3 3.0 ~ 7.3 98
07+09 Wall Duct — — 7.38 9.22 — — 16.60 7.50 ~ 16.60 1420 660 ~ 1420 7.0 3.2 ~ 7.0 98
07+12 Wall Wall — — 7.75 13.55 — — 21.30 7.90 ~ 21.30 1900 620 ~ 1900 9.3 3.0 ~ 9.3 98
07+12 Wall Duct — — 7.20 12.60 — — 19.80 7.50 ~ 19.80 1880 660 ~ 1880 9.2 3.2 ~ 9.2 98
07+15 Wall Wall — — 7.46 18.64 — — 26.10 9.30 ~ 26.10 2760 680 ~ 2760 13.5 3.3 ~ 13.5 98
07+15 Wall Duct — — 6.69 16.71 — — 23.40 9.10 ~ 23.40 2360 810 ~ 2360 11.6 4.0 ~ 11.6 98
07+18 Wall Wall — — 6.65 19.95 — — 26.60 9.90 ~ 26.60 2830 710 ~ 2830 13.9 3.5 ~ 13.9 98
07+18 Wall Duct — — 5.93 17.78 — — 23.70 9.60 ~ 23.70 2410 840 ~ 2410 11.8 4.1 ~ 11.8 98
09+09 Wall Wall — — 9.90 9.90 — — 19.80 7.90 ~ 19.80 1660 620 ~ 1660 8.1 3.0 ~ 8.1 98
09+09 Wall Duct — — 9.10 9.10 — — 18.20 7.50 ~ 18.20 1640 660 ~ 1640 8.0 3.2 ~ 8.0 98
09+09 Duct Duct — — 8.25 8.25 — — 16.50 7.10 ~ 16.50 1530 690 ~ 1530 7.5 3.4 ~ 7.5 98
09+12 Wall Wall — — 9.50 13.30 — — 22.80 8.40 ~ 22.80 2160 650 ~ 2160 10.6 3.2 ~ 10.6 98
09+12 Wall Duct — — 8.88 12.42 — — 21.30 8.00 ~ 21.30 2130 680 ~ 2130 10.4 3.3 ~ 10.4 98
09+12 Duct Wall — — 8.88 12.42 — — 21.30 8.00 ~ 21.30 2130 680 ~ 2130 10.4 3.3 ~ 10.4 98
09+12 Duct Duct — — 8.21 11.49 — — 19.70 7.60 ~ 19.70 2040 720 ~ 2040 10.0 3.5 ~ 10.0 98
09+15 Wall Wall — — 8.67 17.33 — — 26.00 9.90 ~ 26.00 2700 710 ~ 2700 13.2 3.5 ~ 13.2 98
09+15 Wall Duct — — 8.47 16.93 — — 25.40 9.60 ~ 25.40 2820 840 ~ 2820 13.8 4.1 ~ 13.8 98
09+15 Duct Wall — — 8.17 16.33 — — 24.50 9.40 ~ 24.50 2600 750 ~ 2600 12.8 3.7 ~ 12.8 98
09+15 Duct Duct — — 7.97 15.93 — — 23.90 9.20 ~ 23.90 2770 880 ~ 2770 13.6 4.3 ~ 13.6 98
09+18 Wall Wall — — 7.97 19.13 — — 27.10 9.90 ~ 27.10 3020 710 ~ 3020 14.8 3.5 ~ 14.8 98
09+18 Wall Duct — — 7.76 18.64 — — 26.40 9.60 ~ 26.40 3120 840 ~ 3120 15.3 4.1 ~ 15.3 98
09+18 Duct Wall — — 7.85 18.85 — — 26.70 9.50 ~ 26.70 3290 750 ~ 3290 16.1 3.7 ~ 16.1 98
09+18 Duct Duct — — 7.65 18.35 — — 26.00 9.20 ~ 26.00 3460 880 ~ 3460 17.0 4.3 ~ 17.0 98
12+12 Wall Wall — — 13.05 13.05 — — 26.10 8.90 ~ 26.10 3040 670 ~ 3040 14.9 3.3 ~ 14.9 98
12+12 Duct Wall — — 12.30 12.30 — — 24.60 8.50 ~ 24.60 2990 710 ~ 2990 14.7 3.5 ~ 14.7 98
12+12 Duct Duct — — 11.50 11.50 — — 23.00 8.00 ~ 23.00 2870 750 ~ 2870 14.1 3.7 ~ 14.1 98
12+15 Wall Wall — — 11.20 16.00 — — 27.20 9.90 ~ 27.20 3080 710 ~ 3080 15.1 3.5 ~ 15.1 98
12+15 Wall Duct — — 10.91 15.59 — — 26.50 9.60 ~ 26.50 3190 840 ~ 3190 15.6 4.1 ~ 15.6 98
12+15 Duct Wall — — 10.87 15.53 — — 26.40 9.40 ~ 26.40 3220 750 ~ 3220 15.8 3.7 ~ 15.8 98
12+15 Duct Duct — — 10.58 15.12 — — 25.70 9.20 ~ 25.70 3320 880 ~ 3320 16.3 4.3 ~ 16.3 98
12+18 Wall Wall — — 10.43 17.87 — — 28.30 12.90 ~ 28.30 3550 900 ~ 3550 17.4 4.4 ~ 17.4 98
12+18 Wall Duct — — 10.17 17.43 — — 27.60 12.50 ~ 27.60 3650 1030 ~ 3650 17.9 5.1 ~ 17.9 98
12+18 Duct Wall — — 10.09 17.31 — — 27.40 12.40 ~ 27.40 3630 940 ~ 3630 17.8 4.6 ~ 17.8 98
12+18 Duct Duct — — 9.73 16.67 — — 26.40 11.90 ~ 26.40 3660 1060 ~ 3660 18.0 5.2 ~ 18.0 98
15+15 Wall Wall — — 14.20 14.20 — — 28.40 13.40 ~ 28.40 3180 910 ~ 3180 15.6 4.5 ~ 15.6 98
15+15 Duct Wall — — 13.85 13.85 — — 27.70 13.10 ~ 27.70 3490 1030 ~ 3490 17.1 5.1 ~ 17.1 98
15+15 Duct Duct — — 13.50 13.50 — — 27.00 12.80 ~ 27.00 3400 1160 ~ 3400 16.7 5.7 ~ 16.7 98
15+18 Wall Wall — — 13.36 16.04 — — 29.40 13.50 ~ 29.40 3660 910 ~ 3660 18.0 4.5 ~ 18.0 98
15+18 Wall Duct — — 12.95 15.55 — — 28.50 13.10 ~ 28.50 3630 1030 ~ 3630 17.8 5.1 ~ 17.8 98
15+18 Duct Wall — — 13.00 15.60 — — 28.60 13.20 ~ 28.60 3630 1030 ~ 3630 17.8 5.1 ~ 17.8 98
15+18 Duct Duct — — 12.64 15.16 — — 27.80 12.80 ~ 27.80 3660 1160 ~ 3660 18.0 5.7 ~ 18.0 98
18+18 Wall Wall — — 14.70 14.70 — — 29.40 13.50 ~ 29.40 3600 910 ~ 3600 17.7 4.5 ~ 17.7 98
18+18 Duct Wall — — 14.30 14.30 — — 28.60 13.20 ~ 28.60 3630 1030 ~ 3630 17.8 5.1 ~ 17.8 98
18+18 Duct Duct — — 13.90 13.90 — — 27.80 12.80 ~ 27.80 3660 1160 ~ 3660 18.0 5.7 ~ 18.0 98
07+07+07 Wall Wall Wall — 8.00 8.00 8.00 — 24.00 9.50 ~ 24.00 1910 640 ~ 1910 9.4 3.1 ~ 9.4 98
07+07+09 Wall Wall Wall — 7.82 7.82 9.76 — 25.40 10.10 ~ 25.40 2130 670 ~ 2130 10.4 3.3 ~ 10.4 98
07+07+09 Wall Wall Duct — 7.60 7.60 9.50 — 24.70 9.80 ~ 24.70 2210 720 ~ 2210 10.8 3.5 ~ 10.8 98
